- Page 1 USER’S MANUAL Folding Poker Table TQ10082 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Before You Start
Before You Start Please read all instructions carefully and keep it for future reference. Warnings: Attention! Use it with protective equipment. Attention! Not use it in the traffic. Attention! The product is not suitable for the children under 3 years. General Warnings: The product must be installed and used under the supervision of an adult. -
Page 3: Specifications
Safety Alert: Contains small parts, not suitable for children under 36 months! Maximum Load: 66 lbs/30 kg Safety Alert: This stroller must be assembled by an adult. Please read and understand this manual before use! This manual contains important information, please keep it for future reference. - Page 4 Specifications Battery 6V4.5Ah*1 Charger In-put 6V500MA Motor RS380SP 6V (380#) 25W RPM12000*2 Suitable age 37-95 months Charging time 6-10 hours Maximum load 66 lbs/30 kg For one person only Car size 26*26*18.7”/66.5*66.5*47.6 cm Package size 26*8.8*26”/66.5*66.5*47.6 cm Speed 2-2.5miles/h, 3-6Km/h Battery Safety Alert ●...
- Page 5 Spare parts list Number Name Image Quantity Cushiong screw Head stock Backrest...
- Page 6 Seat Wheel Motor Body Universal wheel Rear axle Fixed piece Gasket M8 machine screw M4*14 screw...
-
Page 7: Safety Alert
Safety Alert To prevent accidents ● The vehicle must be under adult supervision. Always be within the sight of an adult when in use. ● When driving a vehicle, you should wear a protective helmet, must wear shoes, must sit in the seat. ●... - Page 8 Wheels Assembly As the picture shows: 1. Turn the body over and install the motor(Plug in the motor connection wire pair according to the wire color and embed it in the body hole.) 2. Insert the wheels into the rear axle, follow the gasket, and tighten it with a M8 machine screw.
- Page 9 Front Faucet and Backrest Assembly 1. Connect the wire from the head stock with the car body according to their same color. 2. Insert the head stock into the car body according to the slot. 3. Tighten it with car body with the M4*14 screws. 4.
- Page 10 Battery Connection and Cushion Installation As shown in the figure, please connect the power wire according to their same color, before tight the seat with the cushion screw! Insert the seat into the slot as shown in the picture. 1 and 2: car front and rear switch, two forwards at the same time according to move the car forward;...
- Page 11 How to use the remote control (if equipped) 1.Forward 5.Speed 2.Back 6.Right 3.Brake 7.Speed display 4.Left Frequency Channel (MHz) 2426 How to connect the remote control with the vehicle, check follows: First, open the cover in back of the remote control,put two 1.5V aa battery (prepared by yourself) Note: Place the positive and negative poles.
- Page 12 Charging Warning This product has a charging protection function: when charging, has no functions. Only adults can charge the battery! When charging, the power switch must be off. Before the first use, the battery should be charged for 4-6 hours. The charging time should not exceed 10 hours to prevent the battery from overheating.
-
Page 13: Failure Recovery
Failure Recovery Fault Type Checkpoint Troubleshooting The vehicle Low battery Charging. is not running Thermal protector Reset the protector. See protector. tripped Loose battery Check the battery. connector or wire Battery is damaged Please replace the battery. The electrical system Please contact customer services. - Page 14 Need to Poor contact of wires Check whether the battery move or connectors connector is firmly inserted and forward the wires around the motor. Motor crashes A crash means that the power is not transmitted to the terminal and the vehicle needs to be repaired.
-
Page 15: Maintenance
Maintenance ● Parents are responsible for checking the main components of the vehicle before use, and must regularly check for potential hazards. For example,whether batteries, chargers, cables or wires, plugs, screws are fastened to other parts of the shell, if such damage occurs, the toy must be properly removed before the toy can be used. - Page 16 Protector The battery has a thermal fuse and rest protector, which will automatically trip and cut off all functions if the vehicle electrical system or battery is overloaded.The protector will reset, and the power will be restored 20 seconds after the device is turned off, and then turned on again. If the thermal protector blows repeatedly during normal use, the vehicle may need repair, please contact your dealer.
- Page 17 Replacements for missing or damaged parts will be shipped ASAP ! US office: Fontana UK office: Ipswich AU office: Truganina DE office: Hamburg FR office: Saint Vigor d'Ymonville PL office: Gdańsk Contact Us! Do NOT return this item. US:cs.us@costway.com UK:cs.uk@costway.com AU:cs.au@costway.com...
