Viewing on a Television Set

In addition to being viewed on the camera's LCD
screen, recorded video clips or still images can be
viewed on a TV screen. The TV screen can be used to
frame the subject during video recording.
To view images on a TV set, select the video output
system first.
A. Selecting a Video Output System
1. Press the MENU button to enter
the Setup mode ( ).
2. Use the 4-way arrow button to
select " " – Video Out, then
select "NTSC" or "PAL".
NTSC: For USA, Canada, Mexico,
Taiwan, Korea, Japan, etc.
PAL: For Europe, Australia, China,
Singapore, etc.
3. Press the button, then the MENU
button to exit the menu.
B. Viewing the Image on a TV Set
1. Make sure that both TV set and DV camera are
turned off.
2. Connect the DV camera to your TV set, using the
provided Video cable.
• Connect one end of the Video
cable to the DV camera's TV-
output connector.
• Connect the other end of the
cable to the Video-In jack of the
TV set.
3. Turn on the TV set, and select the channel through
the Video Input.
4. Power on the DV camera, then press the MODE
button.
To play back, press the
mode ( ).
To use the TV screen to frame the subject during video
shooting, press the
The image will appear on the TV monitor.
button to enter Playback
button to enter Video mode ( ).
15
