Page 2
PART LIST Left Leg Right Leg Left Back Leg Right Back Leg Seat 1 PC 1 PC 1 PC 1 PC 1 PC Back Support Tube Middle Pole Plastic Spacer 1 PC 1 PC 2 PCS 2 PCS HARDWARE LIST M6*18mm M6*15mm M6*10mm...
Page 3
Step 1. Attach back (part F) to seat (part E) using short bolts (part #3), barrel bolts (part #4) and allen wrenches (part #7). Remove all protective caps from seat (part E). NOTE: Please don't fully tighten bolts until unit is fully assembled.
Page 4
Step 2. Insert left back leg (part C) into left leg (part A) and right back leg (part D) into right leg (part B) using plastic spacer (part I). Secure assembled unit (parts A, B, C, D & I) using bolts (part #1) and allen wrench (part #7).
Page 5
Step 4. Attach seat (part E) to assembled unit (parts B & D) using medium bolts (part #2), plastic caps (part #5) and allen wrench (part #7). NOTE: Please don't fully tighten bolts until unit is fully assembled. Step 5. Attach support tube (part G) to seat (part E) using medium bolts (part #2), plastic caps (part #5) and allen wrench (part #7).
Page 6
Step 6. Attach middle pole (part H) to legs (parts A & B) using medium bolts (part #2), plastic caps (part #5) and allen wrench (part #7). NOTE: Please don't fully tighten bolts until unit is fully assembled. Step 7. Attach middle pole (part H) to back legs (parts C & D) using medium bolts (part #2), plastic caps (part #5) and allen wrench (part #7).
Page 7
Step 8. Attach plastic caps (part #5) and nut caps (part #6) to back (part F). NOTE: Please fully tighten all bolts at this time.
