Crosley Furniture PALM HARBOR CO7107-BR Manual

Bar stool

PALM HARBOR OUTDOOR

WICKER 24" BAR STOOL

CO7107-BR

1 of 7

Table of Contents

Need help?

Do you have a question about the PALM HARBOR CO7107-BR and is the answer not in the manual?

Page 1 PALM HARBOR OUTDOOR WICKER 24" BAR STOOL CO7107-BR 1 of 7...
Page 2 Congratulations! You have purchased a stylish piece of Crosley Furniture. We strived to provide fine furniture products, built with quality materials and hand finished details. Please carefully follow the assembly instructions to ensure your furniture is assembled correctly to provide long lasting enjoyment.
Page 3 PART LIST Foot panel Seat Stretcher 2pcs 2pcs HARDWARE LIST Washer(M6mm) Bolt(M6*20mm) Bolt(M6*40mm) 12pcs 4pcs 16pcs Allen Key(M6mm) Screw cap(M6mm) 16pcs 3 of 7...
Page 4 Step 1. Attach foot panels (B) into stretcher (C). Please do not screw at this step. Step 2. Lay seat (A) down on a flat surface.Attach assmbled parts B, C to the seat (A) using bolts (D), washers (F), allen key (H) in vertical direction. Cross direction by using bolts (E),washers (F), allen key (H) .
Page 5 Step 3. Using bolts (D), and washers (F) attach stretchers (C) to foot panels (B). Step 4. Tighten all bolts, and put Caps (G) on the head of bolts. X 16 5 of 7...
Page 6 Step 5. Turn the assembled bar stool upright on a flat surface. 6 of 7...
Page 7 Limited Manufacturers Warranty Crosley Furniture Products are warranted against defects in material and workmanship for a period of 90 days beginning from the date of sale. Should any parts be missing or defective, we will replace or repair the parts for a period of 90 days from the date of purchase.
