- Page 1 PORTABLE AIR CONDITIONER PAT Series OWNER’S MANUAL OPERATOR’S MANUAL TECHNICAL MANUAL For models: GPC08AO-A3NNA1A Please read this owner’s manual carefully before operating the unit and keep it for future reference. IMPORTANT : The remote control and hardware necessary to use your new product is included inside the box.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Operation Notices ........................3 Safety warnings ................................3 Exception Clauses ..............................3 The Refrigerant ................................4 Safety precautions ..............................5 Operation environment ............................6 Parts name ...................................7 Operation Guide ........................8 Operation introduction for control panel......................8 Operation of control panel ............................Buttons on remote controller ..........................10 Maintenance ...........................14 Clean and maintenance ............................14 Installation ..........................16... -
Page 3: Operation Notices
OPERATION NOTICES DANGER Safety warnings This symbol indicates the possibility of death or serious injury. WARNING This symbol indicates the possibility of injury or damage to CAUTION property. Indicates important but not hazard-related information, NOTICE used to indicate risk of property damage. Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons. -
Page 4: The Refrigerant
The refrigerant Appliance filled with flammable gas R410A. Before use the appliance, read the owner’s manual first. Before install the appliance, read the installation manual first. Before repair the appliance, read the service manual first. To realize the function of the air conditioner unit, a special refrigerant circulates in the system. The used refrigerant is the fluoride R410A, which is specially cleaned. -
Page 5: Safety Precautions
DANGER Safety precautions WARNING • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been CAUTION given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 6: Operation Environment
Operation environment • Operating Temperature Range Maximum cooling: DB/WB(°F/°C), 95/75(35/24) The air conditioner must be operated within the temperature range: 61°F (16°C)~95°F (35°C). • The appliance is for indoor use only. • The appliance must be positioned so that the plug is accessible. •... -
Page 7: Parts Name
Parts name NOTICE: Actual product may be different from graphics, please refer to actual products. Installation accessories can't be discarded. 1. Controller panel 2. Guide louver 3. Handels 4. Filter 5. Air inlet 6. Middle drainage port 7. Power cord 8. -
Page 8: Operation Guide
OPERATION GUIDE Operation introduction for control panel Fan mode indicator Dry mode indicator Dual-8 nixie tube Fan speed indicator + / - button Cool mode indicator Mode Auto Timer button Swing ON/OFF button button Fan button Mode button NOTE: • After putting through the power, the air conditioner will give out a sound. After that, you can operate the air conditioner by the control panel. -
Page 9: Operation Of Control Panel
Operation of control panel 1 ON/OFF BUTTON Pressing this button can turn on or turn off the air conditioner. 2 + / – BUTTON Under cooling mode, press “+” or “–” button to increase or decrease set temperature by 1°F (°C). Set temperature range is 61°F (16°C)~86°F (30°C). -
Page 10: Buttons On Remote Controller
Buttons on remote controller AUTO Auto mode Cool mode AUTO Dry mode Fan mode Heat mode Mode Timer on Timer off Swing operation Sleep operation Lock Set speed Set temperature Set time Send signal Introduction for buttons on remote controller NOTE: •... - Page 11 MODE BUTTON Pressing this button once can select your required mode circularly as below (the corresponding icon " 3 " will be lit up after the mode is selected): AUTO - 4COOL - 4DRY HEAT - 4FAN (Only for models with heating function) •...
- Page 12 TIMER BUTTON • When unit is on, press this button to set Timer Off. T-OFF and H icon will be blinking. Within 5 seconds, press + or - button to adjust the time for Timer Off. Pressing + or - button once will increase or decrease the time by 0.5h.
- Page 13 Replacement of batteries in remote controller Battery 1. Press the back side of remote controller on the spot Reinstall marked with " ", and then push out the cover of battery box along the arrow direction. Remove 2. Replace two 7# (AAA 1.5V) dry batteries and make sure the positions of + and - polar are correct.
-
Page 14: Maintenance
MAINTENANCE DANGER Clean and maintenance WARNING • Before cleaning the air conditioner, please turn off the unit and disconnect power. Otherwise, it may cause electric shock. CAUTION • Do not wash air conditioner with water. Otherwise, it may cause electric shock. •... - Page 15 Clean heat discharge pipe Remove the heat discharge pipe from air conditioner, clean and dry it, and then reinstall it. (For the method of installation and removal, please refer to the instruction for "Installation of heat discharge pipe"). Checking before use-season 1.
-
Page 16: Installation
INSTALLATION DANGER Installation precaution WARNING • Observe all governing codes and ordinances. • Do not use damaged or non-standard power cord. CAUTION • Be caution during installation and maintenance. Prohibit incorrect operation to prevent electric shock, casualty and other accidents. NOTICE Selection of installation location Basic requirement... -
Page 17: Preparation For Installation
Preparation for installation NOTE: Check if the accessories are available before installation. Please refer to the window panel installation section for the list of these specific accessories. Accessory list Heat Joint A discharge pipe Rear clip Cord hook Screws User's manual AUTO Remote Battery... -
Page 18: Drain Water
Drainage de l’eau • To reach the maximum performance, it is not recommended to drain water, during Cool mode. • It is recommended to use the middle drainage port to drain water, during Dry mode. • To drain water from the bottom drainage port when the display shows "H8". Drainage method: 1. - Page 19 AVERTISSEMENT 3. Insert the drainage hose into drain connector. ATTENTION When using continuous drainage option from the middle hole, place portable on a level surface AVIS and make sure garden hose is clear of any obstructions and is directed downward. Placing porta- ble on an uneven surface or improper hose installation may result in water filling up the chassis and causing the unit to shut off.
-
Page 20: Installation Of Heat Discharge Pipe
Installation of heat discharge pipe Install heat discharge pipe 1.Rotate joint A and Rear clip clockwise into the The discharge pipe is suggested to be installed two ends of heat discharge pipe. according to below figure by the manufacturer. Clockwise Joint A Heat Rear clip... -
Page 21: Install Window Panel
Install window panel Accessory list Adjustment Mothproof Mounting Screw panel plate Window Bracket Rain guard panel Extension Fixed base Foam seal A panel Exhaust Foam seal B Fixed clip cover (adhesive type) Suggested tools for installation 1. Screwdriver (medium size Phillips) 2. Tape measure or ruler 3. Knife or scissors 4. - Page 22 6.1 For the window is too narrow for direct in- 8. Install the window panel into the window stallation, The window panel needs to be frame. Make sure that the exhaust cover is cut down in size. attached to the window panel. 6.2 If the width of window is larger than the length of window panel, please use the adjustment panel to make sure you can...
-
Page 23: Malfunction Analysis
MALFUNCTION ANALYSIS Please check below items before asking for maintenance. If the malfunction still can’t be elimi- nated, please contact local dealer or qualified professionals. Issue Possible Causes Solution Power failure? Wait after power recovery. Is plug loose? Reinsert the plug. Whether the air switch is tripped off or Ask professional person to replace air Air conditioner... - Page 24 Issue Possible Causes Solution Whether air outlet or air inlet is Eliminate the obstacles blocked? Under heating mode, whether The unit will stop blowing fan after indoor temperature increase set reaching set temperature. temperature?(Cool & Heat Unit only) No air blowed In order to prevent cold air, air out from air Whether heating mode is started up...
-
Page 25: Annex
ANNEX Operation test • Put through the power supply and then press ON/OFF button on remote controller to start the unit. • Press mode button to select auto, cooling, drying, fan or heating function, and then check if the unit operates normally. -
Page 26: Assistance
ASSISTANCE Distributed by Ouellet Canada Inc. 1 877 247-3461 Before returning the unit to the retailer, for any problem related to the installation, use or proper functioning of the unit; contact our customer support department. One of our agents will guide you through the next steps.
