Table of Contents

Owner's Manual
Original Instructions
Split Air Conditioner
CONTENTS
......................................................................................
..................................................................................................
.........................................................................................
.......................................................................................
Thank you for choosing our product.
Please read this Owner's Manual carefully before operation and
retain it for future reference.
Notice：
Actual product may be different from graphics,
please refer to actual products.
...............................................................................
.............................................................
..............................................................................
..................................................................
.......................................................................................
............................................
01
05
06
12
13
14
16
19
20
22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GWH09AGA-K6DNA1A and is the answer not in the manual?

Questions and answers

Related Manuals for Tosot GWH09AGA-K6DNA1A

Summary of Contents for Tosot GWH09AGA-K6DNA1A

  • Page 1: Table Of Contents

    Owner's Manual Original Instructions Split Air Conditioner CONTENTS Safety precautions ..................Parts name ....................Operation and introduction of remote contr oller ..........Clean and maintenance ................Checked items before maintenance ............. Installation notice ..................Installation of indoor unit ................Test and operation ..................
  • Page 2 GWH09AGA-K6DNA1A/I GWH09AGB-K6DNA1B/I GWH12AGB-K6DNA1A/I GWH12AGC-K6DNA1A/I GWH18AGD-K6DNA1A/I...
  • Page 3 Explanation of Symbols WARNING This symbol indicates the possibility of death or serious injury. This symbol indicates the possibility of injury or damage to CAUTION property. Indicates important but not hazard-related information, used NOTICE to indicate risk of property damage. Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons.
  • Page 4 The refrigerant This appliance is not intended for use by persons Before install the Appliance filled (including children) with reduced physical, sensory appliance, read with flammable or mental capabilities, or lack of expe the installation gas R32. knowledge, unless they have been given superv- manual first.
  • Page 5 Safety operation of flammable refrigerant Installation notes Check whether there is fire source or potential fire source in the maintenance area. The air conditioner must be installed in a room - The naked flame is prohibited in the mainte- that is larger than the minimum room area. The nance area;...

  • Page 6: Safety Precautions

    Safety precautions WARNING Installation Installation or maintenance The grounding resistance must be performed by qua- should comply with nation- lified professionals. al electric safety regula- The appliance shall be in- tions. stalled in accordance with Air Conditioner should be national wiring regulations. properly grounded.
  • Page 7 Safety precautions CAUTION Installation Instructions for installation For the air conditioner with- and use of this product are out plug, a circuit breaker provided by the manufac- must be installed in the turer. line. Select a location which is The yellow-green wire in out of reach for children air conditioner is ground- and far away from animals...
  • Page 8 Safety precautions WARNING Operation and Maintenance tioner to multi-purpose soc- This appliance can be used ket. Otherwise, it may cau- by children aged from 8 se fire hazard. years and above and per- Do disconnect power supp- sons with reduced physi- ly when cleaning air condi- cal, sensory or mental ca- tioner.
  • Page 9 Safety precautions CAUTION Operation and Maintenance frequently. Do not spill water on the re- Air conditioner gives off mote controller, otherwise burning smell. the remote controller may Indoor unit is leaking. be broken. Do not use fire or hair dry- er to dry the filter to avoid deformation or fire hazard.

  • Page 10: Parts Name

    Parts name Indoor Unit air inlet panel filter aux. button panel upper air guide louver air outlet lower air guide louver ■ If remote controller is lost or damaged, please use aux. button to turn on or turn off the air conditioner.

  • Page 11: Operation And Introduction Of Remote Controller

    Operation and introduction of remote controller Introduction for icons on display Buttons on remote controller screen I feel Set fan speed Turbo mode Send signal Auto mode Cool mode Dry mode Fan mode Heat mode Sleep mode 8℃ heating function Health mode Scavenging function ON/OFF...
  • Page 12 Introduction for buttons on Press " " / " " button to adjust fan blowing angle. remote controller (Cooling only unit won’t receive heating mode signal. If setting heat mode with remote controller, press ON/ Notice OFF button can’t start up the unit). ●...
  • Page 13 Hold " "button above 2s to set your required ● swing angle. When reaching your required Press "▲" or " " button once increase or de cr- angle, release the button. ease set temperature 1 ℃ (°F). Holding "▲" or "...
  • Page 14 setting temperature. ● After starting up T-ON or T-OFF,set the constant cir- Sleep 2 is sleep mode 2, that is air conditioner ● culating valid. will run according to the presetting a group of After that,air conditioner will be turned on or turned off sleep temperature curve.
  • Page 15 Notice ● Under energy-saving function, fan speed is defaulted Press this button to achieve the on and off of at auto speed and it can t be adjusted. health and scavenging functions in operation st- ● Under energy-saving function, set temperature can ation.
  • Page 16 Auto clean function Notice ● During operation, point the remote control signal Under unit off status, hold "Mode" and "Fan" sender at the receiving window on indoor unit. buttons simultaneously for 5s to turn on or turn off ● The distance between signal sender and receiving the auto clean function.

  • Page 17: Clean And Maintenance

    Clean and maintenance WARNING ■ The filter should be cleaned every three months . If there is much dust in the operation environme- WARNING nt, clean frequency can be increased. ■ Turn off the air conditioner and disconnect the ■ After removing the filter, do not touch fins to power before cleaning the air conditioner to av- avoid injury.

  • Page 18: Checked Items Before Maintenance

    Checked items before maintenance Phenomenon Solution Check items General phenomenon analysis Whether there’s od- Eliminate the odour Odours are our source, such as Please check below ite ms before asking for source. Clean the furniture and cigare- emitted filter. maintenance. If the malfunction still can’t be tte, etc.

  • Page 19: Installation Notice

    Installation notice WARNING sure that the unit is running in cooling mode. Then, fully close the valve at high pressure side (liquid valve). About 30-40 seconds later, fully close the valve at low pressure side (gas valve), immediately stop the unit and disconnect power.
  • Page 20 Selection of installation location Requirements for electric connection Basic requirement 7.If the supply cord is damaged, it must be repla- Installing the unit in the following places may cau- ced by the manufacturer, its service agent or se malfunction. If it is unavoidable, please consu- similarly qualified persons in order to avoid a lt the local dealer: hazard .

  • Page 21: Installation Of Indoor Unit

    Installation of indoor unit Notice Indoor outdoor ● Pay attention to dust prevention Step 1: sures when opening the hole. Choose installation location Φ55 5-10 Φ70 Recommend the installation location to the client and then confirm it with the client. Step 2: Step 4: Install wall-mounting frame...
  • Page 22 Tightening torque (N . m) drain hose Hex nut diameter Φ 6 15~20 Φ 9.52 30~40 Φ 12 45~55 insulating pipe Φ 16 60~65 Notice Φ 19 70~75 ● Add insulating pipe in the indoor drain hose in order to prevent condensation. ●...
  • Page 23 drain hose connection pipe Remove the wire clip; connect the power conn- band ection wire to the wiring terminal according to the color; tighten the screw and then fix the po- wer connection wire with wire clip. indoor power cord 09K、12K: Bind them evenly.

  • Page 24: Test And Operation

    Test and operation Check after installation ● Check according to the following requirement after finishing installation. Items to be checked Possible malfunction Has the unit been The unit may drop, shake or installed firmly? emit noise. It may cause insufficient Have you done the refri- cooling(heating) capacity.

  • Page 25: Configuration Of Connection Pipe

    Configuration of connection pipe Additional refrigerant charging amount for R32 Standard length of connection pipe: 5m, 7.5m, Min. length of connection pipe. For the unit with standard connection pipe of 5m, there is no limitation for the min length of con- nection pipe.
  • Page 26 B: Remove the burrs smooth surface Remove the burrs with shaper and prevent the ● burrs from getting into the pipe. improper expanding pipe shaper leaning damaged crack uneven surface thickness downwards the length is equal Working temperature range Outdoor side Indoor side C: Put on suitable insulating pipe DB/WB （℃）...

  • Page 27: Specialist's Manual

    Specialist’s Manual The following checks shall be applied to instal- fire extinguishing equipment shall be available to ● lations using flammable refrigerants: hand. Have a dry powder or CO fire extinguisher adjacent to the charging area. – the charge size is in accordance with the room size within which the refrigerant containing parts are in- Ventilated area ●...
  • Page 28 Specialist’s Manual Repair to intrinsically safe components – recovery equipment and cylinders conform to ● the appropriate standards. Do not apply any permanent inductive or capaci- d) Pump down refrigerant system, if possible. tance loads to the circuit without ensuring that this e) If a vacuum is not possible, make a manifold so will not exceed the permissible voltage and current that refrigerant can be removed from various parts...
  • Page 29 Specialist’s Manual dition, a set of calibrated weighing scales shall be available and in good working order. Hoses shall be complete with leak-free disconnect couplings and in good condition. Before using the recovery mac- hine, check that it is in satisfactory working order, has been properly maintained and that any associ- ated electrical components are sealed to prevent ignition in the event of a refrigerant release.
  • Page 32 66129935484...
