  • Page 1 RACK 2 2-SLOT 80 SERIES USER MANUAL August/2022 Rev. 1.0.

  • Page 2: Table Of Contents

    Heritage Audio - Madrid, Spain © 2022 Heritage Audio S.L. is the sole owner of the copyright of all information and drawings contained in this manual which are not to be copied or reproduced by any means or disclosed in part or whole to any third party without written permission.

  • Page 3: Description

    DESCRIPTION Our Rack 2 is handmade in the EU employing the same exact ISEP mechanical components used in the Series 80 consoles with aluminium rails, guides, etc. This will ensure your original vintage modules, as well as any of the currently made modules, will fit like a glove.

  • Page 4: Getting Started

    GETTING STARTED FRONT SECURITY RAIL 2 x EDGE CONNECTOR Impedance Switch Space 2 x D.I. JACK INPUT OUTPUT ATTENUATOR To fasten and secure the 80 To connect and power the 80 Opening to allow the Discreet Class A JFET Attenuates from 0 to -inf. Series Modules in place.
  • Page 5 REAR POWER CONNECTOR LINE OUTPUT LINE INPUT MIC INPUT Standard IEC connects the external 2 x Male XLR, Gold Plated. 2 x Female XLR, Gold Plated. 2 x Female XLR, Gold Plated. power supply. Accepts 90-240 V AC. All XLRs are: MALE XLR FEMALE XLR Pin 1: GND...

  • Page 6: Applications

    APPLICATIONS *8173 Modules ACTIVATE +48 V FOR CONDENSER not included CONDENSER MIC - L USB - COMPUTER MIC INPUT 1 MIC INPUT 2 OUTPUT - 2 OUTPUT -1 LINE INPUTS - AUDIO INTERFACE CONDENSER MIC - R D.I. D.I. INPUT 1 *8173 Modules not included USB - COMPUTER...

  • Page 7: Specifications

    SPECIFICATIONS • Handcrafted in the EU employing the same mechanical components used in vintage Series 80 consoles. • Neutrik gold-plated XLRs for Mic and Line inputs. • Neutrik gold plated XLRs outputs. • Illuminated red pushbuttons for +48 V phantom power (Less than 260 mA @ 48 V DC). •...

  • Page 8: Warranty Statement

    2 years to the original purchaser. In the event of such defects, the product will be repaired without charge or, at our option, replaced with a new one if delivered to Heritage Audio prepaid, together with a copy of the sales slip or other proof of purchase date.

  • Page 9: Recall Sheets

    RECALL SHEETS...
  • Page 10 HERITAGE AUDIO. C/ Alfonso Gómez, 38, 3C. 28037 Madrid – Spain. Tel: +34 917 266 189 info@heritageaudio.com...
