FRAME 8
8-SLOT
80 SERIES
USER MANUAL
August/2022 Rev. 1.0.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 80 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heritage Audio 80 Series

Summary of Contents for Heritage Audio 80 Series

  • Page 1 FRAME 8 8-SLOT 80 SERIES USER MANUAL August/2022 Rev. 1.0.

  • Page 2: Table Of Contents

    Heritage Audio - Madrid, Spain © 2022 Heritage Audio S.L. is the sole owner of the copyright of all information and drawings contained in this manual which are not to be copied or reproduced by any means or disclosed in part or whole to any third party without written permission.

  • Page 3: Description

    DESCRIPTION Our FRAME 8 is handmade in the EU employing the same exact ISEP mechanical components used in the Series 80 consoles with aluminium rails, guides, etc. This will ensure your original vintage modules, as well as any of the currently made modules, will fit like a glove.
  • Page 4 GETTING STARTED FRONT PHANTOM POWER SWITCH OUTPUT ATTENUATOR 8 x EDGE CONNECTOR Impedance Switch Space RAIL Activates the 48 V power for Attenuates from 0 to infinity To connect and power the 80 Opening to allow the To fasten and secure the 80 Condenser MICs.
  • Page 5 REAR MIC INPUT LINE INPUT LINE OUTPUT POWER CONNECTOR 8 x Female XLR, Gold Plated. 8 x Female XLR, Gold Plated. 8 x Male XLR, Gold Plated. Neutrik gold plated 4-pin XLR. All XLRs are: MALE XLR FEMALE XLR Pin 1: GND GND Pin 2: Hot Hot (+)

  • Page 6: Applications

    APPLICATIONS DRUM RECORDING 1 - MIC INPUT KICK 2 - MIC INPUT SNARE SNARE 3 - MIC INPUT 4 - MIC INPUT HI HAT TOM 1 5 - MIC INPUT 6 - MIC INPUT TOM 2 7 - MIC INPUT OH - L OH - R 8 - MIC INPUT...
  • Page 7 LINE LINE OUTPUTS KEYBOARD LINE INPUTS 1-2 OUTPUTS 1-2 USB - COMPUTER LINE INPUTS - AUDIO INTERFACE 6673 Modules not included...
  • Page 8 AUDIO PROCESSING THUNDERBOLT COMPUTER MONITOR SPEAKERS AUDIO INTERFACE LINE LINE OUTPUTS INPUTS LINE INPUTS 1-8 OUTPUTS 1-8 8173 & 6673 Modules not included...

  • Page 9: Specifications

    SPECIFICATIONS • Handcrafted in the EU employing the same mechanical components used in vintage Series 80 consoles. • Neutrik gold-plated XLRs for Mic and Line inputs. • Neutrik gold plated XLRs outputs. • Illuminated red pushbuttons for +48 V phantom power (Less than 260 mA @ 48 V DC). •...

  • Page 10: Warranty Statement

    2 years to the original purchaser. In the event of such defects, the product will be repaired without charge or, at our option, replaced with a new one if delivered to Heritage Audio prepaid, together with a copy of the sales slip or other proof of purchase date.

  • Page 11: Recall Sheets

    RECALL SHEETS...
  • Page 12 HERITAGE AUDIO. C/ Alfonso Gómez, 38, 3C. 28037 Madrid – Spain. Tel: +34 917 266 189 info@heritageaudio.com...
