MA 3010 Series
MA 4010 Series
Full Installation Guide
Everything you need to get your TV safely on the wall, in no time
Before you start
...we just wanted to say thanks for choosing Vogel's. Smart choice.
And you're already making another smart choice – reading the manual! Keep reading to learn all
about safe, efficient installation, and how to use your new mount.
Stay safe
Warning
Always read these safety instructions carefully before installing and using this product.
Following these instructions is strictly required. Incorrect mounting and/or installation could
put you, your TV, and your family at substantial risk.
MA 3010/4010 Series - English
1
Advertisement
Related Manuals for vogel's MA 3010 Series
Summary of Contents for vogel's MA 3010 Series
- Page 1 MA 3010 Series MA 4010 Series Full Installation Guide Everything you need to get your TV safely on the wall, in no time Before you start …we just wanted to say thanks for choosing Vogel’s. Smart choice. And you’re already making another smart choice – reading the manual! Keep reading to learn all about safe, efficient installation, and how to use your new mount.
- Page 2 Don’t dare risk it… Read all Vogel’s recommends that the mounting and/or installation of this product should be carried out by a suitably qualified expert. Vogel’s cannot be held responsible for any injury and/or damage caused by incorrect installation.
-
Page 3: What's In Your Box
What’s in your box? Something missing? Make sure your packaging has everything in place: A. Wall mount B. Strips C. Instructions D. Bolts for fastening strips on TV M6 bolts M8 bolts E. Spacers F. Washers G. Fischer© Plugs (fischer© DuoPower) H. - Page 4 Got your tools ready? Don’t start without all the necessary tools: Crosshead screwdriver or crosshead attachment for electric screwdriver Drilling machine with screwdriver function No. 8 wrench For walls with wooden studs: 3mm or 1/9” wood drill ...
- Page 5 Ready… set… get installing! Step 1: Attach the strips to the TV 1. Tilt the hooks away from the strips Ⓑ in case you want to mount your TV in a tilted position. 2. Tighten the hooks using a screwdriver and number 8 wrench. ...
- Page 6 Are you missing any bolts? Or need different ones? The friendly team at Vogel’s Consumer Care are waiting to help: vogels.com/contact Make sure bolts and spacers are positioned correctly. Refer to the user manual of your TV for the correct mounting material. Step 2: Attach the wall mount to the wall How well do you know your walls? What they’re made of matters more than you think…...
- Page 7 1. Decide how high you want the wall mount Ⓐ to be. Aim for the TV to be at eye level when seated. 2. Hold the wall mount Ⓐ against the wall and mark the location of the 4 holes. Use a spirit level to level the wall mount.
- Page 8 5. Attach the wall mount Ⓐ to the wall with the bolts Ⓗ , washers Ⓕ , and plugs Ⓖ . Lubricate the bolts for easy screwing in. Wooden wall with studs 1. Don’t just guess! Always use a stud finder to determine the position of studs. ...
- Page 9 6. Attach the wall mount Ⓐ to the wall with the bolts Ⓗ and washers Ⓕ . Lubricate the bolts for easy screwing in. Other wall type / I don’t know my wall type If your wall is a little special – for example, hollow bricks, metal stud walls, wood panels or plasterboard –...
- Page 10 Step 3: Attach the TV to the wall mount 1. Carefully lift and attach the TV to the wall mount Ⓐ . Lifting your TV is a two-person job. Don’t be bold! Job done now! Enjoy watching your TV! MA 3010/4010 Series - English...
- Page 11 Handy features Tilt 1. Unplug the cables from your TV. 2. Move the TV slightly to the left. 3. Lift your TV off of the wall mount Ⓐ , and put it down somewhere safe. Again, lifting your TV is a two-person job. Always get help. MA 3010/4010 Series - English...
- Page 12 4. Loosen the screws on the strips Ⓑ using a screwdriver and number 8 wrench. 5. Pull the hooks on the strips Ⓑ out for more tilt angle or push them in for a smaller tilt angle. 6. Tighten the screws on the strips Ⓑ using a screwdriver and number 8 wrench. ...
- Page 13 3. Lift your TV off of the wall mount Ⓐ , and put it down somewhere safe. Again, lifting your TV is a two-person job. Always get help. Tell us how you feel! Your opinion matters more than you might think. It helps us make better products, and helps other customers make informed choices.
-
Page 14: Simple Troubleshooting
‘Which bolts or screws do I need to Vogel's offers a complete assembly kit with all mounting use?’ materials included in the box, for both your TV and wall. - Page 15 ‘What is VESA?’ VESA is a standard pattern of mounting location holes on the back of a TV which allows many standard TV mounts to be easily fitted to your TV. Go green! We care about the planet. If you’re getting rid of the packaging or the TV mount itself, please visit your local recycling facility, or contact your municipal office.
- Page 16 Guarantee Thanks again for choosing Vogel’s! That is why Vogel’s gives you a 2-year guarantee for defects in materials and manufacturing. 1. Vogel’s guarantees that if during the guarantee period of a product, faults arise due to defects in manufacturing and/or materials, it will, at its discretion, repair or if necessary replace the product, free of charge.
