MA 3010 Series
MA 4010 Series
Full Installation Guide
Everything you need to get your TV safely on the wall, in no time
Before you start
...we just wanted to say thanks for choosing Vogel's. Smart choice.
And you're already making another smart choice – reading the manual! Keep reading to learn all about safe, efficient installation, and
how to use your new mount.
Stay safe
Warning
Always read these safety instructions carefully before installing and using this product.
Following these instructions is strictly required. Incorrect mounting and/or installation could put you, your TV, and your family at
substantial risk.
Don't dare risk it... Read all
https://manuals.vogels.com/en-us/ma3010_4010.html
MA 3010 Series
Additional tools
Click to watch
(https://youtu.be/XR8FJmoYFkI)
1/13
