- Page 1 LATCH-16 User Manual | 3097 LATCH-16 PART #3097 USER MANUAL © Sealevel Systems, Inc. 3097 Manual | SL9124 12/2022...
-
Page 2: Table Of Contents
SOFTWARE INSTALLATION ..........................8 SPECIFICATIONS ............................... 10 APPENDIX A – TROUBLESHOOTING........................ 11 APPENDIX B – HOW TO GET ASSISTANCE ..................... 12 APPENDIX C – COMPLIANCE NOTICES ......................13 WARRANTY ................................ 14 © Sealevel Systems, Inc. 3097 Manual | SL9124 12/2022... -
Page 3: Introduction
This allows “non-volatility” in the relay circuit. The Sealevel LATCH-16 provides two 8-bit latching relay output ports. This allows the user to set the LATCH-16 to a desired state, which is unaffected by power loss or interruption. The 16 relays remain in the desired state regardless of the power up / down condition of the PC. -
Page 4: Before You Get Started
Before You Get Started What’s Included The LATCH-16 (3097) is shipped with the following items. If any of these items are missing or damaged, please contact Sealevel for replacement. LATCH-16 (3097) Adapter • Advisory Conventions Warning The highest level of importance used to stress a condition where damage could result to the product, or the user could suffer serious injury. -
Page 5: Installation
Be sure to set the Address and Jumper Options before installation. The LATCH-16 can be installed in any of the PC expansion slots, except J8 on the original IBM "XT" and Portable. Remove the PC case, remove the blank metal slot cover, and insert the board. Replace the screw, replace the case, and the installation is complete. -
Page 6: Port Enable / Disable
“1”. Port Enable / Disable The LATCH-16 can be enabled or disabled with switch position 8 on the dipswitch. The port is enabled with the switch "On" or "Closed" and disabled when "Off" or "Open". Technical Description The LATCH-16 provides two eight bit latched relay output ports. - Page 7 Base+3 An I/O read to Base+3 will return a 0 in bit position D0 if a write to Base+2 is in progress (Set B). An I/O read to Base+3 will return a 0 in bit position D1 if a write to Base+3 is in progress (Reset B). © Sealevel Systems, Inc. 3097 Manual | SL9124 12/2022...
-
Page 8: Software Installation
Only users running Windows 7 or newer should utilize these instructions for accessing and installing the appropriate driver via Sealevel’s website. If you are utilizing an operating system prior to Windows 7, please contact Sealevel by calling 864.843.4343 or emailing support@sealevel.com... - Page 9 For additional software support, please call Sealevel Systems’ Technical Support, (864) 843-4343. Our technical support is free and available from 8:00 AM - 5:00 PM Eastern Time, Monday through Friday. For email support contact: support@sealevel.com. Port A 2,20 3,21 4,22...
-
Page 10: Specifications
Boards are built to UL 94V0 rating and are 100% electrically tested. These printed circuit boards are solder mask over bare copper or solder mask over tin nickel. Power Consumption Supply line +5 VDC Rating 210 mA © Sealevel Systems, Inc. 3097 Manual | SL9124 12/2022... -
Page 11: Appendix A - Troubleshooting
If these steps do not solve your problem, please call Sealevel Systems’ Technical Support, (864) 843-4343. Our technical support is free and available from 8:00 A.M.to 5:00 P.M. Eastern Time Monday through Friday. -
Page 12: Appendix B - How To Get Assistance
If possible, please have the adapter installed in a computer ready to run diagnostics. 3. Sealevel Systems provides an FAQ section on its web site. Please refer to this to answer many common questions. This section can be found at http://www.sealevel.com/faq.htm... -
Page 13: Appendix C - Compliance Notices
Always use cabling provided with this product if possible. If no cable is provided or if an alternate cable is required, use high quality shielded cabling to maintain compliance with FCC/EMC directives. © Sealevel Systems, Inc. 3097 Manual | SL9124 12/2022... -
Page 14: Warranty
Sealevel's commitment to providing the best I/O solutions is reflected in the Lifetime Warranty that is standard on all Sealevel manufactured I/O products. We are able to offer this warranty due to our control of manufacturing quality and the historically high reliability of our products in the field. Sealevel products are designed and manufactured at its Liberty, South Carolina facility, allowing direct control over product development, production, burn-in and testing.
