Anybus
Communicator
- PROFINET IO-Device to EtherCAT Slave
5.3. Connect to PROFINET Network
Figure 5. Connect to PROFINET network
1. Connect the Communicator, upper connector, to your PROFINET network.
EtherNet/IP Connector
To Do Next
Connect the Communicator to the EtherCAT network and to power.
Check LED status, refer to
Communicator LED
Page 10 of 56
Pin
1
2
3
4
5
6
7
8
Indicators.
Connect to PROFINET Network
Description
TD+
TD-
RD+
Not used
Not used
RD-
Not used
Not used
SCM-1202-193 Version 1.0
