Graco 4EVER DLX EXTEND2FIT Instruction Manual

4-in-1 car seat featuring anti-rebound bar
Hide thumbs Also See for 4EVER DLX EXTEND2FIT:

Advertisement

Table of Contents

NWL0001153323A 8/20
4EVER
Read This Instruction Manual
Do not install or use this child restraint until you read and understand
FAILURE TO PROPERLY USE THIS CHILD RESTRAINT INCREASES THE
RISK OF SERIOUS INJURY OR DEATH IN A SUDDEN STOP OR CRASH.
NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 1
NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 1
DLX EXTEND2FIT
®
4-IN-1 CAR SEAT
featuring Anti-Rebound bar
the instructions in this manual.
www.gracobaby.com
®
8/28/20 3:50 PM
8/28/20 3:50 PM

Advertisement

Table of Contents
loading

Related Manuals for Graco 4EVER DLX EXTEND2FIT

Summary of Contents for Graco 4EVER DLX EXTEND2FIT

  • Page 1 FAILURE TO PROPERLY USE THIS CHILD RESTRAINT INCREASES THE RISK OF SERIOUS INJURY OR DEATH IN A SUDDEN STOP OR CRASH. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 1 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 1 8/28/20 3:50 PM...
  • Page 2 Certification Car Seat’s Useful Life Vehicle Seat Protection Warm Weather Use 1-E Safety Warnings 2 Features Pages 28-33 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 2 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 2 8/28/20 3:50 PM 8/28/20 3:50 PM...

  • Page 3: Rear-Facing

    Pages 50-67 4-A Forward-Facing Use 4-B Install Forward-Facing with LATCH 4-C Install Forward-Facing with the Vehicle Seat Belt NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 3 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 3 8/28/20 3:50 PM 8/28/20 3:50 PM...

  • Page 4: Securing Child

    6-D Securing Child Highback Booster 6-E Securing Child Backless Booster 7 Moving the Lower Anchor Pages 107-110 Attachment 8 Accessories Page 111 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 4 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 4 8/28/20 3:50 PM 8/28/20 3:50 PM...

  • Page 5: Vehicle Information

    11-C Cleaning Harness, Lower Anchor Attachment and Tether 11-D Cleaning Extend2Fit Extension Panel ® 11-E Cleaning Anti-Rebound Bar NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 5 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 5 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 6 According to the AAP , these infants may suffer breathing issues if improperly reclined in a exam car seat. When rear-facing, use the corrected age for preemies. Graco advises that you have be u your physician or hospital staff evaluate your infant and recommend the proper car seat or car bed before you and your infant leave the hospital.
  • Page 7 In the event there is no back seat, review your vehicle owner’s manual to see how to use your child restraint. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 7 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 7 8/28/20 3:50 PM...
  • Page 8 LATCH system, although some manufacturers began including LATCH earlier. Some vehicle owner manuals use the term ISOFIX to identify the LATCH system. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 8 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 8 8/28/20 3:50 PM...
  • Page 9 Other vehicle types may have different lower anchor and 11” tether anchor locations. (28 cm) Vehicle’s Lower Anchor Vehicle Seat Bight NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 9 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 9 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 10 11 inches (28 cm) from the center of one lower anchor to the center of the other lower anchor. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 10 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 10 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 11 Review section 6-B, 6-C, 6-D, 6-E and 10 of this manual AND your vehicle owner’s manual. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 11 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 11 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 12 If your fingers slide off the harness straps without pinching the straps, it is tight enough. Review section 5. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 12 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 12 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 13 If your fingers slide off the harness straps without pinching the straps, it is tight enough. Review section 5. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 13 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 13 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 14 Position Shoulder Belt Shoulder belt lies across shoulder between neck and edge of shoulder. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 14 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 14 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 15 Chest Clip Even With Armpits (D) Review section 5 Cannot Pinch Harness Straps at the Shoulder (E) Review section 5 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 15 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 15 8/28/20 3:50 PM 8/28/20 3:50 PM...

  • Page 16: Forward-Facing

    Chest Clip Even With Armpits (D) Review section 5 Cannot Pinch Harness Straps at the Shoulder (E) Review section 5 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 16 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 16 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 17 Review section 6 Shoulder Belt Lies On the Shoulder, Between the Neck and Edge of Shoulders Review section 6 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 17 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 17 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 18 Even if this car seat seems easy to figure out on your own, you must follow the detailed instructions in this instruction manual to ensure the steps below are performed correctly. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 18 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 18 8/28/20 3:50 PM...
  • Page 19 Over 65 lb (30 kg) MUST be in booster mode.* *Check your local and state laws and the AAP/NHTSA recommendations. See page 25 for more information. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 19 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 19 8/28/20 3:50 PM...
  • Page 20 For recall information, call the U.S. Government’s Vehicle Safety Hotline at 1-888-327-4236 (TTY: 1–800–424–9153), or go to http://www.NHTSA.gov. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 20 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 20 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 21 For additional resources or to get your car seat checked by a child passenger safety technician, please visit the following web sites: www.nhtsa.gov • www.seatcheck.org • www.safekids.org NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 21 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 21 8/28/20 3:50 PM...
  • Page 22 STOP using this car seat and throw it away 10 years after the date of manufacture. Look for this sticker on back of the car seat. Graco Children’s Products Inc. advises against loaning or passing along a car seat unless you know the complete history of the product. We also advise against purchasing a car seat second hand.
  • Page 23 Car seat parts can get very hot in the sun or warm weather. To avoid burns, always check before putting child in car seat. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 23 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 23...
  • Page 24 If an air bag inflates, it can hit the child and car seat with great force and cause serious injury or death to your child. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 24 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 24...
  • Page 25 AAP and NHTSA recommendations, for car seat usage.* *Graco Supports the American Academy of Pediatrics and National Highway Traffic Safety Administration’s Car Seat Guidelines. Visit www.gracobaby.com/en-US/safety for information on car seat usage recommendations.
  • Page 26 DO NOT use car seat if it is damaged or missing parts. DO NOT use accessories or parts other than those provided by Graco. Their use could alter the performance of the car seat. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 26 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 26...
  • Page 27 Do not use both the vehicle seat belt and lower anchor attachment at the same time when using the car seat with the 5-point harness. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 27 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 27 8/28/20 3:50 PM...
  • Page 28 2-A Car Seat Features NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 28 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 28 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 29 S Harness Storage Q Crotch Buckle Compartment R Buckle Strap T Belt Lock-Off (under seat back pad) U Backrest Locks NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 29 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 29 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 30 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 30 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 30 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 31 G Anti-Rebound Bar Release Button H Rear-Facing Belt Path I Booster Lap Belt Path J Recline Position Indicator K Lower Anchor Strap NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 31 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 31 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 32 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 32 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 32 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 33 D Forward-Facing Lower Anchor Connector Storage E Recline Handle F Instruction Manual Storage G Shoulder Belt Positioning Clip NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 33 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 33 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 34 Premier 4Ever ® ® ground. DLX Extend2Fit featuring Anti- ® Rebound Bar seat product page to view installation videos. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 34 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 34 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 35 NEVER place this child restraint rear-facing in a vehicle seating location that has an active front air bag. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 35 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 35 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 36 Premier 4Ever ® ® DLX Extend2Fit featuring Anti- ® Rebound Bar seat product page to view installation videos. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 36 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 36 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 37 7. 5. Recline the Car Seat Place the car seat in 1st, 2nd, 3rd or 4th recline position. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 37 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 37 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 38 The base should sit as flat as possible on the vehicle seat. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 38 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 38 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 39 If needed, rolled towels may be placed under the car seat at the vehicle seat crease, until the ball is completely in the blue zone. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 39 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 39 8/28/20 3:50 PM...
  • Page 40 (28 cm) from the center of one lower anchor to the center of the other lower anchor. CLICK! NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 40 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 40 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 41 If the seat moves less than 1” (2.5 cm), it is tight enough. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 41 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 41 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 42 Readjust if needed. See section 5-A to secure your child. Recheck the level indicator with child in seat. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 42 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 42 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 43 Chest Clip Even With Armpits Review section 6 Cannot Pinch Harness Straps at the Shoulder Review section 6 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 43 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 43 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 44 Premier 4Ever ® ® DLX Extend2Fit featuring Anti- ® Rebound Bar seat product page to view installation videos. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 44 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 44 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 45 Vehicle Place rear-facing in vehicle seat. The base should sit as flat as possible on the vehicle seat. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 45 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 45 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 46 If needed, rolled towels may be placed under the car seat at the vehicle seat crease, until the ball is completely in the blue zone. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 46 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 46 8/28/20 3:50 PM...
  • Page 47 Slowly pull out on the belt and it should be locked. If not, review your car’s owner manual and section 10-D. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 47 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 47 8/28/20 3:50 PM...
  • Page 48 Readjust if needed. See section 5-A to secure your child. Recheck the level indicator with child in seat. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 48 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 48 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 49 Chest Clip Even With Armpits Review section 5 Cannot Pinch Harness Straps at the Shoulder Review section 5 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 49 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 49 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 50 DO NOT USE the Anti-Rebound Bar OR the Leg Extension Panel in the forward-facing mode. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 50 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 50 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 51 Premier 4Ever ® ® DLX Extend2Fit featuring Anti- ® Rebound Bar seat product page to view installation videos. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 51 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 51 8/28/20 3:50 PM 8/28/20 3:50 PM...

  • Page 52: With Latch

    Premier 4Ever ® ® DLX Extend2Fit featuring Anti- ® Rebound Bar seat product page to view installation videos. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 52 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 52 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 53 For children over 40 lb (18.1 kg), MUST use recline position 6 and must install with vehicle seat belt instead of LATCH. See section 4-C. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 53 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 53 8/28/20 3:50 PM...
  • Page 54 For easier installation, extend the lower anchor strap to its maximum length by pressing the grey button and pull out on the strap. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 54 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 54 8/28/20 3:50 PM...
  • Page 55 11 inches (28 cm) from the center of one lower anchor to the center of the other lower anchor. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 55 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 55 8/28/20 3:50 PM...
  • Page 56 If the seat moves less than 1” (2.5 cm), it is tight enough. See section 5-A to secure your child. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 56 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 56 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 57 Chest Clip Even With Armpits Review section 5 Cannot Pinch Harness Straps at the Shoulder Review section 5 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 57 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 57 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 58 Premier 4Ever ® ® DLX Extend2Fit featuring Anti- ® Rebound Bar seat product page to view installation videos. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 58 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 58 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 59 For children 40 lb or less (18 kg), MUST use recline position 5. For children over 40 lb (18.1 kg), MUST use recline position 6. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 59 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 59 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 60 A. Loosen the harness straps. B. Raise the headrest to the highest position. C. Unbuckle the chest clip. D. Unbuckle the buckle. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 60 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 60 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 61 Hold the upper (red) latch in position, then flip down the lower (gray) tab. Release the upper latch. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 61 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 61 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 62 Buckle the seat belt. The seat belt should lie as flat as possible and not be twisted. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 62 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 62 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 63 11A. Replace the Seat Pad Move the headrest back to its proper position for your child. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 63 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 63 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 64 Slowly pull out on the belt and it should be locked. If not, review your car’s owner manual and section 10-D. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 64 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 64 8/28/20 3:50 PM...
  • Page 65 Pull on the shoulder belt to tighten while feeding the slack back in the retractor. After step 9B, continue with step 12 on the next page. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 65 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 65 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 66 If the seat moves less than 1” (2.5 cm), it is tight enough. See section 5-A to secure your child. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 66 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 66 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 67 Chest Clip Even With Armpits Review section 5 Cannot Pinch Harness Straps at the Shoulder Review section 5 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 67 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 67 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 68 (B) Unbuckle the chest clip and the buckle. (C) Place harness straps off to the sides. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 68 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 68 8/28/20 3:50 PM 8/28/20 3:50 PM...

  • Page 69: Rear-Facing

    Remove the infant head and body Forward-Facing supports. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 69 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 69 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 70 6. Check the Buckle Position The correct slot the one that is closest to your child without being underneath your child. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 70 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 70 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 71 Buckle is in the Inner Most Position Unsnap seat pad and expose the top of seat. Locate the metal retainer. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 71 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 71 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 72 From the top of the car seat, pull the buckle out. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 72 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 72 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 73 Make sure the metal retainer is flush against the top of the plastic shell. Resnap the seat pad. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 73 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 73 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 74 (A), and in behind when in the outter-most position (B) and that it is flat and is not twisted. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 74 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 74 8/28/20 3:50 PM...
  • Page 75 Waist Pull up on the harness strap while pushing the chest clip down. Do this to both sides. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 75 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 75 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 76 It does not press on the child’s flesh or push the child’s body into an unnatural position. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 76 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 76 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 77 14. Raise the Chest Clip to Child’s Armpit Level 15. Check Tightness Again, Tighten More if Needed NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 77 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 77 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 78 DO NOT USE the Anti-Rebound child’s arm or back. Bar OR the Leg Extension Panel in the booster mode. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 78 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 78 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 79 8-12. Be sure to check your local and state laws, as well as AAP and NHTSA recommendations, for car seat usage. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 79 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 79 8/28/20 3:50 PM...
  • Page 80 See section 9 to remove the Anti-Rebound Bar. 3. Store The Harness System A. Loosen the shoulder straps as much as possible. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 80 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 80 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 81 Extend the extension panel, recline the car seat to position 1, then locate the metal retainer under the car seat shell. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 81 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 81 8/28/20 3:50 PM...
  • Page 82 From the top of the car seat, pull the buckle out. E. Unsnap Pad and Expose Seat Back Undo the 2 snaps in the headrest pad. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 82 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 82 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 83 F. Lift the headrest pad flap up out of the G. Unsnap Bottom Seat Pad Undo the 2 lower snaps. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 83 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 83 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 84 H. Pull Bottom Seat Pad Back To Expose the Plastic Shell I. Open the Harness Storage Door NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 84 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 84 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 85 Move the headrest back to its proper position for your child. Move the extension panel to position 1. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 85 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 85 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 86 Place forward-facing on a vehicle seat that has a lap/shoulder seat belt. The base should sit as flat as possible on the vehicle seat. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 86 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 86 8/28/20 3:50 PM...
  • Page 87 Graco allows the securing of the car seat with LATCH in the booster mode only if the vehicle manufacturer allows it. The child still MUST BE SECURED with the vehicle lap/shoulder seat belt. LATCH can be used in the booster mode regardless of the weight of the child up to 100 lb (45 kg).
  • Page 88 To move the lower anchor attachment, review section 7. 7. Unhook Tether Strap From Storage Location and Lay it in the Seat NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 88 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 88 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 89 (28 cm) from the center of one lower anchor to the center of the other lower anchor. 9. Remove The Slack From The Lower Anchor Strap NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 89 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 89 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 90 12. Thread the Vehicle Seat Shoulder Belt Through Seat Belt Guide on the Headrest See section 6-D to secure your child. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 90 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 90 8/28/20 3:50 PM...
  • Page 91 Unbuckle the chest clip and the buckle strap. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 91 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 91 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 92 To move the lower anchor attachment, review section 7. 5. Unsnap Bottom Seat Pad Unsnap seat pad and expose the bottom of seat base. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 92 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 92 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 93 7. Rotate Metal Retainer and Insert It Up Through the Shell and Pad From the top of the car seat, pull the buckle out. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 93 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 93 8/28/20 3:50 PM...
  • Page 94 9. Lift the Red Backrest Locks Up With the car seat in the 6th recline position, lift the red backrest locks up and slide together. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 94 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 94 8/28/20 3:50 PM...
  • Page 95 Push the seat back forward and lift out of base. To replace the seat back, reverse the steps. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 95 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 95 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 96 12.Store Splitter Plate Pull the harness adjustment strap all the way out and then store the splitter plate. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 96 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 96 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 97 The base should sit as flat as possible on the vehicle seat. See section 6-E to secure your child. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 97 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 97 8/28/20 3:50 PM...
  • Page 98 2. Thread Vehicle’s Shoulder Belt Into Seat Belt Guide in the Headrest NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 98 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 98 8/28/20 3:50 PM...
  • Page 99 The belt guides should be even with or just above the shoulders. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 99 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 99 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 100 Lap Belt Behind Armrest and Lies Low Across Hips and Thighs Shoulder Belt Lies On the Shoulder, Between the Neck and Edge of Shoulders NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 100 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 100 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 101 2. Ears Must Be Below the Top of the Vehicle Seat Back or Headrest NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 101 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 101 8/28/20 3:50 PM...
  • Page 102 You may need to use the belt positioning clip to help get a good fit. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 102 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 102 8/28/20 3:50 PM...
  • Page 103 Insert the loop end of the strap through the outer slot next to the harness adjustment strap as shown. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 103 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 103 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 104 4. Pull to Tighten Strap 5. Push Clip Through Slot In Pad 6. Attach Seat Pad to Base NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 104 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 104 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 105 Shorten Lengthen or shorten the belt length as shown. Clip should fit right at the top of shoulder as shown. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 105 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 105 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 106 Lap Belt Behind Armrest and Lies Low Across Hips and Thighs Shoulder Belt Lies On the Shoulder, Between the Neck and Edge of Shoulders NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 106 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 106 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 107 A. Loosen the harness straps. B. Raise the headrest to the highest position. C. Unbuckle the chest clip. D. Unbuckle the buckle. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 107 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 107 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 108 Rear-Facing: Slide Lower anchor strap along bar to the front of the seat. Forward-Facing: Slide the Lower anchor strap up along bar to the top. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 108 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 108 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 109 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 109 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 109 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 110 6. Replace Seat Pad 7. Move the Headrest to Its Proper Position for Your Child NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 110 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 110 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 111 To remove, undo the fastening strips and pull the straps out of the headrest. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 111 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 111 8/28/20 3:50 PM 8/28/20 3:50 PM...

  • Page 112: Anti-Rebound Bar

    DO NOT install with the Anti-Rebound Bar dipping downwards. •Do not carry the car seat by holding onto the Anti- Rebound Bar. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 112 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 112 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 113 Removing the Anti-Rebound Bar Push the buttons on both sides of the car seat at the same time to remove the Anti-Rebound Bar. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 113 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 113 8/28/20 3:50 PM...
  • Page 114 Press in on the hook’s spring. Push tether hook in, then lift up and pull away from tether anchor. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 114 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 114 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 115 • Set the air bag ON-OFF switch, if available, to the OFF position • Move the seat as far back as possible NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 115 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 115 8/28/20 3:50 PM...
  • Page 116 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 116 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 116 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 117 The male end of the seat belt with the silver tongue. Seat Bight The crease where the vehicle seat back and seat bottom meet. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 117 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 117 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 118 Lap Belt with Motorized get a secure fit. Read both your Mounted on Door Shoulder Belt vehicle and car seat manuals. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 118 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 118 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 119 Note: Most vehicles manufactured after 1996 will have Switchable retractors in the back seat. If you have any questions about your retractor type, consult your vehicle owner’s manual or call Graco for assistance. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 119 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 119...
  • Page 120 See Sliding Latch Plate and ELR Retractor. to switch the retractor. The lock-off locks the seat belt. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 120 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 120 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 121 1” (2.5 cm). Note: When using the lock-off, you do not need to switch the retractor. The lock-off locks the seat belt. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 121 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 121 8/28/20 3:50 PM...
  • Page 122 Grab the sides of the seat at the belt path and slide the seat side-to-side and front-to-back. The seat should not move more than 1” (2.5 cm). NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 122 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 122 8/28/20 3:50 PM...
  • Page 123 Note: When using the lock-off, you do not need to use the locking clip. The lock-off locks the seat belt. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 123 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 123 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 124 The seat should not move more than 1 “ (2.5 cm). NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 124 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 124 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 125 Machine wash pad in cold water on delicate cycle and drip-dry. DO NOT USE BLEACH. Reverse the steps to reattach the pad on the headrest. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 125 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 125 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 126 Machine wash pad in cold water on delicate cycle and drip-dry. DO NOT USE BLEACH. Reverse the steps to reattach the pad to the shell. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 126 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 126 8/28/20 3:50 PM...
  • Page 127 Machine wash pad in cold water on delicate cycle and drip-dry. DO NOT USE BLEACH. Reverse the steps to reattach the pad to the shell. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 127 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 127 8/28/20 3:50 PM...
  • Page 128 WARNING! Inspect and clean buckle from time to time to remove any objects or debris that could prevent latching. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 128 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 128 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 129 Use only mild soap and water to clean the extension panel. DO NOT USE BLEACH or other chemicals. Avoid spilling drinks on the extension panel. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 129 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 129 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 130 Use only mild soap and water to clean the Anti- Rebound Bar. DO NOT USE BLEACH or other chemicals. Avoid spilling drinks on the Anti-Rebound Bar. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 130 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 130 8/28/20 3:50 PM 8/28/20 3:50 PM...
  • Page 131 Notes NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 131 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 131 8/28/20 3:50 PM 8/28/20 3:50 PM...

  • Page 132: Replacement Parts

    1-800-345-4109 Store instruction manual in the slot with the instruction book icon as shown. NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 132 NWL0001153323A 4Ever DLX Extend2Fit USA ENG R07.indd 132 8/28/20 3:50 PM 8/28/20 3:50 PM...
