Firebox T40/T40-W Hardware Guide
WatchGuard® Firebox security appliances deliver unparalleled unified threat management, superior
performance, ease of use, and value for your small organization or branch office. Our security
subscriptions give you fully integrated protection from spyware, spam, viruses, worms, trojans, web-
based exploits, and blended threats. From firewall and VPN protection to secure remote access,
WatchGuard Firebox appliances support a broad range of network environments.
This guide introduces the Firebox T40 RoHS-compliant (lead-free) hardware product. The Firebox T40
network security appliance is designed for small organizations and branch offices.
Fireware OS
The Firebox T40 supports WatchGuard's next generation UTM OS—Fireware® OS. Each Firebox
appliance includes Fireware OS and delivers exceptional protection against today's sophisticated
threats to make sure that your business stays connected. For more information on the features of
Fireware OS, see
About Your Hardware
Hardware Specifications
Processor
Memory
Storage
Power Supply
Dimensions
Weight
Interface Specifications
Network Interfaces
Radio Type and
Frequency Band
(T40–W)
I/O Interfaces
https://www.watchguard.com/help/docs/help-center/en-US/Content/en-US/Hardware-Guides/firebox-t40-hardware-guide.html?cshid=10001
Fireware Help.
NXP LS1043A, 1.0GHz, 4-Core
DDR4 4GB
mSATA 16GB
Input Ratings: 100-240V AC, MAX 1.2A, 50-60Hz
Output: 54V DC
D = 205.5 mm (8")
W = 217 mm (8.5")
H = 43 mm (1.7")
T40: 0.88 kg (1.94 lbs)
T40–W: 0.9 kg (1.98 lbs)
5 RJ45 connectors, 1000Base-TX (10/100/1000Mbps)
Interface 4 supports PoE+ (Power over Ethernet), compliant with the
IEEE 802.3at standard
A single 3x3:3 radio that can operate on one of these bands:
2.4 GHz 802.11 b/g/n
5 GHz 802.11 a/n/ac
2x USB3.0, Type-A
1 RJ45 Serial Port
