Johnson Controls DMPR-KC204 Installation Bulletin

DMPR-KC204, DMPR-KC205, and DMPR-KC206 Jackshafts
K
it Includes
Table 1: Jackshaft Kit Components
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Note: Cut tubing as required.
Items 11 and 13 are available as kit DMPR-KC203.
Items 14 and 15 are available as kit DMPR-KC202.
© 1998 Johnson Controls, Inc.
Part No. 44-598-108, Rev. A
Figure 1: Jackshaft Kit Components
Description
Mounting Bracket with Bushing
3/4 inch Galvanized Tubing
Hose Clamp 3/4 inch I.D.
5/16-18 x 1-1/2 inch Bolt
Crank Arm
No. 5/16-18 Nut
Connection Link
Push Nut
Clevis Pin
Screw, 12-24 x 1/2 inch, Self-tapping
Drive Arm
Blade Arm
U-Bolt w/Nuts
Couplers
Rivets
No. 10-32 x 1-1/4 inch Hex-head Screw
No. 10-32 Hex Nut
Quantity Quantity
-204 -205
2 2
5 feet 5 feet
2 2
1 2
1 2
1 2
1 2
2 4
2 4
6 8
1 2
1 2
2 4
0 12
0 30
2 4
2 4
T
ools Required
•
drill, 3/16 inch (5 mm) drill bit and 1-1/4 inch hole saw
•
screwdriver, flat-blade, 5/16 inch or No. 12 nut driver
•
hammer
•
wrench, 5/16 and 7/16 inch
Installation Bulletin
