Johnson Controls PN-TP10L Installation Manual

Installation Manual for Protection Net
(for Left Side Installation of Outdoor Unit)
This protection net is to protect the outdoor unit heat exchanger from external damages such as being hit
by a ball. Install it following the directions below.
IMPORTANT NOTICE:
1. Applicable Unit
Name
Model
Required Qty.
Applicable Outdoor Unit
NOTE:
the product catalog before installation.
2. Installation Work
(1) Be sure to securely tighten the protection net with the supplied screws (accessories).
If the screws are not securely tightened, it may cause vibration or abnormal sound.
If they are over-tightened, the screw thread will be broken. When tightening the screws, make sure to
follow the tightening torque below.
(2) Apply touch-up coating at the screw holes of the outdoor unit in order to prevent rusting
(3) Secure enough service space with consideration for attaching/detaching the protection net.
(4) Do not step on the protection net or the outdoor unit in order to prevent falls resulting in injury.
check for accumulation and clean the protection net periodically.
(6) The protection net may freeze in cold weather.
(7) It is not possible to use the snow protection hood along with the left side inlet.
protection net.
: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
Protection Net (for Left Side Installation)
PN-TP10L
1
Top Flow Type
72,000 to 120,000 Btu/h
+0.7 ft +1.0 N m)
1
Model: PN-TP10L
