Backyard Discovery Barrington 2206052 Assembly Instructions Manual
  1. Manuals
  2. Brands
  3. Backyard Discovery Manuals
  4. Outdoor Furnishing
  5. Barrington 2206052
  6. Assembly instructions manual

Backyard Discovery Barrington 2206052 Assembly Instructions Manual

16x12 gazebo
Hide thumbs

Advertisement

Quick Links

Download this manual
Manufactured by:
Backyard Discovery
3305 Airport Drive, Pittsburg, KS 66762
800-856-4445
Basepoint Business Centre: Rivermead Drive,Westlea, Swindon SN5 7EX Phone: 0800-118-2476 J.P. Coenstraat 7, The Bridge, The Hague, 2595 WP, Netherlands
Phone: 08005678990
16x12 Barrington Gazebo
MODEL # : 2206052
Please visit www.backyarddiscovery.com
For the most up to date assembly manual, to register your product, or to order
replacement parts Para obtener instrucciones en español, visite
www.backyarddiscovery.com
EASY STEP-BY-STEP
3D INTERACTIVE INSTRUCTIONS
DOWNLOAD THE FREE APP
INSTALLATION
SERVICES
AVAILABLE!
See inside for details
See inside for details
INS-2206052-A-16x12 BARRINGTON GAZEBO ENG 6-13-2022
*
Made in China

Advertisement

loading
Need help?

Need help?

Do you have a question about the Barrington 2206052 and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Discovery Barrington 2206052

Summary of Contents for Backyard Discovery Barrington 2206052

  • Page 1 Manufactured by: Backyard Discovery 3305 Airport Drive, Pittsburg, KS 66762 800-856-4445 Basepoint Business Centre: Rivermead Drive,Westlea, Swindon SN5 7EX Phone: 0800-118-2476 J.P. Coenstraat 7, The Bridge, The Hague, 2595 WP, Netherlands Phone: 08005678990 16x12 Barrington Gazebo MODEL # : 2206052 Please visit www.backyarddiscovery.com...
  • Page 2 OWNER'S MANUAL - BASIC SETUP DIMENSIONS & ASSEMBLY NOTES It is critically important that you start with square and level footings, concrete pad or deck to attach your structure Pay close attention to the items needed for each step. Make sure you are using the correct hardware for each step. •...
  • Page 3 OWNER'S MANUAL - ANCHORING LAYOUT 14'-10 1/16" 4.5m 14'-4 1/16" 4.4m 13'-10 1/16" 4.2m METAL ANCHOR PLATES (4) ANCHORS PER POST 3 3/8" [86mm]...
  • Page 4 OWNER'S MANUAL - PARTS IDENTIFICATION Wood Components (Not to Scale) ROOF SUPPORT- W4L15194 1"x3 3/8"x54 1/8" (24x86x1374) ROOF JOIST- W4L15289 1"x3 3/8"x61 1/4" (24x86x1556) ROOF JOIST - W4L15288 ROOF SUPPORT - W4L15314 1"x3 3/8"x46 7/8" (24x86x1556) 1"x3 3/8"x38 13/16" (24x86x986) ROOF JOIST - W4L15203 ROOF JOIST - W4L15293 1"x3 3/8"x10 11/16"...
  • Page 5 OWNER'S MANUAL - PARTS IDENTIFICATION Wood Components (Not to Scale) PURLIN - W4L15302 1"x3 3/8"x68 1/2" (24x86x1740) PURLIN - W4L15303 1"x3 3/8"x54 1/8" (24x86x1374) PURLIN - W4L15304 1"x3 3/8"x75 1/16" (24x86x1906) PURLIN - W4L15306 PURLIN - W4L15305 1"x1 3/8"x29 1/8" (24x86x740) 1"x3 3/8"x49 9/16"...
  • Page 6 OWNER'S MANUAL - PARTS IDENTIFICATION Wood Components (Not to Scale) RAFTER- W4L15312 1 3/8"x3 3/8"x76 11/16" (36x86x1948) RAFTER- W4L15290 1 3/8"x3 3/8"x67 1/8" (36x86x1705) RAFTER- W4L15291 RAFTER- W4L15292 1 3/8"x3 3/8"x43 5/8" (36x86x1109) 1 3/8"x3 3/8"x20 3/16" (36x86x512) RAFTER - W4L15207 1 3/8"x3 3/8"x69"...
  • Page 7 OWNER'S MANUAL - PARTS IDENTIFICATION Wood Components (Not to Scale) CORBEL W/TAG- W2A03199 CORBEL- W2A03198 1 3/8"x6 7/16"x36 1/4 (36x163x921) 1 3/8"x6 7/16"x36 1/4 (36x163x921) COVER BOARD - W4L15313 1 "x5 1/4"x89 1/2" (24x134x2274) BEAM - W4L15284 BEAM- W4L15192 1 3/8"x5 1/4"x45 3/16" (36x134x1148) 1 3/8"x5 1/4"x89"...
  • Page 8 OWNER'S MANUAL - PARTS IDENTIFICATION Hardware Components H100792 LAG SCREW WH H100460 LAG SCREW BLK 1/4x3 H100171 BOLT WH BLK (13) WH BLK (18) 1/4x1 (34) 1/4x1 H100488 BOLT WH BLK (20) 1/4x2 H100471 LAG SCREW WH BLK (34) 5/16x1 1/2 T-NUT H100398 H100379...
  • Page 9 OWNER'S MANUAL - PARTS IDENTIFICATION Hardware Components H100385 SCREW PFH BLK 8x1 (184) H100536 H100759 SCREW PWH SCREW H100392 SCREW PWH H100200 SCREW PFH TAPPING BLK 8x1 1/4 (39) (62) BLK 8x3/4 (17) (26) BLK 8x1 1/2 1/4x1 H101030 SCREW CONFIRMAT BLK SCREW PFH H100382 H100833...
  • Page 10 OWNER'S MANUAL - PARTS IDENTIFICATION Accessory Components (Not to Scale) A4M01193 A4M01191 PANEL BRACKET PANEL BRACKET A4M01239 01238 PANEL BRACKET PANEL BRACKET ( 2) A4M01752 RAFTER CLIP (18) A4M01237 ROOF (12) SUPPORT SPLICE CLIP A4M01184 PANEL SUPPORT BRACKET A4M01236 STEEL POST A6P00308 STEEL POST PLATE A4M01235...
  • Page 11 OWNER'S MANUAL - PARTS IDENTIFICATION Accessory Components (Not to Scale) A4M01248 CORNER RIDGE CAP LONG A4M01258 RIDGE CAP SPLICE ASSEMBLY A4M01257 EDGE TRIM MEDIUM A4M01203 EDGE TRIM SHORT A4M01719 RIDGE CAP CHANNEL A4M01247 RIDGE CAP CHANNEL SHORT A4M01204 RIDGE PEAK CAP A4M01201 EDGE TRIM SPLICE A4M01205...
  • Page 12 OWNER'S MANUAL - PARTS IDENTIFICATION Accessory Components (Not to Scale) A4M01240 A4M01354-1 A4M01354-2 29 GA STEEL SHEETING 29 GA STEEL SHEETING 29 GA STEEL SHEETING A4M01355-1 A4M01356-1 A4M01355-2 29 GA STEEL SHEETING 29 GA STEEL 29 GA STEEL SHEETING SHEETING A4M01356-2 A4M01357-2 29 GA STEEL SHEETING...
  • Page 13 OWNER'S MANUAL - PARTS IDENTIFICATION Accessory Components (Not to Scale) A4M01358-2 A4M01358-1 29 GA STEEL SHEETING 29 GA STEEL SHEETING A4M01359-2 A4M01359-1 29 GA STEEL SHEETING 29 GA STEEL SHEETING 9205413 ELECTRICAL ENCLOSURE (x1)

  • Page 14: Hardware Parts

    PRE-ASSEMBLY STEP 1 - SORTING PARTS It is critical for ease of assembly that you take the time to sort and organize the wood and hardware. WOOD PARTS: • Organize wood parts by the three-digit, alpha-numeric number stamped on each board (ex. P01). •...
  • Page 15 PRE-ASSEMBLY STEP 2 - TOOLS REQUIRED Drill Attachments: Phillips Head Open End Wrenches 1/2" & 7/16" 1/8", 3/16", 3/8" & 7/16" Drill Bits Cordless Drill or Electric Drill 3/8" Drive Ratchet, 1/2" & 7/16" STD Sockets, 1/2" & 7/16" Deep Sockets Phillips Screw Driver 3/8 &...
  • Page 16 PRE-ASSEMBLY STEP 3 - CHOOSE YOUR ASSEMBLY METHOD There are several types of assembly instructions available to you. 1. Printed Assembly Manual included with your set 2. BILT APP - 3D interactive instructions 3. Combination of the Printed Manual and BILT APP (Note: Step numbers can differ between the two methods)
  • Page 17 STEP 1 - 12FT POST ASSEMBLY POST - W2A03202 6"x6"x89 1/2" (152x152x2274) A6P00308 POST - W2A03203 6x6 POST FOOT 6"x6"x89 1/2" (152x152x2274)
  • Page 18 STEP 2 - 12FT BEAM ASSEMBLY BEAM - W4L15240 BEAM - W4L15241 1 3/8"x5 1/4"x45 1/4" (36x134x1150) 1 3/8"x5 1/4"x67 13/16" (36x134x1723)
  • Page 19 STEP 3 - 12FT BEAM ASSEMBLY BEAM- W4L15192 1 3/8"x5 1/4"x45 3/16" (36x134x1148)
  • Page 20 STEP 4 - 12FT BEAM ASSEMBLY 12 FT BEAM ASSEMBLY FROM PREVIOUS STEPS...
  • Page 21 STEP 5 - 12FT BEAM ASSEMBLY 12FT BEAM ASSEMBLY FROM PREVIOUS STEPS...
  • Page 22 STEP 6 - 12FT BEAM ASSEMBLY CORBEL- W2A03198 1 3/8"x6 7/16"x36 1/4"(36x163x921)
  • Page 24 STEP 7 - 16FT BEAM ASSEMBLY BEAM - W4L15283 1 3/8"x5 1/4"x59 15/16" (36x134x1522) BEAM - W4L15284 1 3/8"x5 1/4"x59 1/16" (36x134x2261)
  • Page 25 STEP 8 - 16FT BEAM ASSEMBLY CORBEL- W2A03198 1 3/8"x6 7/16"x36 1/4" (36x163x921) CORBEL W/TAG- W2A03199 BEAM - W4L15282 1 3/8"x6 7/16"x36 1/4" (36x163x921) 1 3/8"x5 1/4"x89" (36x134x1500)
  • Page 26 STEP 9 - 16FT BEAM ASSEMBLY...
  • Page 27 STEP 10A - 16FT BEAM ASSEMBLY (x2) 12FT POST ASSEMBLY (x2) 16FT BEAM ASSEMBLY...
  • Page 28 STEP 10B - 16FT BEAM ASSEMBLY COVER BOARD - W4L15313 1"x5 1/4"x89 1/2" (24x134x2274)
  • Page 30 STEP 11...
  • Page 31 STEP 12 - ROOF SUPPORT ASSEMBLY A4M01234 POST CLIP...
  • Page 32 STEP 13 - ROOF SUPPORT ASSEMBLY ROOF SUPPORT- W4L15160 1"x3 3/8"x48 (24x86x1219) A4M01184 PANEL SUPPORT BRACKET...
  • Page 33 STEP 14 - ROOF SUPPORT ASSEMBLY ROOF SUPPORT- W4L15194 1"x3 3/8"x54 1/8" (24x86x1374) ROOF SUPPORT - W4L15314 A4M01237 ROOF SUPPORT SPLICE CLIP 1"x3 3/8"x38 13/16" (24x86x986)
  • Page 34 STEP 15 - ROOF SUPPORT ASSEMBLY...
  • Page 35 STEP 16 - ROOF SUPPORT ASSEMBLY A4M01205 METAL SPACER A4M01204 RIDGE PEAK CAP...

  • Page 36: Step 17 - Support Assembly

    STEP 17 - SUPPORT ASSEMBLY...
  • Page 37 STEP 18 - ROOF SUPPORT ASSEMBLY...
  • Page 38 STEP 19 - 16FT ROOF PANEL ASSEMBLY ROOF JOIST - W4L15288 A4M01193 A4M01191 PANEL BRACKET PANEL BRACKET 1"x3 3/8"x46 7/8" (24x86x580)
  • Page 39 STEP 20A - 16FT ROOF PANEL ASSEMBLY ROOF JOIST- W4L15297 1"x3 3/8"x61 1/4" (24x86x1556) ROOF JOIST- W4L15298 ROOF JOIST- W4L15289 1"x3 3/8"x44 1/2" (24x86x1130) 1"x3 3/8"x61 1/4" (24x86x1556) A4M01237 ROOF SUPPORT ROOF JOIST - W4L15293 SPLICE CLIP 1"x3 3/8"x44 1/2" (24x86x1130)
  • Page 40 STEP 20B - 16FT ROOF PANEL ASSEMBLY H09/H10 (x1) ROOF JOIST ASSY'S FROM PREVIOUS STEP H02/H05 (x1) ROOF JOIST ASSY'S FROM PREVIOUS STEP...
  • Page 41 STEP 21A - 16FT ROOF PANEL ASSEMBLY RAFTER- W4L15312 1 3/8"x3 3/8"x76 11/16" (36x86x1948) RAFTER- W4L15299 1 3/8"x3 3/8"x76 11/16" (36x86x1948)
  • Page 42 STEP 21B - 16FT ROOF PANEL ASSEMBLY RAFTER- W4L15292 RAFTER- W4L15296 1 3/8"x3 3/8"x20 3/16" (36x86x512) 1 3/8"x3 3/8"x20 3/16" (36x86x512) RAFTER - W4L15294 1 3/8"x3 3/8"x67 1/8" (36x86x1705) RAFTER- W4L15290 1 3/8"x3 3/8"x67 1/8" (36x86x1705) RAFTER- W4L15291 1 3/8"x3 3/8"x43 5/8" (36x86x1109) RAFTER - W4L15295 1 3/8"x3 3/8"x43 5/8"...
  • Page 43 STEP 22A - 16FT ROOF PANEL ASSEMBLY ROOF JOIST- W4L15300 1"x4 7/16"x63 13/16" (24x112x1605) ROOF JOIST- W4L1301 1"x4 7/16"x68 1/2" (24x112x1740)
  • Page 44 STEP 22B - 164FT ROOF PANEL ASSEMBLY...
  • Page 45 STEP 22C - 16FT ROOF PANEL ASSEMBLY...
  • Page 46 STEP 23A - 16FT ROOF PANEL ASSEMBLY PURLIN - W4L15227 1"x1 5/16"x51 1/2" (24x34x1308) PURLIN - W4L15305 PURLIN - W4L15306 PURLIN- W4L15307 1"x3 3/8"x49 9/16" (24x86x1259) 1"x1 3/8"x29 1/8" (24x86x740) 1"x3 3/8"x50 13/16" (24x86x1291) PURLIN- W4L15308 1"x3 3/8"x75 1/16" (24x86x1907)
  • Page 47 STEP 23B - 16FT ROOF PANEL ASSEMBLY PURLIN - W4L15303 1"x3 3/8"x54 1/8" (24x86x1374) PURLIN - W4L15304 1"x3 3/8"x75 1/16" (24x86x1906) PURLIN - W4L15302 1"x3 3/8"x68 1/2" (24x86x1740)
  • Page 48 STEP 24 - 16FT ROOF PANEL ASSEMBLY 29 GA STEEL A4M01359-1 A4M01356-1 29 GA STEEL A4M01240 A4M01354-1 29 GA STEEL SHEETING 29 GA STEEL SHEETING SHEETING SHEETING A4M01355-1 29 GA STEEL SHEETING A4M01357-1 A4M01358-1 29 GA STEEL SHEETING 29 GA STEEL SHEETING...
  • Page 49 STEP 25 - 16FT ROOF PANEL ASSEMBLY A4M01719 RIDGE CAP CHANNEL A4M01247 RIDGE CAP CHANNEL SHORT...
  • Page 50 STEP 26 - 16FT ROOF PANEL ASSEMBLY...
  • Page 52 STEP 27 - 12FT ROOF PANEL ASSEMBLY 01238 PANEL BRACKET A4M01239 PANEL BRACKET ROOF JOIST - W4L15203 1"x3 3/8"x10 11/16" (24x86x272)
  • Page 53 STEP 28 - 12FT ROOF PANEL ASSEMBLY ROOF JOIST- W4L15216 1"x3 3/8"x44 1/2" (24x86x1130) ROOF JOIST- W4L15220 1"x3 3/8"x44 1/2" (24x86x1130) ROOF JOIST - W4L15316 1"x3 3/8"x53 3/16" (24x86x1351) A4M01237 ROOF SUPPORT ROOF JOIST - W4L15315 SPLICE CLIP 1"x3 3/8"x53 3/16" (24x86x1351)
  • Page 54 STEP 29 - 12FT ROOF PANEL ASSEMBLY RAFTER - W4L15207 1 3/8"x3 3/8"x69" (36x86x1752) RAFTER- W4L15217 RAFTER - W4L15208 1 3/8"x3 3/8"x69" (36x86x1752) 1 3/8"x3 3/8"x45 7/16" (36x86x1155) RAFTER W4L15218 RAFTER- W4L15219 RAFTER- W4L15209 1 3/8"x3 3/8"x45 7/16" (36x86x1155) 1 3/8"x3 3/8"x21 15/16" (36x86x557) 1 3/8"x3 3/8"x21 15/16"...
  • Page 55 STEP 30A - 12FT ROOF PANEL ASSEMBLY ROOF JOIST- W4L15221 ROOF JOIST- W4L15204 1"x4 7/16"x80 1/2" (24x112x2044) 1"x4 7/16"x65 15/16" (24x112x1675)
  • Page 56 STEP 30B - 12FT ROOF PANEL ASSEMBLY...
  • Page 57 STEP 30C - 12FT ROOF PANEL ASSEMBLY...
  • Page 58 STEP 31 - 12FT ROOF PANEL ASSEMBLY PURLIN- W4L15239 PURLIN W4L15232 PURLIN- W4L15237 1"x1 5/16"x12 3/4" (24x34x324)) 1"x3 3/8"x27 1/4" (24x86x692) 1"x3 3/8"x56" (24x86x1422) PURLIN- W4L15228 PURLIN- W4L15229 PURLIN- W4L15231 1"x3 3/8"x58 5/16" (24x86x1481) 1"x3 3/8"x43 7/8" (24x86x1114) 1"x3 3/8"x51 7/16" (24x86x1307) PURLIN- W4L15230 1"x3 3/8"x75 11/16"...
  • Page 59 STEP 32 - 12FT ROOF PANEL ASSEMBLY A4M01356-2 29 GA STEEL SHEETING A4M01359-2 29 GA STEEL A4M01355-2 29 GA STEEL SHEETING 29 GA STEEL A4M01354-2 SHEETING SHEETING A4M01357-2 A4M01358-2 29 GA STEEL SHEETING 29 GA STEEL SHEETING...
  • Page 60 STEP 33 - 12FT ROOF PANEL ASSEMBLY A4M01719 RIDGE CAP CHANNEL A4M01247 RIDGE CAP CHANNEL SHORT...
  • Page 61 STEP 34 - 12FT ROOF PANEL ASSEMBLY...
  • Page 63 STEP 35A - 12FT ROOF PANEL ATTACHMENT...
  • Page 64 STEP 35B - 12FT ROOF PANEL ATTACHMENT...
  • Page 66 STEP 36A - 16FT ROOF PANEL ATTACHMENT...
  • Page 67 STEP 36B - 16FT ROOF PANEL ATTACHMENT...
  • Page 68 STEP 37A - 16FT ROOF PANEL ATTACHMENT...
  • Page 69 STEP 37B - 16FT ROOF PANEL ATTACHMENT...
  • Page 70 STEP 38 - ROOF PANEL ATTACHMENT...

  • Page 71: Step 39 - Roof Assembly

    STEP 39 - ROOF ASSEMBLY A4M01752 RAFTER CLIP (18)
  • Page 72 STEP 40 - ROOF ASSEMBLY A4M01185 CORNER BRACKET...
  • Page 73 STEP 41 - 12FT ROOF TRIM A4M01257 EDGE TRIM LONG A4M01202 A4M01201 EDGE TRIM CORNER A4M01203 EDGE TRIM SPLICE EDGE TRIM SHORT SPLICE...
  • Page 74 STEP 42 - 12FT ROOF TRIM A4M01257 EDGE TRIM LONG A4M01201 EDGE TRIM SPLICE...
  • Page 75 STEP 43 - ROOF ASSEMBLY A4M01248 CORNER RIDGE CAP LONG A4M01248 CORNER RIDGE CAP LONG...
  • Page 76 STEP 44 - ROOF ASSEMBLY A4M01258 RIDGE CAP SPLICE ASSEMBLY...
  • Page 77 STEP 45 - ROOF ASSEMBLY...
  • Page 78 STEP 46 - GAZEBO ASSEMBLY A4M01236 STEEL POST STEEL POST PLATE A4M01235 ANCHORING PLATE...
  • Page 79 STEP 47 - GAZEBO ASSEMBLY BYD ID TAG A100241 (SMALL) WITHOUT AGES...
  • Page 80 STEP 48 - GAZEBO ASSEMBLY...

  • Page 81: Electrical Enclosure

    PowerPort™ 9205413 ELECTRICAL ENCLOSURE (x1) FOR POWERPORT INSTALLATION REFER TO ASSEMBLY INSTRUCTIONS THAT COME PACKAGED WITH THE POWERPORT KIT. INSTALL ON ANY POST THAT IS DESIRED. FOLLOW DIRECTIONS FOR PROPER INSTALLATION.
