Summary of Contents for Draytek Vigor Router 11ax Series

  • Page 2 Vigor Router 11ax Series Quick Start Guide Version: 1. 0 Firmware Version: V4. 4. 2 (For future update, please visit DrayTek web site) Date: March 14, 2022...
  • Page 3 Intellectual Property Rights (IPR) Information Copyrights © All right s reserved. This publicat ion cont ains inf ormat ion t hat is prot ect ed by copyright . No part may be reproduced, t ransmit t ed, t ranscribed, st ored in a ret rieval syst em, or t ranslat ed int o any language wit hout writ t en permission f rom t he copyright holders.
  • Page 4 Declaration of Conformity Hereby, DrayTek Corporat ion declares t hat t he radio equipment t ype Vigor2135ax, Vigor2765ax, Vigor2766ax series rout er is in compliance wit h Direct ive 2014/ 53/ EU. The f ull t ext of t he EU declarat ion of conf ormit y is available at t he f ollowing int ernet address: ht t ps: / / www.
  • Page 5 Regulatory Information Federal Communicat ion Commission Int erf erence St at ement This equipment has been t est ed and f ound t o comply wit h t he limit s f or a Class digit al device, pursuant t o Part 15 of t he FCC Rules. These limit s are designed t o provide reasonable prot ect ion against harmf ul int erf erence in a resident ial inst allat ion.

  • Page 6: Table Of Contents

    1. Package Content ....................1 2. Panel Explanation....................2 2.1 Broadband Router - Vigor2135ax, Vigor2135Vax ..............2 2.2 35b Security Router - Vigor2765ax, Vigor2765Vax..............4 2.3 G.Fast Security Router - Vigor2766ax, Vigor2766Vax ............... 6 3. Hardware Installation ................... 8 3.1 Network Connection ........................8 3.2 Wall-Mounted Installation ......................

  • Page 7: Package Content

    Take a look at t he package cont ent . If t here is anyt hing missed or damaged, please cont act DrayTek or dealer immediat ely. Rout er Quick St art Guide RJ-45 Cable (Et hernet ) RJ-11 t o RJ-11 Cable (Annex A)

  • Page 8: Panel Explanation

    Vigor2135ax Vigor2135Vax Status Explanation Of f The syst em is not ready or is f ailed. Blinking The syst em is ready and can work normall y. Blinking wit h WLAN WPS is enabled and wait ing f or t he response f rom t he wireless client .
  • Page 9 Interface Description Wireless band will be swit ched / changed WLAN according t o t he but t on pressed and released. ON/ OFF For example,  2. 4G (On) and 5G (On) – in def ault .  2. 4G (Of f ) and 5G (On) – pressed and released t he but t on once.

  • Page 10: Security Router - Vigor2765Ax, Vigor2765Vax

    Vigor2765ax Vigor2765Vax Status Explanation Of f The syst em is not ready or is f ailed. Blinking The syst em is ready and can work normall y. Blinking wit h WLAN WPS is enabled and wait ing f or t he response f rom t he wireless client .
  • Page 11 Interface Description Wireless band will be swit ched / changed WLAN according t o t he but t on pressed and released. ON/ OFF For example,  2. 4G (On) and 5G (On) – in def ault .  2. 4G (Of f ) and 5G (On) – pressed and released t he but t on once.

  • Page 12: G.fast Security Router - Vigor2766Ax, Vigor2766Vax

    Vigor2766ax Vigor2766Vax Status Explanation Of f The syst em is not ready or is f ailed. Blinking The syst em is ready and can work normall y. Blinking wit h WLAN WPS is enabled and wait ing f or t he response f rom t he wireless client .
  • Page 13 Interface Description Wireless band will be swit ched / changed WLAN according t o t he but t on pressed and released. ON/ OFF For example,  2. 4G (On) and 5G (On) – in def ault .  2. 4G (Of f ) and 5G (On) – pressed and released t he but t on once.

  • Page 14: Hardware Installation

    This sect ion will guide you t o inst all t he rout er t hrough hardware connect ion and conf igure t he rout er’ s set t ings t hrough web browser. Bef ore st art ing t o conf igure t he rout er, you have t o connect your devices correct ly.

  • Page 15: Wall-Mounted Installation

    Vigor rout er has keyhole t ype mount ing slot s on t he underside. Drill t wo holes on t he wall. The dist ance bet ween t he holes shall be 100. 75mm. The recommended drill diamet er shall be 6. 5mm (1/ 4” ). Fit screws int o t he wall using t he appropriat e t ype of screw plug.

  • Page 16: Software Configuration

    To access Int ernet , pl ease f inish basic conf igurat ion af t er complet ing t he hardware inst allat ion. The Quick Start Wizard is designed f or you t o easily set up your rout er f or Int ernet access.
  • Page 17 Now, t he Main Screen will pop up. Click Wizards>>Quick Start Wizard . Note The home page will change slight ly in accordance wit h t he rout er you have. The f irst screen of Quick Start Wizard is ent ering login password. Af t er t yping t he password, please click Next .
  • Page 18 On t he next page as shown bel ow, please select t he WAN int erf ace t hat you use. If DSL int erf ace is used, please choose WAN1; if Et hernet int erf ace is used, please choose WAN2; if 3G USB modem is used, please choose WAN3. Then click Next f or next st ep.
  • Page 19 Af t er f inished t he above set t ings, simply click Next. Please manually ent er t he Username/ Password provided by your ISP. Then click Next f or viewing summary of such connect ion. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, t he syst em st at us of t his prot ocol will be shown.
  • Page 20 Choose WAN1 as WAN Int erf ace and click t he Next but t on; you will get t he f ollowing page. Please ent er t he IP address/ mask/ gat eway inf ormat ion originall y provided by your ISP. Then click Next f or viewing summary of such connect ion. Click Finish.

  • Page 21: Customer Service

    If t he rout er cannot work correct ly af t er t rying many ef f ort s, pl ease cont act your dealer/ DrayTek f or f urt her help right away. For any quest ions, pl ease f eel f ree t o send e-mail t o “...
