Summary of Contents for Memorex MVD1402
- Page 1 MVD1402 User’s Guide 14" COLOR TV WITH DVD PLAYER Before operating this product, please read these instructions completely.
-
Page 2: Table Of Contents
Connection to an External Unit ...12 • Connection Using the A/V Out Jacks ...12 • Connection Using the Coaxial Jack...13 About Discs ...14 Setting the TV Menus...16 • Video Setup Menu ...16 • Audio Setup Menu ...16 • Timer Setup Menu ...17 •... -
Page 3: Important Safety Instructions
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC WARNING: To assure continued compliance, follow the attached installation instructions and use only shielded cables when connecting to other devices. - Page 4 IMPORTANT SAFETY INSTRUCTIONS (CONTINUED) Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna.
- Page 5 17. OUTDOOR ANTENNA GROUNDING If an outside antenna is connected to the product, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electric Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge product, size of grounding conductors, location of antenna discharge product, connection to grounding electrodes and requirements for grounding electrodes.
-
Page 6: Notes On Handling
NOTES ON LOCATING THE DVD PLAYER: • When you place this player near another TV, radio or VCR, the playback picture may become poor and the sound may be distorted. In this case, move the player away from the TV, radio or VCR. -
Page 7: Location Of Controls
14. POWER Button 15. POWER Indicator REAR 1. COAXIAL Output Jack 2. COMPONENT IN Jacks (Y/CB/CR) 3. VIDEO Output Jack 4. VIDEO 2 IN Jack 5. Stereo AUDIO 2 Left/Right IN Jacks 6. AUDIO OUT Jacks 7. TV Antenna Jack... -
Page 8: Remote
REMOTE NOTE: When setting the TV Menus, the Channel +/- buttons are used as Navigation UP/DOWN and the Volume +/- buttons are used as Navigation Right/Left.. POWER Button SCAN Button RECALL Button Direct Channel Selection/Number (0-9) buttons Not Used Channel + Button Volume –... -
Page 9: Remote Control
BATTERY INSTALLATION Follow these precautions when using batteries in this device: 1. Use only the size and type of batteries specified. 2. Be sure to follow the correct polarity when installing the batteries as indicated next to the battery compartment. Reversed batteries may cause damage to the device. -
Page 10: Antenna Connections
Simply connect it to the “L (Mono)” Audio Input jack, but the sound will be monaural. How do I watch the external unit connected to the Audio/Video Input jacks? Press the TV/AV button so VIDEO1 appears on the screen, then start the external source. Are the cables included? No, the cables are sold separately, visit your local electronics store. -
Page 11: Cable (Catv)/Satellite Connections
Follow the connections shown below. With the switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the “A” position, tune your TV to the output of the converter/descrambler box (usually channel 3 or 4) and use the converter/descrambler box to tune scrambled channels. -
Page 12: Connection From An External Unit
1. Connect the cable, satellite or incoming antenna to the VHF/UHF IN jack on the rear of the external unit. 2. Connect a 75 ohm coaxial cable from the external unit’s 75 ohm OUT jack to the TV Antenna jack on the rear of the unit. -
Page 13: Connection Using The Component Y/P B /P R Jacks
3. Connect the external unit’s Component Video OUT jacks to this unit’s COMPONENT IN Jacks (Y/CB/CR). 4. Press the TV/AV button until DVD appears on the TV screen. NOTE: Connect the DVD player to this unit with the component in jacks for best results, otherwise use the Video 2 in jack. -
Page 14: Connection Using The Coaxial Jack
CONNECTION TO AN EXTERNAL UNIT (CONTINUED) CONNECTION USING THE COAXIAL JACK From Digital Out Coaxial Cable From Video Out 1. Front Left Speaker 2. This Unit 3. Center Speaker–can be located on top or below the Television. 4. Sub-woofer–can be located anywhere in the room. 5. -
Page 15: About Discs
ABOUT DISCS The region number for this DVD Player is: See the following page for information regarding region numbers. PLAYABLE DISCS: The following discs can be played back on this DVD player: DISC TYPES: Data on most DVDs is divided into sections called “titles” and then into subsections called “chapters”, each of which is given a title or chapter number. - Page 16 Region number of this DVD player, this DVD player cannot play that disc. You may not be able to play back some DVD video discs on this player if they were purchased from outside your geographic area or made for business purposes. When you try to play back an unauthorized disc, "Wrong Region" appears on the TV screen.
-
Page 17: Setting The Tv Menus
To exit the menus, press the EXIT button. Clock 01:13 Auto Program • Use the Volume Up/Down buttons to adjust the volume directly while in TV/AV/DVD mode. Time-On - - : - - Ch. Select Time-Off - - : - -... -
Page 18: Timer Setup Menu
Remind Time Clock Ch. Switch Time-On Ch. Select While in TV/AV mode, press the MENU button 1 once; the Time-Off Video menu will appear. Press the VOLUME Up 2 or Down Sleep Time 3 button to select the Timer setting. -
Page 19: Setting The On Timer
Time-On Ch. Switch Ch. Select Clock Time-Off Time-On While in TV/AV mode, press the MENU button 1 once; the Sleep Time Ch. Select Video menu will appear. Press the VOLUME Up 2 or Down Remind Time Time-Off 3 button to select the Timer setting. -
Page 20: Setting The Off Timer
Remind Time Ch. Select Ch. Switch Time-Off Sleep Time Timer While in TV/AV mode, press the MENU button 1 once; the Remind Time Clock Video menu will appear. Press the VOLUME Up 2 or Down Ch. Switch Time-On 3 button to select the Timer setting. -
Page 21: Setting The Remind Timer
When the actual time reaches matches the Remind time, it will switch to the channel which you set. This is useful for you if you won't miss the favorite TV program while you watching on another program at different TV channel. -
Page 22: Setup Menu
Setup setting. Press the CHANNEL Up 4 or Setup C. Caption Down 5 button until LANGUAGE is selected. Language Demo Mode Background Language SETTING THE BACKGROUND (TV/CATV MODE ONLY) Black Stretch Background Black Stretch Fade Setup C. Caption Fade Demo Mode C. - Page 23 Demo Mode Setup SETTING THE VNR (VIDEO NOISE REDUCTION) Language Background Setup Black Stretch Language Fade Background C. Caption Black Stretch Demo Mode Fade C. Caption Demo Mode Setup Press the MENU button 1 once; the Video menu will Language appear.
-
Page 24: Setting The Closed Captions
Setup setting. Press the CHANNEL Up 4 or Setup Fade Down 5 button until C. CAPTION is selected. C. Caption Language Demo Mode Background Black Stretch SETTING THE TV TO DEMO MODE Fade C. Caption Setup Demo Mode Demo Mode Language Background Black Stretch Fade C. -
Page 25: Channel Setup Menu
Fine Channel System Auto Auto Program Antenna Skip While in the TV mode, press the MENU button 1 once; the Current Ch. Channel Video menu will appear. Press the VOLUME Up 2 or Down 3 Fine button to select the Channel Setting. Press the CHANNEL Up... -
Page 26: Setting Channels Into Memory
Channel System Auto memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the unit’s memory. In Antenna addition to normal VHF/UHF channels, this unit can receive up to 125 Cable TV channels. Skip Current Ch. Fine... -
Page 27: Adding And Deleting Channels
Auto Program Channel System Auto Antenna Skip While in the TV mode, press the MENU button 1 once; the Current Ch. Video menu will appear. Press the VOLUME Up 2 or Down Fine 3 button to select the Channel Setting. -
Page 28: Calendar Setup Menu
CALENDAR SETUP MENU: 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 Calendar Solar 2005 6 Calendar Solar 2005 Press the MENU button 1 once; the Video menu will 12 13 14 15 16 17 18 appear. -
Page 29: Tv Parental Control
V-Chip enables parents to prevent their children from watching inappropriate material on TV. V-Chip reads the ratings for programming (except for news, sports, unedited movies on premium cable and Emergency System signals), then denies access to programming if the program’s rating meets the limitations you select. In this case, the program will be blocked. -
Page 30: Tv Rating Setup
Lock Menu Lock Menu Change Password Change Password Press the CHANNEL Up 1 or Down 2 button until TV RATING is selected, then the VOLUME Up 3 or Down 4 button to select it. FV D L S V B B B B... -
Page 31: Mpaa Rating Setup
TV-PG B B B B B TV PARENTAL CONTROL (CONTINUED) TV-Y > B TV-14 B B B B B TV-Y7 B B TV-MA B TV-G MPAA RATING SET-UP TV-PG B TV-14 B TV-MA B Parental Lock Parental Lock TV Rating... -
Page 32: Lock Menu
PG-13 TV PARENTAL CONTROL (CONTINUED) NC-17 LOCK MENU Parental Lock Parental Lock TV Rating MPAA Rating Lock Menu Lock Menu Change Password Enter the Parental Lock menu and turn on the V-chip option as described on page 28 (steps 1 and 2). -
Page 33: Dvd Setup Menus
TV DISPLAY 4:3/PS: Select when the unit is connected to an external conventional TV. Video material formatted in the Pan Scan style is played back in that style (the left and right edges are cut off). 4:3/LB: Select when the unit is connected to an external normal TV. -
Page 34: Parental
PARENTAL The Parental option enables parents to prevent their children from watching inappropriate material on a DVD. It reads the ratings for programming, then denies access to programming if the program’s rating meets the limitations you select. In this case, the user will have to enter a password. While in the DVD stop mode OR while in DVD mode and without a DVD inserted, press the SETUP button the Password Page will appear. -
Page 35: Basic Operation
DISPLAY While in the TV mode, press the Display button to show the current channel. If in an AV mode, the mode will appear when pressed. Press again to clear the display. TV/AV Press to select TV (CATV), VIDEO 1 (Front jacks), VIDEO 2 (Rear jacks) or DVD (Component). -
Page 36: Calendar
CALENDAR Press to access the Calendar setting menu (see page 27). VOLUME Buttons Set the sound as follows: Press the VOLUME Up 1/Down 2 buttons to adjust the sound level. BASIC OPERATION (CONTINUED) TIME Press to access the Time setting menu (see page 17). NOTE: This menu cannot be accessed while in the DVD mode. -
Page 37: Tv Basic Operation
FAQs: Why do I only receive 69 channels, when my cable goes much higher? The TV/CATV option must be set to CATV when using cable, see step 2 above. Why are some channels scrambled? You must subscribe to these channels through your cable company. -
Page 38: Scan
Press the SCAN button and the unit will automatically scan each station. When you see a channel you would like to view, press the SCAN button again. TV BASIC OPERATION (CONTINUED) RECALL Press the RECALL button to switch between the present... -
Page 39: Closed Captions
• Some cable systems and copy protection systems may interfere with the Closed Captioned signal. • If using an indoor antenna or if TV reception is very poor, the Closed Caption Decoder may not appear or may appear with strange characters or misspelled words. In this case, adjust the antenna for better reception or use an outdoor antenna. -
Page 40: Dvd Basic Operation
DVD BASIC OPERATION (GENERAL) When “ ” appears while pressing a button, this means that the corresponding function cannot be performed either on the disc inserted, or in the selected AUDIO MODE You can cycle between the audio modes as follows: For DVD, Press the AUDIO button repeatedly to cycle through the audio languages available on the playing DVD. -
Page 41: Playback Of A Dvd
DVD BASIC OPERATION (GENERAL) (CONTINUED) IMPORTANT NOTES: • “ ” will appear on the TV screen during operation if you try to access a function that is not available on the disc. • Some discs may take a few seconds to load. •... -
Page 42: Skip
SKIP Press the SKIP (n) button 1 to advance the DVD to the beginning of the next chapter. Press the SKIP (o ) button 2 to move the DVD to the beginning of the previous chapter. SLOW Use this feature to move the DVD in slow motion. During playback, press the SLOW button 1 to move the DVD forward in slow motion speeds of 1/2 ,1/4 , 1/8 , 1/16 (the sound will be muted) and resume normal playback. -
Page 43: Title/Chapter Search
Title will repeat continuously. While in the Playback mode, press the REPEAT button a third time; “ ALL” will appear on the TV screen and the complete disc will repeat continuously. Press the REPEAT button once more to cancel Repeat mode. -
Page 44: Audio Language
Use the Navigation (√,®,π,†) buttons 2 to move the image on the TV screen. Press the ZOOM button 1 once more to cancel the zoom function. This is not available on all discs. -
Page 45: Programmed Playback
To perform programmed playback, proceed as follows: Press the PROGRAM button, the Program menu will appear on the TV screen. Repeat step 2 until all desired chapters have been programmed. You can repeat a chapter more than once if desired. -
Page 46: Cd/Vcd Basic Operation
Press the OPEN/CLOSE button 1 to close the disc tray. “CLOSE” will appear on the screen. FOR CD: After loading, the TRACK menu will appear on the TV screen. Press the Navigation (π,†) buttons 2 to select the desired track. -
Page 47: Forward/Reverse
For CD: To play a song and then stop, select the track as described on the previous page, then press the REPEAT button 1 once; “Single” will appear on the TV screen and the unit will repeat the selected track once. -
Page 48: Programmed Playback(Vcd Only)
To perform programmed playback, proceed as follows: Press the PROGRAM button, the Program menu will appear on the TV screen. Repeat step 2 until all desired tracks have been programmed. You can repeat a track more than once if desired. -
Page 49: Picture Cd Basic Operation
Press the OPEN/CLOSE button 1 to close the disc tray. “CLOSE” will appear on the screen. After loading, the folder/picture menu will appear on the TV screen. Press the Navigation (π,†) button 2 to select the desired folder/photo. Press the PLAY/ENTER button 3 to confirm. -
Page 50: Troubleshooting Guide
Some features and functions are not available on all discs. The equipment is not connected properly. The INPUT of the TV is not set to receive the DVD signal output. The video cables (if using an external unit) are not securely connected. - Page 51 WWW.MEMOREXELECTRONICS.COM OR CONTACT CUSTOMER SERVICE AT PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1-800-321-6993.
-
Page 52: Care And Maintenance
Caring for Discs • Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the disc. • Do not attach adhesive tape, stickers, etc. to the disc label. •... -
Page 53: Specifications
Picture Tube ...14” Color Picture Tube Speaker Output Power...2 x 2W Signal System ...NTSC TV Tuner ...Support Mode: NTSC. Supports both TV (Air) and CATV (Cable TV) Operating Temperature ...+5° to +35°C Operating Humidity Range...5% to 90% (no condensation) Discs Played:... - Page 54 Memcorp, Inc. Weston, FL Printed in Hong Kong Visit our website at www.memorexelectronics.com...
