Memorex MVDT2002A Owner's Manual

Combination 20” flat color television and video cassette / dvd video player
Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNER'S MANUAL
COMBINATION 20" FLAT COLOR TELEVISION
AND VIDEO CASSETTE / DVD VIDEO PLAYER
MVDT2002A
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer
for the required programming code.
When shipped from the factory, the TV/CABLE menu option is set to the "CABLE" (Cable Television) mode.
If not using CABLE, set this menu option to the "TV" position.
Before operating the unit, please read this manual thoroughly.
5V40401A [En] Cover
ATTENTION
TV/CABLE MODE SELECTION
1
2/3/06, 5:58 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVDT2002A and is the answer not in the manual?

Questions and answers

Related Manuals for Memorex MVDT2002A

Summary of Contents for Memorex MVDT2002A

  • Page 1 OWNER’S MANUAL COMBINATION 20” FLAT COLOR TELEVISION AND VIDEO CASSETTE / DVD VIDEO PLAYER MVDT2002A If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code. When shipped from the factory, the TV/CABLE menu option is set to the “CABLE” (Cable Television) mode.
  • Page 2 NOTE: Please keep all packaging material for at least 90 days in case you need to return this product to your place of purchase or Memorex. WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3: Important Safeguards

    1. READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. 2. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. 3. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. 4.
  • Page 4 IMPORTANT SAFEGUARDS 13. LIGHTNING To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line surges.

  • Page 5: Power Source

    IMPORTANT SAFEGUARDS 25. LASER BEAM Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the laser beam. It may cause sight damage. 26. DISC Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

  • Page 6: Features

    Features Color TV with DVD/CD Player/Video Cassette Recorder • Color TV with DVD/CD player with Video Cassette Recorder - Unique space saving design combines a color TV, a DVD/CD player and a Hi-Fi Video cassette recorder. A DVD disc has much more capacity, but is the same size as an audio CD disc.

  • Page 7: Table Of Contents

    Before using your unit IMPORTANT SAFEGUARDS ... 3 Power source ... 5 Features ... 6 Contents ... 7 Parts and functions ... 8 Remote control ... 9 Antenna connections ... 11 Cable TV connections ... 12 Connections to other equipment ... 13 Setting the on screen display language ...

  • Page 8: Parts And Functions

    Parts and functions Front Cassette loading slot (Mono) Phones Video In L – Audio In – R Phones jack Video In jack Audio In (L/R) jacks Rew (Rewind) button (VCR) Stop/Eject button (VCR) Play button (VCR) F.Fwd button (VCR) Rec/Otr button (VCR) Channel ▲/▼...

  • Page 9: Remote Control

    5V40401A [En]06-11 Remote control POWER Power on/off TV/VCR Press to operate TV/VCR Press to operate DVD CH +/– Select channel Direct channel selection of TV Input setting Enter a password VOL +/– Adjust volume of TV MUTE Switch off the sound DISPLAY/CALL Display TV/VCR or DVD operation status JUMP...

  • Page 10: Inserting Batteries

    Remote control Inserting Batteries Open the battery compartment cover in the direction of the arrow. Battery precautions The precautions below should be followed when using batteries in this device: 1. Use only the size and type of batteries specified. 2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment. Reversed batteries may cause damage to the device.

  • Page 11: Antenna Connections

    If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service (CABLE), see page 12 for Cable TV connections. Combination VHF/UHF antenna (Single 75 ohm cable or 300 ohm twin-lead wire) RF IN jack 75 ohm...

  • Page 12: Cable Tv Connections

    Cable TV connections This unit has an extended tuning range and can tune most Cable TV channels without using a Cable TV Converter box. Some Cable TV companies offer “premium pay channels” in which the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

  • Page 13: Connections To Other Equipment

    The exact arrangement you use to interconnect various video and audio components to the unit is dependent on the model and features of each component. Check the Owner's Manual provided with each component for the location of video and audio inputs and outputs. Using an AV Amplifier with built-in digital surround If you are using an Amplifier with a built-in digital surround sound as follows, you can enjoy the various audio systems including Dolby Digital Surround audio that sounds just like the movie.
  • Page 14 Connections to other equipment Using the audio/video inputs If you connect the unit to camcorder or TV game, you can select by pressing INPUT SELECT. Press INPUT SELECT repeatedly to select the desired mode. “LINE” or TV channel will display on the screen for 4 seconds. TV Channel LINE (Front) NOTE:...

  • Page 15: Setting The On Screen Display Language

    Setting the on screen display language You can choose from three different languages (English, Spanish and French) for the on-screen displays. NOTE: If no buttons are pressed for more than 60 seconds, the MENU screen will return to normal TV-operation automatically. 5V40401A [En]12-17 Press POWER to turn on the unit.

  • Page 16: Auto Clock Setting

    Auto clock setting The Auto clock function will automati- cally set the built-in clock (Month, Day, Year and Time) when the unit is connected to an Antenna or Cable TV system and it is turned off. As the unit searches for a receivable station in your area and it receives a broadcast signal for Auto clock, the Auto clock needs several minutes to set itself.
  • Page 17 Auto clock setting NOTES: • When shipped from factory, “DAYLIGHT SAVING TIME” is set to “AUTO”. • When you want to set the Daylight Saving Time manually, on the first Sun- day in April you set to “ON”, and on the last Sunday in October you set to “OFF”.

  • Page 18: Manual Clock Setting

    Manual clock setting You must set the date and time manually for Timer Recordings, ON/ OFF Timer and Daylight Saving Time if the Auto clock process did not set them correctly. NOTE: After a power failure or disconnection of the power, the timer settings will be lost. In this case, reset the present time.

  • Page 19: Tv Operation

    NOTES: • If a channel with no broadcast is selected, the sound will automati- cally be muted. • If a station being viewed stops broadcasting, the unit will automati- cally shut itself off after 15 minutes. 5V40401A [En]18-21 To turn on the unit, press POWER. Adjust the volume level by pressing VOL + or –...

  • Page 20: Quick View

    TV operation NOTE: To listen through the headphones, insert the plug to your headphones (not supplied) equipped with a 1/8 inch mini plug into the PHONES jack on the front of the unit. The sound from the unit speaker is muted.

  • Page 21: Closed Caption

    What is closed captioning? This television has the capability to decode and display Closed Captioned television programs. Closed Captioning will display text on the screen for hearing impaired viewers or it will translate and display text in another language. NOTES: •...

  • Page 22: Memorizing Channels

    Memorizing channels This unit is equipped with a channel memory feature which allows channels to skip up or down to the next channel set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the unit’s memory. In addition to normal VHF and UHF channels, this unit can receive up to 113 Cable TV channels.
  • Page 23 Memorizing channels 5V40401A [En]22-25 Automatic memory tuning Press SETUP/TV MENU in the TV/VCR mode. The TV/VCR menu screen will appear. Press to select option. Press to select “AUTO CH MEMORY”. Press . The TV will begin memorizing all the channels available in your area.

  • Page 24: Setting The V-Chip

    Setting the V-Chip An age limitation can be set to restrict children from viewing or hearing violent scene or pictures that you may choose to exclude. The restriction applies to “TV RATING” and “MOVIE RATING” if this data is transmitted. You may set this restriction separately. To use the V-Chip function, you must register a password.
  • Page 25 Setting the V-Chip To use the TV after the TV is protected. When a program is received that is blocked by the V-Chip, enter the pass- word, then press ENTER. When the password is entered correctly the protection will be temporarily overridden. If the TV is turned off, or the channel is changed the V-Chip restriction will be reactivated.
  • Page 26 Setting the V-Chip 5V40401A [En]26-29 To change password Press SETUP/TV MENU in the TV/VCR mode. The TV/VCR menu screen will appear. Press to select option. Press to select the “PASSWORD”. Enter the Password using the Number buttons (0-9), then press ENTER.

  • Page 27: Setting The On Timer

    This feature allows you to program the unit to turn on at a predetermined time. If you program the ON TIMER to “DAILY” the TV will turn on everyday at the same time to the same channel. NOTES: • The unit will automatically turn off approximately 1 hour later after the ON TIMER turns on if no OFF TIMER has been set.

  • Page 28: Setting The Off Timer

    Setting the off timer This feature allows you to program the unit to turn off at a predetermined time. If you program the OFF TIMER to “DAILY” the TV will turn off at the same time everyday. NOTES: • If a station being viewed stops broad- casting, the unit will automatically shut itself off after 15 minutes.

  • Page 29: Picture Control Adjustment

    Picture controls are factory preset but you can adjust them individually as follows: NOTES: • The CONTRAST default setting is set to maximum at the factory. • The On-screen display will disap- pear 60 seconds after finishing an adjustment or by pressing SETUP/ TV MENU three times.

  • Page 30: Adjusting The Picture Preference

    Adjusting the picture preference You can select four picture modes— STANDARD, SPORTS, MOVIE, and MEMORY—as described in the following table: 5V40401A [En]30-35 Press SETUP/TV MENU in the TV/VCR mode. The TV/VCR menu screen will appear. Press to select option. Press to select “PICTURE PREFERENCE”, then press...

  • Page 31: Stereo Recording And Playback

    Stereo recording and playback / Second Audio Program (SAP) Stereo recording and playback The VHS Hi-Fi audio system permits high fidelity recording of MTS STEREO TV broadcasts. NOTES: • When playing back a tape that is not recorded in Hi-Fi stereo mode, the audio will automatically be monaural.

  • Page 32: Loading And Unloading A Cassette Tape

    Loading and Unloading a cassette tape Use only video cassette tapes marked Loading Push the center of the tape until it is automatically inserted. Automatic power ON When you insert a cassette tape the unit power will turn ON automatically. Automatic playback When loading a cassette tape without an erase prevention tab, playback will start automatically.

  • Page 33: Cassette Tape Playback

    NOTES: • This unit selects the playback tape speed SP, LP or SLP automatically. • If you play a prerecorded tape after the DVD playback, you must set the unit to TV/VCR mode using TV/VCR. • When you select the TV/VCR mode during DVD playback, DVD playback will change to the still mode, and after 5 minutes it will change to the stop...

  • Page 34: Special Playback

    Special playback Picture Search Reverse picture search function Press REW x 1 or x 2 during the playback. Forward picture search function Press F.FWD x 1 or x 2 during the playback. To return to playback: Press PLAY. SPEED SEARCH TIMES PICTURE SEARCH SPEED TAPE SPEED PRESS ONCE...

  • Page 35: Recording

    ZERO RETURN function / Video index search system NOTES for Counter Display: • If you rewind the tape beyond “00:00:00”, a minus sign (“–”) will be displayed in front of the time. • When you load a tape, the counter will reset to “00:00:00”.

  • Page 36: Recording A Tv Program

    Recording a TV program Recording and viewing the same TV program NOTES: • If power is switched off during record- ing, the TV and the DVD sections go off and the VCR continues to record. Press STOP to halt the recording and turn off the VCR.
  • Page 37 Recording a TV program Auto Rewind feature This VCR will automatically rewind the tape when the tape has ended (except during OTR and TIMER REC). It will also eject the tape. 5V40401A [En]36-39 To stop recording Press STOP to stop recording. “...

  • Page 38: One-Touch Timer Recording (Otr)

    One-touch Timer Recording (OTR) The One-touch Timer Recording feature provides a simple and convenient way to make a timed recording. NOTES: • If you wish to watch a DVD during a one-touch recording (OTR), press DVD to change to the DVD mode and perform the DVD playback.

  • Page 39: Timer Recording

    Timer recording can be programmed on-screen with the remote control. The built-in timer allows automatic unattended recording of up to 8 programs within 1 month. NOTES: • If the TIMER REC indicator blinks when the timer recording ended, the TV program has not been completely recorded because of an insufficient tape supply.
  • Page 40 Timer recording Timer recording special case Weekly (e.g. WKL-TUE: each Tuesday) or daily (e.g. MON-SAT: Monday to Saturday) Timer record- Follow the procedure of timer recording on the previous page. At picture 4 press the desired setting appears. Then press ENTER. When you press repeated, the indicator at DATE will change as follows, in this example the day is Friday.

  • Page 41: Duplicating A Video Tape

    Duplicating a video tape If you connect the unit to another VCR or camcorder, you can duplicate a previously recorded tape. Make all connections before turning on the power. Load a blank cassette tape with the erase prevention tab intact into the recording unit. Load a previously recorded tape into the playback VCR or CAMCORDER.

  • Page 42: Disc

    Disc This unit applies to DVD discs from Region 1 or ALL. The loaded Disc (DVD, Audio-CD and MP3-CD) will be recognized automatically. The suitable Disc-formats are: DVD, CD, CD-R/RW and DVD-R/RW (Video format only). Some CD-R/RW and DVD-R/RW discs may be incompatible. Do not play DVD-ROM, DVD-Audio, CDV, Video-CD, MP3/WMA/JPEG-CD or CD-G to prevent accidental erasure of prerecorded material.

  • Page 43: Preparation

    The following pages describe the setup/operation in DVD mode. NOTE: If the unit does not operate properly: Static electricity, etc., may affect the player's operation. Disconnect the AC power cord once, then connect it again. 5V40401A [En]42-46 Preparation / Status display of disc Preparation Before DVD/CD operation, please make preparations as follows.

  • Page 44: Playback Procedure

    Playback procedure NOTES: • If a non-compatible disc is loaded, “Incorrect Disc”, “Region Code Error” or “Parental Error” will appear on the TV screen according to the type of loaded disc. If these appear, check your disc again (see pages 42 and 55). •...

  • Page 45: Special Playback

    NOTE: There may be a slight delay between when you press the button and the function activating. NOTE: The unit is capable of holding a still video image or On screen display image on your television screen indefinitely. If you leave the still video image or On screen display image displayed on your TV for an extended period of time, you risk...

  • Page 46: Mp3 Playback

    MP3 playback This player can play back the MP3-data which has been recorded on CD-R or CD- RW. To produce the MP3-data, you need a Windows-PC with CD-ROM drive and a MP3-encoding Software (not supplied). The Apple-HFS-System cannot be played. MP3 CD information Limitations on MP3 CD playback •...

  • Page 47: Zooming

    NOTES: • You can select the Still Playback, Slow- motion Playback or Fast Forward (Review) Playback in the zoom mode. • Some discs may not respond to zoom feature. 5V40401A [En]47-54 Zooming / Locating desired scene Zooming This unit will allow you to zoom in on the frame image. You can then make selections by switching the position of the frame.

  • Page 48: Repeat Playback

    Repeat playback NOTES: • Some discs may not be compatible with the repeat operation. • In A-B Repeat mode, subtitles near the A or B locations may not be displayed. • You cannot set the A-B Repeat for the scenes that include multiple angles. •...

  • Page 49: Program Playback

    Program playback/Random playback (only CD) NOTES: • To cancel program play, select “Clear” at step 4 and press ENTER. • The program is cancelled when you open the disc tray or turn the power off. • Random playback cannot be combined with Repeat playback.

  • Page 50: Changing Soundtrack Language

    Changing soundtrack language / Subtitles NOTES: • If the desired language is not heard after pressing AUDIO SELECT several times, the language is not recorded on the disc. • Changing soundtrack language is cancelled when you open the disc tray. The initial default language or available language will be heard if the disc is played back again.

  • Page 51: Changing Angles

    Changing angles / Title selection / DVD menu NOTES: • Depending on the DVD, you may not be able to change the angles even if multi-angles are recorded on the DVD. • Depending on the DVD, you may not be able to select the title. Depending on the DVD, a “title menu”...

  • Page 52: Setting The Aspect Ratio Of Tv Screen

    Setting the aspect ratio of TV screen / Setting on screen display NOTE: It is not always possible for the DVD disc to display the picture as per your pre- ferred picture setting - for example, if you select “4:3 Panscan”, the disc may not offer this option.

  • Page 53: Setting The Picture Mode

    Setting the Picture mode/Screen saver function There are two types of source content in pictures recorded in DVD video discs: film content (pictures recorded from films at 24 frames per second) and video content (video signals recorded at 30 frames per second). Make this selection according to the type of content being viewed.

  • Page 54: Dynamic Range Control

    Dynamic Range Control DRC (Dynamic Range Control) ena- bles you to control the dynamic range so as to achieve a suitable sound for your equipment. NOTES: • This function works only during playback of Dolby Digital recorded discs. • The level of Dynamic Range Reduction may differ depending on DVD video disc.

  • Page 55: Parental Control Setting

    Some discs are specified as not suitable for children. Playback of such discs can be restricted with this unit. NOTES: • When each setup function (P.52~56, 58) has been completed, the unit can always be operated under the same conditions (especially with DVD discs).

  • Page 56: To Change The Parental Level

    To change the parental level NOTE: Do not forget the password. If you forget the password, contact the dealer that you purchased the unit from. 5V40401A [En]55-60 Press DVD to select DVD mode. Press SETUP/TV MENU in the stop mode or No Disc. Press to select option.

  • Page 57: Temporary Disabling Of Rating Level By Dvd Disc

    Temporary disabling of rating level by DVD disc Depending on the DVD disc, the disc may try to temporarily cancel the rating level that you have set. It is up to you to decide whether to cancel the rating level or not. NOTE: This temporary cancellation of the rating level will be kept until the disc is ejected.

  • Page 58: Setting The Language

    Setting the language You can select the language of the disc menu messages of DVDs. The same language can always be selected even if you replace the disc or turn the power off. NOTE: If the selected language is not recorded on the disc, the first priority Menu language is selected.

  • Page 59: Language Code List

    Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” (see page 58). Language Name Code Language Name Code Abkhazian 1112 Fiji Afar 1111 Finnish Afrikaans 1116 French Albanian 2927 Frisian Amharic 1123 Galician Arabic 1128 Georgian Armenian 1835 German Assamese...

  • Page 60: Problems And Troubleshooting

    Use the following check list for troubleshooting when you have problems with your unit. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POWER The AC power cord is not connected. No power.

  • Page 61: Video Head Cleaning

    Problems and troubleshooting (continued) / Video head cleaning SYMPTOMS The disc is dirty. The playback picture has It is in fast forward or fast reverse occasional distortion. playback. No disc is inserted. An unplayable disc is inserted. The disc is placed upside down. The unit does not start playback.

  • Page 62: Reception Disturbances

    Reception disturbances Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the unit is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.
  • Page 63 6/ 2 J5V4 4 1A SH Printed in Thailand 5V40401A [En]61-BACK 2/3/06, 6:00 PM...

  • Page 64: Specifications

    WWW.MEMOREXELECTRONICS.COM OR CONTACT CUSTOMER SERVICE AT (954) 660-7100. PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1-800-321-6993.
  • Page 65 Memcorp Inc. Weston, FL 33331 Printed in Thailand J5V40401A SH 06/02 Visit our website at www.memorexelectronics.com 5V40401A [En]61-BACK 6/2/06, 7:58 PM...
