SMC Networks IT Series Instruction Manual page 23

M E
Enter Range
M E
Enter *100 PPM
M E
Down 10 PPM
M E
Down USER
M E
Enter 100 PPM
M E
Enter Mode
M E
Enter %LEL
M E
Down Calib
M E
Enter Out: 4mA
M E
Enter 4mA
M E
Enter ACK
M E
Mode Calib
M E
Down CalibOut
M E
Enter Track
M E
Enter *Track
M E
Down Tbl Out
M E
Enter *T2.50mA
M E
Down Dig Input
M E
Enter Sprvsd
M E
Down Warm Min
M E
Enter Warm 1
M E
Enter Address
M E
Enter Addr:016
M E
Enter ACK
M E
Enter Address
M E
Down Baud
M E
Enter *38400
Range Adjustment Example
S.P. Function - Range Adjust
Select [E] to select or or
Press [E] if selecting 0-10 PPM range
Press [E] if selecting User adjustable range
Select [E] to select or or
4-20 mA Adjustment Example
S.P. Function - Output Units Adjust
Use or keys to select units of output as %LEL, %Vol, PPM, %F.S. or mA
Use or to select for 4 mA output, 20 mA output, 4 mA input or 20 mA
input
S.P. Function - 4-20 mA Calib Adjust
Use [E] to calibrate analog output, adjust output level with
then press [E] when done
Use or to select for 4 mA output, 20 mA output, 4 mA input or 20 mA
input
Selects 4 mA
Momentary Acknowledge of new Set Point
S.P. Function - Calib Adjust
S.P. Function - Output during Calibration Adjust
Use or keys to select Track, Zero, C1.50mA, C4.00mA or User mA
Track = Output during calibration tracks the calibration gas, Zero = Output is
Zero during calibration, C1.50mA = Output during calibration is 1.50 mA,
C4.00mA = Output during calibration is 4.0 mA
* = Current selection
S.P. Function - 4-20 mA Output during Trouble Adjust
Use or keys to select 2.50 mA or User select
S.P. Function - Digital Input Adjust
Use or keys to select Supervised or Unsupervised Digital Input
S.P. Function - Warm Up Time Adjust
Use or keys to select between 1 and 8 minutes warm up time
RS-485 Adjustment Example
S.P. Function - RS-485 Address Adjust
Use or keys to enter new address
New address selected
S.P. Function - RS-485 Address Adjust
S.P. Function - RS-485 Baud Rate Adjust
Press [E] to select or [ ] or [ ] to select another
Table 4-3B Set-Up Configuration
Page: 19
Model 5100-99-IT 4-20 mA Module
to select another and press [E]
to select another and press [E]
