SMC Networks IT Series Instruction Manual page 22

Key Function Display
--0%LEL-
M E
Mode ALMRSET:
M E
Mode CALIB:--
M E
Mode SETUP:---
M E
Enter Alarms
M E
Down Relays
M E
Down Relays
M E
Down 4-20mA
M E
Down Dig Input
M E
Enter H.Alarm
M E
Enter HASP:40-
M E
Down (x5) HASP:55-
M E
Enter ACK
H.Alarm
M E
Enter H. Relay
M E
Down L.Relay
M E
Enter Latch
M E
Down Sentry
M E
Down *Sentry
Description
Default Display
Mode Function - Alarm Reset
Mode Function - Calibrate
Mode Function - Set Point Adjustments
S.P. Function - Alarm Adjust
S.P. Function - Relays Adjust
S.P. Function - Range Adjust
S.P. Function - 4-20 mA Adjust
S.P. Function - RS-485/Sentry Output Adjust
High Alarm Set Point Adjustment Example
S.P. Function - High Alarm Adjust
High Alarm Set Point: current = 40
Use or keys to adjust to new set point
High Alarm Set Point: new = 55
Momentary Acknowledge of new Set Point
S.P. Function - High Alarm Adjust
Relays Set Point Adjustment Example
S.P. Function - High Alarm Relay Adjust
S.P. Function - Low Alarm Relay Adjust
Use or keys to adjust to new relay action (Latch,
Sentry, NonLatc) * indicates current
NOTE: Sentry indicates that Sentry controls relay action
and not the IT Sensor Module
Low Alarm Relay set to Sentry
Table 4-3A Set-Up Configuration
Page: 18
Model 5100-99-IT 4-20 mA Module
Reference
* A Below
* B Below
* Page 19
* Page 19
* Page 19
*A
*B
