Science for your protection
Instruction Manual
for the
Biogents Sentinel
An innovative trapping system
for mosquitoes & other
hematophagous insects
Biogents AG • Weißenburgstraße 22 • D-93055 Regensburg • Germany
tel: +49 - 941 - 5699 - 2167 • fax: +49 - 941 – 5699 - 2168 •
www.bg-sentinel.com • www.biogents.com
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biogents Sentinel
Summary of Contents for Biogents Sentinel
- Page 1 An innovative trapping system for mosquitoes & other hematophagous insects Biogents AG • Weißenburgstraße 22 • D-93055 Regensburg • Germany tel: +49 - 941 - 5699 - 2167 • fax: +49 - 941 – 5699 - 2168 • www.bg-sentinel.com • www.biogents.com...
- Page 2 • Increased numbers of the species mentioned above (attracted without CO Further developed versions of the Biogents Sentinel trap, called the Biogents Mosquitaire and Mosquitito, are specifically designed for private households. For more info on these traps please visit: www.biogents.com...
- Page 3 The BG-Sentinel is collapsible (diameter: 35 cm; height: 10 cm) and light (0.8 kg) making it easy to transport, carry, and store. • The BG-Sentinel can be easily assembled in as little as 5 minutes and does not require the use of any tools. •...
-
Page 4: User Information
For best results, the trap needs to be permanently operated. If switched off, the catch bag needs to be properly removed to prevent the caught mosquitoes from escaping. Parts List The BG-Sentinel basic version trap comes with the following contents. For additional accessories, please see our Product Catalog. Black intake funnel... - Page 5 Insert the three mounting poles (6) into the inner side of the trap by first placing the pole onto the metal ring in the ope- nings on the bottom of the trap [Fig. A] and then slightly bending it to place the top of the pole under the metal ring that encompasses the top of the trap.
-
Page 6: Positioning Of The Trap
Power Supply and Electricity The suction fan requires a power source of 9 to 12 V DC (max. 280 mA). An optional power supply unit (EU Version 220V input, 12V output) with fitting plug connection is available. There are also extension cords, battery mounting support cables, and extra plug connections available. - Page 7 Keep the traps out of strong wind. Strong winds not only deter the mosquitoes but can also affect the suction from the ventilator decreasing the catch rate. The BG-Sentinel is very stable and durable but also lightweight. To keep the trap from toppling over you can: Insert tent stakes into the holes in the side flaps.
- Page 8 Handling the Trap If for some reason you want to switch off the trap, first you need to remove and close the catch bag that is in use at the time. (See instructions below) This is because the funnel net only makes it difficult for mosquitoes to escape but not entirely impossible. Only a running fan ensures that the mosquitoes cannot escape from the catch bag.
-
Page 9: Maintenance
BG-Lure, which mimics the scent of human skin and releases a mixture of several compounds for up to five months. We also offer the Biogents Sweetscent attractant which is similar to the BG Lure, but only lasts 2 months, and is ideal for indoor use. - Page 10 Fi- gure U shows the Biogents specialized pressure reducing regulator. If you do not use the Biogents Eisenhans Carbonation Control System to regulate the flow and minimize the output of CO while optimizing its release, then the CO flow re- strictor is needed to minimze the flow of CO from the preferred source.
- Page 11 Aedes aegypti and the tiger mosquito Aedes albopictus , even without the addition of CO The following two graphs depict the performance of the BG-Sentinel (without CO with monitoring Aedes aegypti and Aedes albopictus mosquito species in Brazil and the United States, respectively.
-
Page 12: Troubleshooting
24 hours a day, 7 days a week for as long as possible. Furthermore, the BG-Sentinel should be kept running even if the mosquito popu- lation has decreased to ensure that newly hatched mosquitoes (e.g. after heavy rainfall) or migrating mosquitoes can still be captured. -
Page 13: Safety Precautions
Always follow the manu- facturer / supplier guidelines for the source you have chosen. If any further problems occur or you have any further questions, please contact us Biogents AG Weissenburgstr. 22 D-93055 Regensburg Germany www.bg-sentinel.com...
