- Page 1 User Manual: PC-IA500 Industrial Switch Version 5.2019...
- Page 2 Introduction This hardened designed industrial 5 port 10/100M Ethernet Switch is equipped with wide range VDC power input. It is suitable for heavy usage areas such as hazardous environments or central control place where a reliable device is critical. It is an ideal solution for Industrial Automation, IP surveillance, traffic monitoring and a wide range of applications.
- Page 3 Power connecting procedure: STEP 1 Take out 4 pin terminal block located in the included mounting kit package. STEP 2 Connect power wires to +V1- or +V2- with corresponding polarity. Connect the grounding wire to the ground screw. STEP 3 Plug into terminal block socket shown above.
- Page 4 LED indicator Page 4/7...
- Page 5 Specifications IEEE 802.3 10Base-T Ethernet IEEE Standards IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3x Flow Control and Back Pressure Switch Architecture Back-plane (Switching Fabric): 1Gbps Data Processing Store and Forward Flow Control IEEE 802.3x Flow Control and Back Pressure MAC address Table Size Packet Buffer Size 448k 5xRJ-45 10/100/1000BaseT(X) auto negotiation,...
- Page 6 Certifications Safety LVD(EN60950-1) CE, FCC, EN 55032/24 CISPR 32, FCC Part 15B Class A IEC 61000-4-2 ESD: Contact: 6KV; Air: 8KV IEC 61000-4-4 EFT: Power: 2KV; Signal: 2KV IEC 61000-4-5 Surge: Power: 2KV; Signal: 2KV Vibration EN 60068-2-6 Page 6/7...
- Page 7 Housing Dimension (mm) Page 7/7...
