- Page 1 User Manual: PC-PIGE500-GBTE Industrial Switch with PoE+ Version 12.2020...
-
Page 2: Installation Package
Introduction This switch is rated compact size IP30 and installation by DIN RailTthis industrial gigabit unmanaged Ethernet switch has 5*10/100/1000Tx with 4*IEEE 802.3at compliant ports (30W/port), suitable for applications that require high bandwidth communication. In order to prevent unregulated voltage, this series provides high EFT and ESD protection. This also allows it to function in harsh environments, as well as support power redundancy with a dual power input design with reverse polarity protection. -
Page 3: Power Connection
Power connection If the DC voltage is supplied by an external circuit, please use a protection device on the power supply input. Supply by UL Listed industrial use power. The industrial Ethernet switch’s hardware specs, ports, cabling information, and wiring installation will be described within this user manual This unit comes with a 6 pin terminal block. -
Page 4: Led Indicator
LED indicator There are LED light indicators located on the front panel of the industrial Ethernet switch that display the power status and network status. Each LED indicator has a different color and has its own specific meaning, see below. Color Description Power input 1 or 2 is active... -
Page 5: Din Rail Mounting
DIN Rail mounting The DIN-Rail is pre-installed on the industrial Ethernet switch from the factory. If the DIN-Rail is not on the industrial Ethernet switch, please see the Figures below to learn how to install the DIN-Rail on the switch. Follow the steps below to learn how to hang the industrial Ethernet switch. -
Page 6: Wall Mounting
Wall mounting Follow the steps below to mount the industrial Ethernet switch using the wall mounting bracket. Step 1. Remove the DIN-Rail bracket from the industrial Ethernet switch by loosening the screws. Step 2. Place the wall mounting brackets on the top and bottom of the industrial Ethernet switch. Step 3. -
Page 7: Troubleshooting
Trouble shooting Verify you have the right power cord or adapter. Never use a power supply or adapter with a non- compliant DC output voltage or it will burn the equipment. Select the proper UTP or STP cable in order to construct the network. Use an unshielded twisted-pair (UTP) or shield twisted-pair (STP) cable for RJ-45 connections: 100Ω... - Page 8 Housing Dimension (mm) 30mm (W) x 95mm (H) x 75mm (D Page 8/8...
