- Page 1 Mobile Data Terminal Technical Manual Installation and Programming ver.1.18 hardware v.2 23/05/2021...
-
Page 3: Table Of Contents
Connectors and Cables ................................18 Ports Mapping ..................................20 Mechanical Movement Sensor ............................21 User and Demo Software ...............................22 Note ......................................29 The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 4: Introduction
(Autotest, Sta! s! cal Memory, “Trip by Trip” buff er and the Tariff programming). The third sec! ons contains the descrip! on of all the tariff programming parameters. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 5: Appearance
Serial COM Micro SD Slot Sim Card 2 Holder Test Connector Host USB Port Lan Ethernet The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. - Page 6 The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
- Page 7 The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
-
Page 8: How To Seal The Mdt
USB Seal Tariff Cover Seal SD Sealing Cover MDT Head Seal SIM CARDs Cover Seal The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 9: Measures
Right Side View Left Side View Dimensions (in millimeters) Width Height Depth Weight (in grams) X-One The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 10: Electrical Connection Table
2 A ENGINE +12 V BROWN fuse 2 A WHITE/VIOLET CAR LIGHT SWITCH Panic Bu on The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 11: Electrical Specifi Cations
RS-232 serial ports: COM1, COM2 Android COM5, COM6, COM7 (optional COM8, COM10, COM11, COM12) Panic Button The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 12: Blocking Wires
Blocking Wires Place the connector’s wires as indicated in the following images. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. - Page 13 Cut the rubber cover and place both in the back cover. Close the back connectors cover fi xing the screws. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
-
Page 14: Dashboard Fitting
Remove the protective fi lm from the glue pad on the board. base of the bracket. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. - Page 15 Adjust the bracket so the mdt screen is in the best provided. position for the driver. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
-
Page 16: Windscreen Fitting
Firmly press the bracket onto the glass to obtain the Using the screws provided fi x the MDT to the best adhesion possible. bracket. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 17: Combo Antenna Installation
22mm nut. Tape up the antenna connection. Tape up the antenna cables each 40-50 cm. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 18: Connectors And Cables
PANIC BUTTON Ac" ve Low WHITE VIOLET BLACK ENGINE Ac" ve High BLUE BLACK +8/32V +8/32V +8/32V +8/32V The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. - Page 19 USB 4 - P USB 3 - P USB 4 - GND USB 3 - GND The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
-
Page 20: Ports Mapping
Generic Analog Input 1, 10 bits ADC ANALOG INPUT 2 Generic Analog Input 2, 10 bits ADC The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 21: Mechanical Movement Sensor
Fix the sensor’s cap to end the sensor’s assembling opera" on and to have the sensor fully opera" ve The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. -
Page 22: User And Demo Software
Development Kit provided with the X-One, and the source code of those applica• ons is available as example for the developers. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited. - Page 23 fi le in the “\Hard Disk\SysApps\BOX” folder of the target X-One device, and restart it. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
- Page 24 Shutdown sequence can be started by AITP (power bu# on, engine…) or by the user applica• on, sending the AITP shutdown or restart with the AITP DLL. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
- Page 25 , than is possible to setup the AITP to turn it on, eventually in Stealth mode. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
- Page 26 • on. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
- Page 27 Application to read and write Com Tax 2 Message from/to internal AITP device. GPIO Test Application to control hardware internal GPIO pins. The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
- Page 28 Application to update AITP software setting. SERIAL CONSOLE Simply ASCII Termina that debugging testing perpherals connected via serial ports The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third party is strictly prohibited.
-
Page 29: Note
