MODEL NO.: MI-31662
FEATURES
•Cast-iron breaker system .
•Large control knob of variable speed feed system to increase
or decrease speed when the planer is in operation.
•Metric and SAE graduation scale to indicate workpiece
thickness on the front of the machine.
•The anti-kickback finger system at the front of the machine
eliminates any risk of stock being forcibly ejected.
•A dust chute with its 6" outlet to receive a dust collector.
•Magnetic control with overload protection.
OPERATING MANUAL
SPECIFICATIONS
•TABLE SIZES
•MAXIMUM PLANING WIDTH
•MAXIMUM PLANING THICKNESS
•MINIMUM PLANING THICKNESS
•MINIMUM PLANING LENGTH
•MAXIMUM PLANING DEPTH
•CUTTERHEAD DIAMETER
•KNIVES
•CUTTERHEAD SPEED
•FEEDING SPEED (VARIABLE) 20 TO 38 FPM (6 TO 11.6M/MIN)
•CUTS PER INCHE (25.4mm)
•MOTOR
•WEIGHT
25-1/4"x 28" (660x711 mm)
24" (610mm)
8" (203mm)
3/16"(4.75mm)
8" (203mm)
5/16 " (8mm)
3-1/8" (80mm)
3/HELICAL
4800RPM
62.5/20 FPM TO 33/38 FPM / －
10HP/208V/3PH
1100 LBS (500kg)

Advertisement

loading
Need help?

Need help?

Do you have a question about the MI-31662 and is the answer not in the manual?

Questions and answers

Related Manuals for Magnum Industrial MI-31662

Summary of Contents for Magnum Industrial MI-31662

  • Page 1 MODEL NO.: MI-31662 SPECIFICATIONS FEATURES •TABLE SIZES 25-1/4”x 28" (660x711 mm) •Cast-iron breaker system . •MAXIMUM PLANING WIDTH 24" (610mm) •Large control knob of variable speed feed system to increase •MAXIMUM PLANING THICKNESS 8" (203mm) or decrease speed when the planer is in operation.

  • Page 2: Safety Rules

    SAFETY RULES READ CAREFULLY BEFORE OPERATING THE MACHINE Learn the machine’s applica�ons and limita�on- 13. Be sure planer blades are seriously locked in s, as well as the specific poten�al hazards the machine. par�cular to this machine. Follow available safety instruc�ons and safety rules carefully. 14.

  • Page 3: Unpacking And Cleanup

    24” INDSUTRIAL PLANER VARIABLE FEED SPEED KMS-TOOLS EQUIPMENT industrial planers are carefully tested and inspected before shipment and if properly used will give perfect result. However, a reasonable amount of care and attention is necessary to ensure perfect performance and accurate work. It is imperative that you take a few moments to familiar yourself with these instructions, as they will no doubt save you a lot of time and trouble.

  • Page 4: Installation

    FIG.3 INSTALLATION 1. Remove the fastening bolts from the machine to the shipping skid. 2. Two lifting lugs are built into the machine, one of which is illustrated in (Fig.3, A). These lugs can be used to mechanically lift the machine using a forklift and lifting straps.
  • Page 5 ASSEMBLING DUST HOOD A dust hood with a 5” opening is supplied with your machine and is to be used when connecting the planer to a dust collector or a central dust collection system. Position dust hood (A) Fig.8, against the rear of the machine and on the top of cutterhead guard (B). Align the holes and fasten the dust hood (A) Fig.9, to the cutterhead guard (B) using eight 6mm-button head screws (C) as illustrated in Fig.9.

  • Page 6: Changing Voltage

    CHANGING VOLTAGE If you must reconnect for 220 or 440-volt operation, please contact or have a certified electrician connect the machine to the power source. FIG.13 GROUNDING Machine must be properly grounded in order to avoid electric shock to the work operator. The use of an extension cord is not recommended. If necessary use a three-prong extension cord and outlet (immediately replace the extension cord if worn out, cut or damage).
  • Page 7 FIG.16 TABLE ROLLERS (Fig.16) The planer is equipped with two-table rollers (A); which aid infeeding the stock. This will reduce friction between the stock and the table and will rotate as the stock is fed through the planer. 1. To raise the table rollers, loosen locking level (B) as illustrated in Fig.16 and pull control lever (C) upward to the required height setting.
  • Page 8 FIG. 21 7. If an adjustment to the outfeed table roller is necessary loosen lock-nut (G) Fig.21, located under the table below the outfeed table roller (F). Rotate the adjustment nuts (H) as required; in order to raise or lower the height of the outfeed roller. NOTE: It will be necessary to raise the table in order to gain access to the adjustment nuts.
  • Page 9 FIG. 25 4. If an adjustment to one or all three knives is necessary, slightly loosen the 10 locking screws, 10 of which are shown in Fig.25 & Fig.26 (F) loosen just enough to relieve stress in the cutterhead (B) and do not disturb the knife setting.
  • Page 10 ADJUSTING CHIPBREAKERS FIG. 28 The chipbreakers (A) Fig.28 are located on the top of the planer and extend downward around the front of the cutterhead. The chipbreakers will rise as stock is fed through the planer and “breaks or cuds” the wood chips.
  • Page 11 FIG. 32 FIG. 33 ADJUSTING OUTFEED ROLLER The outfeed roller continues to feed the stock out of the machine after the planning operation is completed and should be set at .030” below the FIG. 34 cutting circle. To check and adjust the setting of the outfeed roller, proceed with the following: 1.
  • Page 12 3. Place the gauge block (A) Fig.37 on the table, directly under the FIG. 37 cutterhead (B). Use a .040” feeler gauge (C) and place on top of the gauge block (A), raise the table until the cutterhead knife slightly touches the feeler gauge (A) when the knife is at its lowest point NOTE: Do not move the table any further until the adjustment is complete.

  • Page 13: Adjusting Table Gibs

    FIG. 42 ADJUSTING TABLE HEIGHT SCALE The table height scale indicates the distance the table is from the cutting circle (depth of cut). To verify and adjust the pointer, proceed with the following steps: 1. Run a piece of wood through the planer and stop the machine. 2.
  • Page 14 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-001 C003016 Column Base (L) MI-31662-002 C003017 Column Base (R) MI-31662-003 G002008 Elevating Screw MI-31662-004 S284008 Spring Washer ∮10.2x∮18.4x3.7x2.5T MI-31662-005 S137030 Hex. Head Screw M10-P1.5x30L MI-31662-006...
  • Page 15 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-026 G003013 Work Table MI-31662-027 C007001 Table Gib MI-31662-028 T013027 Table Roller Assembly MI-31662-029 C020003 Datum Plank MI-31662-030 C051019 Collar MI-31662-031 S284007 Spring Washer ∮8.2x∮15.4x3.2x2.0T MI-31662-032 S136040 Hex.
  • Page 16 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-039-1 T001034 Cutterhead Assembbly MI-31662-039-2 P24GT002 Helical Cutterhead S284008 Spring Washer MI-31662-040 ∮10.2x∮18.4x3.7x2.5T S203030 Hex. Socket Screw M10-P1.5x30L MI-31662-041 C015029 Bracket(L) MI-31662-042 C015096 Bracket(R) MI-31662-043 C046073...
  • Page 17 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-067 G006011 Gear Box Assembly MI-31662-068 S282011 Washer ∮10.5x∮25x2T MI-31662-069 S284008 Spring Washer ∮10.2x∮18.4x3.7x2.5T MI-31662-070 S203030 Hex. Socket Head Screw M10-P1.5x30L MI-31662-071 T017006 Link Assembly MI-31662-072 S203025 Hex.
  • Page 18 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-084 T020038 Electric Wire Assembly MI-31662-085 C073079 Top Cover MI-31662-086 C061001 Bottom Knuckle MI-31662-087 S284007 Spring Washer ∮8.2x∮15.4x3.2x2.0T MI-31662-088 S202030 Hex. Socket Head Screw M8-P1.25x30L MI-31662-089...
  • Page 20 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-118 C015094 Plate MI-31662-119 T016008 Level Gear MI-31662-120 S284007 Spring Washer ∮8.2x∮15.4x3.2x2.0T MI-31662-121 S202025 Hex. Socket Head Screw M8-P1.25x25L MI-31662-122 T003003 Level Screw...
  • Page 21 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-123 C006054 Work Table MI-31662-124 C015018 Support MI-31662-125 S201016 Hex. Socket Head Screw M6-P1.0x16L MI-31662-126 C017013 Elevating Arm MI-31662-127 C046076 MI-31662-128 S267512V Spring Pin ∮5∮5.2x40L MI-31662-129...
  • Page 22 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-146 T014002 Reduce Gear Box Assembly MI-31662-147 T015008 Gear Pulley Assembly MI-31662-148 S284007 Spring Washer ∮8.2x∮15.4x3.2x2.0T MI-31662-149 S136025 Hex.Head Screw M8-P1.25x25L PARTS LIST FOR MI - 31662 NO.
  • Page 23 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-167 P24GP052 Helical Cutterhead MI-31662-168 C009054 Support(R) MI-31662-169 S026008ZZ Ball Bearing 6008ZZ ∮40x∮68x15 MI-31662-170 C009053 Support(L) MI-31662-171 C010026 Cover(R) MI-31662-172 S284006 Spring Washer ∮6.1x∮12.2x2.7x1.5T MI-31662-173 S135020 Hex.Head Screw...
  • Page 24 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-184 C009021 Support MI-31662-185 P051001 Brass Bearing ∮19.05x∮22.225x18L MI-31662-186 S043004 Thrust Bearing 2904 20x35x10 MI-31662-187 C035001 Shaft MI-31662-188 C028001 Gear MI-31662-189 S267512V Spring Pin ∮5∮5.2x40L (V)
  • Page 25 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-191-1 P041207R Motor 2P 7 1/2HP(5.5KW) .R MI-31662-191-2 P041208R Motor 2P 10HP(7.5KW) .R MI-31662-192 C064125 Pulley MI-31662-193 S214012 Set Screw M10-P1.5x12L MI-31662-194 C063003 Motor Bracket MI-31662-195...
  • Page 26 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty C009067 Housing MI-31662-203 S026006ZZ Ball Bearing MI-31662-204 6006ZZ. ∮30x∮55x13 S026205ZZ Ball Bearing MI-31662-205 6205ZZ. ∮25x∮52x15 S298131 C-Ring #52 ∮56.2x2.0t MI-31662-206 (2.2) C047078 Pulley Shaft MI-31662-207 S298015 C-Ring #25 ∮23.2x1.2t...
  • Page 27 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-223 C046128 ∮19.05x678L MI-31662-224 C052077 Bushing MI-31662-225 C045012 Finger MI-31662-226 C052014 Bushing PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty...
  • Page 28 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-239 C039027 Infeed Shaft MI-31662-240 C038006 Infeed Roller MI-31662-241 P063004 Rubber Bushing MI-31662-242 C051023 Bushing MI-31662-243 S213012 Set Screw MI-31662-244 C009017 Bearing Block(R) MI-31662-245 C009049 Bearing Block(L)
  • Page 29 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-255 C040039 Roller MI-31662-256 C009008 Support MI-31662-257 S026205ZZ Ball Bearing 6205ZZ ∮25x∮52x15 MI-31662-258 S298131 C-Ring #52 ∮56.2x2.0t (2.2) MI-31662-259 C051020 Collar M6-P1.0x10L MI-31662-260 S273010R M10-P1.5 MI-31662-261 S137320 Hex.Head Screw...
  • Page 30 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-272 C009005 Bearing Housing MI-31662-273 S026204ZZ Ball Bearing 6204ZZ. ∮20x∮47x14 MI-31662-274 S026205ZZ Ball Bearing 6205ZZ. ∮25x∮52x15 MI-31662-275 C029007 Pinion MI-31662-276 C064017 Rear Pulley MI-31662-277 C064016 Front Pulley...
  • Page 31 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-292 C066004 Wheel MI-31662-293 P051001 Brass Bearing ∮19.05x∮22.225x18L MI-31662-294 C052016 Bushing MI-31662-295 S282111 Washer ∮10.5x∮25x2.0T MI-31662-296 S137035 Hex.Head Screw M10-P1.5x35L MI-31662-297 C049018 Linked Plate MI-31662-298 C015030...
  • Page 32 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-303-1 P082026 Switch MI-31662-303-2 T075007 Switch Plate (new) MI-31662-304 P074014K25 Magnetic Switch HK-25. MI-31662-305 S312003 Junction Box MI-31662-306 S282008 Washer ∮5.3x∮10x1.0T MI-31662-307 S225010 Rounded Head Screw M5-P0.8x10L...
  • Page 33 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-317 C085048 Cover MI-31662-318 P082710 Button, Green MI-31662-319 P082711 Stop Button, Red PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty...
  • Page 34 PARTS LIST FOR MI - 31662 NO. ITEM NO. REFERENCE NO. DESCRIPTION SPECIFICATION Q'ty MI-31662-330 C057008 Handle, Adjusting Plate MI-31662-331 C057009 Adjusting Plate MI-31662-332 S298050 C-Ring...
