SC3000 26" Disc
SC3000 28" Cyl.
INSTRUCTION FOR USE
INSTRUCTIONS D'UTILISATION
INSTRUCCIONES DE USO
INSTRUÇÕES DE USO
Advance models: 9087266020 - 26" Disc - Charger
9087267020 - 26" Disc - EcoFlex™ + Charger
9087268020 - 28" Cyl. - Charger
9087269020 - 28" Cyl. - EcoFlex™ + Charger
ENGLISH
FRANÇAIS
ESPAÑOL
PORTUGUÊS
9098827000(2)2010-12
Advertisement
Table of Contents
Related Manuals for Advance acoustic ecoflex SC3000 26 Disc Charger
Summary of Contents for Advance acoustic ecoflex SC3000 26 Disc Charger
- Page 1 SC3000 26” Disc SC3000 28” Cyl. ENGLISH INSTRUCTION FOR USE INSTRUCTIONS D’UTILISATION INSTRUCCIONES DE USO FRANÇAIS INSTRUÇÕES DE USO ESPAÑOL Advance models: 9087266020 - 26” Disc - Charger 9087267020 - 26” Disc - EcoFlex™ + Charger 9087268020 - 28” Cyl. - Charger 9087269020 - 28”...
-
Page 3: Table Of Contents
INSTRUCTIONS FOR USE ENGLISH TABLE OF CONTENTS INTRODUCTION ................................2 MANUAL PURPOSE AND CONTENTS ............................2 TARGET ......................................2 HOW TO KEEP THIS MANUAL ............................... 2 IDENTIFICATION DATA ................................... 2 OTHER REFERENCE MANUALS ..............................2 SPARE PARTS AND MAINTENANCE ............................. 2 CHANGES AND IMPROVEMENTS .............................. -
Page 4: Introduction
ENGLISH INSTRUCTIONS FOR USE INTRODUCTION NOTE The numbers in brackets refer to the components shown in Machine Description chapter. MANUAL PURPOSE AND CONTENTS The purpose of this Manual is to provide the operator with all necessary information to use the machine properly, in a safe and autonomous way. -
Page 5: Unpacking/Delivery
INSTRUCTIONS FOR USE ENGLISH UNPACKING/DELIVERY To unpack the machine, carefully follow the instructions on the packing. To move the machine manually, see the Pushing/Towing The Machine paragraph. Upon delivery carefully check that the machine and its packing have not been damaged during transportation. In case of visible damages, keep the packing and have it checked by the carrier that delivered it. -
Page 6: General Instructions
ENGLISH INSTRUCTIONS FOR USE GENERAL INSTRUCTIONS Specifi c warnings and cautions to inform about potential damages to people and machine are shown below. DANGER! – Before performing any maintenance, repair, cleaning or replacement procedure disconnect the battery connector and remove the ignition key. –... - Page 7 INSTRUCTIONS FOR USE ENGLISH WARNING! – Do not use the machine in particularly dusty areas. – Use the machine only where a proper lighting is provided. – If the machine is to be used where there are other people besides the operator, it is necessary to install the pivoting light and the reverse gear buzzer (optional).
-
Page 8: Machine Description
ENGLISH INSTRUCTIONS FOR USE MACHINE DESCRIPTION MACHINE STRUCTURE Steering wheel with control panel (see the following Bumper wheel paragraph) Solution fi lter Steering wheel height control lever Solenoid valve Ignition key Solution/clean water tank opening/closing valve Drive pedal Squeegee hook Heel support height adjustment Battery charger Front steering, driving and braking wheel... - Page 9 INSTRUCTIONS FOR USE ENGLISH MACHINE STRUCTURE (Continues) Serial number plate/technical data/conformity certifi cation Squeegee mounting handwheels Solution/clean water tank Squeegee balance adjusting handwheel Solution/clean water tank fi ller plug with removable fi ller Vacuum system motor hose Vacuum system motor fi lter Recovery water drain hose Battery connection diagram Tank assembly stand...
-
Page 10: Steering Wheel With Control Panel
ENGLISH INSTRUCTIONS FOR USE STEERING WHEEL WITH CONTROL PANEL Reverse gear activation/deactivation lever EcoFlex™ activation/deactivation lever (*) Reverse gear LED indicator EcoFlex™ system LED indicator (*): Detergent fl ow control switch (*) • LED on - EcoFlex™ system on Washing detergent fl ow control switch LED indicator (*) •... -
Page 11: Accessories/Options
INSTRUCTIONS FOR USE ENGLISH ACCESSORIES/OPTIONS In addition to the standard components, the machine can be equipped with the following accessories/options, according to the machine specifi c use: – GEL/AGM batteries – Brushes and cylindrical brushes of different materials – Pads of different materials –... -
Page 12: Wiring Diagram
ENGLISH INSTRUCTIONS FOR USE Technical data for machines with cylindrical brush deck Description 28” Cyl. Cylindrical brush size (diameter x length) 5.7 x 27.2 in (145 x 690 mm) Weight without batteries and with empty tanks 396.8 lb (180 kg) Maximum weight with batteries, full tanks and operator (75 kg) (GVW) 994.3 lb (451 kg) Cylindrical brush motor power... - Page 13 INSTRUCTIONS FOR USE ENGLISH WIRING DIAGRAM (Continues) P100361A SC3000 26” Disc / 28” Cyl. 9098827000(2)2010-12...
-
Page 14: Use
ENGLISH INSTRUCTIONS FOR USE WARNING! On some points of the machine there are some adhesive plates indicating: – DANGER – WARNING – CAUTION – CONSULTATION While reading this Manual, the operator must pay particular attention to the symbols shown on the plates. Do not cover these plates for any reason and immediately replace them if damaged. -
Page 15: Battery Installation And Battery Type Setting (Wet Or Gel/Agm)
INSTRUCTIONS FOR USE ENGLISH BATTERY INSTALLATION AND BATTERY TYPE SETTING (WET OR GEL/AGM) Battery installation Open the cover (20) and check that the recovery tank (19) is empty, otherwise empty it with the drain hose (24). Close the cover (20). Carefully lift the tank assembly (44). -
Page 16: Before Start-Up
ENGLISH INSTRUCTIONS FOR USE BEFORE START-UP WARNING! At every machine start-up, check that, between the deck (10 and 28) and the machine or between the squeegee (30) and the machine, there is no foreign material which may prevent the deck and the squeegee from lifting. This check is necessary because, if the machine has been turned off without lifting the deck and the squeegee, when turned on again, the deck and the squeegee lift automatically. - Page 17 INSTRUCTIONS FOR USE ENGLISH Available brushes and their relevant application guides (suggestions only) Models MIDLITE GRIT 180 MIDGRIT 240 PROLENE PROLITE UNION MIX General cleaning: Concrete Terrazzo fl oor Ceramic tiles/quarrystones Marble Vinyl tiles Rubber tiles Polishing: Rubber tiles Marble Vinyl tiles Cylindrical brush installation/removal (For SC3000 28”...
- Page 18 ENGLISH INSTRUCTIONS FOR USE Available cylindrical brushes and their relevant application guides (suggestions only) Models MAGNA GRIT 46 DYNA GRIT 80 MIDLITE GRIT 180 PROLENE PROLITE UNION MIX General cleaning: Concrete Terrazzo fl oor Ceramic tiles/quarrystones Marble Vinyl tiles Rubber tiles Squeegee installation Install the squeegee (30) and fasten it with the handwheels (34), then connect the vacuum hose (31) to the squeegee.
-
Page 19: Machine Start And Stop
INSTRUCTIONS FOR USE ENGLISH MACHINE START AND STOP Starting the machine Prepare the machine as shown in the previous paragraph. Turn the ignition key (58) to “I” without pressing the drive pedal (4). Check if the battery green warning light (62) turns on. If the yellow or red warning light turns on, turn the ignition key (58) back to “0”... -
Page 20: Machine Operation (Scrubbing/Drying)
ENGLISH INSTRUCTIONS FOR USE MACHINE OPERATION (SCRUBBING/DRYING) Start the machine as shown in the previous paragraph. If necessary, adjust the solution quantity by pressing the switches (59 and 60). If necessary, to reduce the noise, turn on the mute function by pressing the switch (55). NOTE It is suggested to use the mute function only on smooth fl...
