Summary of Contents for PORT Command
- Page 1 Smart Lock User Manual Model: Command...
-
Page 3: Table Of Contents
Table of Contents In the Box Product Specifications Features Preparing the Lock Installation Instructions Programming Your Lock Setting Your Passcode Adding IC Cards Lock Records Remote WiFi Management (Optional) Manual Key Troubleshooting... -
Page 4: In The Box
In the Box 2.) Back Panel (1) 3.) Latch (1) 1.) Front Panel (1) 4.) Manual Key (2) 5.) Waterproof 6.) Strike (1) Rubber Gasket (2) 8.) Bushing: M4x30mm 9.) Bushing: M5x30mm 7.) Strike Box (1) - Page 5 10.) Sliding Screws: 11.) Mortise Screws: 10x5 12.) Mortise (For Aluminum Door) (4) 16x5mm (2) Screws: 25x4mm (For Wooden Door) 13.) M4x20mm Screw 14.) M4x40mm Screw 15.) M4x6mm Screws for Door Thickness for Door Thickness (For the Back Panel 35mm-50mm 50mm-65mm and Battery Panel) (4) (1 3/8’’- 2’’) (2)
- Page 6 18.) M5x50mm Screws 19.)Wifi Gateway (optional) for door thickness 50mm-65mm (2’’-2 1/2’’) (1) 20.) Suction Cup (1) 21.) IC Card (1)
-
Page 7: Product Specifications
Product Specifications Model Materials 304 Stainless Steel & Zinc Alloy Front Panel Lock Size 170x70x20mm (6 3/4x 2 3/4x 3/4’’) Back Panel Lock Size 170x70x20mm (6 3/4x2 3/4x3/4’’) Lock Weight 1.5KG (3.3 lbs) Unlocking Methods Bluetooth Password Manual Key Card WiFi Remote Finish Satin Stainless Steel (SSS) - Page 8 (6 3/4’’) (3 3/8’’) (1’’) (2 3/4’’) Adjustable range from 52mm to 118mm (2 3/4’’) (2 1/4’’) (2 3/8’’) (1’’) Adjustable backset latch (slide the spindle hub to your desired backset)
-
Page 9: Features
Unlock using Passcode, Bluetooth app (iOS and Android), IC Card, Wi-Fi for remote and manual key • The Port Smart Lock unlocks with a permanent Master Passcode • Bluetooth keys based on duration can be generated and shared with guests. The mobile app can generate user passcodes, with validity duration from One-Time, Permanent, or a Duration based on Date-Time. -
Page 10: Preparing The Lock
Preparing the Lock Set up the levers to match the swing hand of the door. Exterior Panel: Remove the 4 • For Left Swing: Put the screws back screws. Turn lever to left and tighten and set • For Right Swing: Turn lever to right and set Interior Panel:... -
Page 11: Installation Instructions
Installation Instructions Install Latch 1) Use the template enclosed to cut holes for the door. ٭It is important to follow the template 2) Adjust the latch to the desired backset (2 3/8’’ or 2 3/4’’) 3) Install the latch using the 25x4mm (Parts #12) for wood doors and 10x5mm (Parts #11) screws for aluminum doors... - Page 12 Installing Interior Panel and Wire 1) Install the second waterproof rubber gasket (Part #5) 2) Connect the wires to the exterior panel wire (just plug in and click) 3) Connect the interior panel to the exterior panel using the M4 screws (Parts 13 and 14) (pick the desired length based on the door thickness)
- Page 13 Install the Battery 1) Install (8) new AAA batteries into the battery chamber Reinstall the Battery Cover 1) Put the battery cover back...
- Page 14 Programming Your Lock 1) Search for TTLock in the App Store or Google Play to download Login Register Register Phone Email Country/Region American Samoa+1684 Enter your Phone number Password between 6-20 characters Phone number/Email Confirm Password Password Verification Code Get Code Login Register Forgot Password?
- Page 15 2) Register a new account with your email address or login with an existing account (skip this step if you have an existing account) • The verification code will be sent to the user’s mobile phone or email and registration will be successful after verification 3) Touch the glass panel to light, click “+Add Lock’’...
- Page 16 On the app a voice command will sound “unlock”, and if there is any On the app a voice command will sound “unlock”, and if there is any...
- Page 17 Unlock with Passcode In order to open the door using passcode, enter the code and “#” 1. You will hear a voice command “unlock” and then open the door 2. If the wrong passcode is entered, you will hear “operation failed” and re-enter 3.
- Page 18 Sending E Keys 1) Click on “ ” as shown in the figure below; you can send the eKey to other users of TTLock to authorize the unlock (the receiver must download the app and set up an account) 2) Select e-key format (timed, permanent, one-time, recurring) 3) Enter the recipent’s account of TTLock, then set the name and effective time of the eKey.
- Page 19 Authorized Admin Create Admin You can authorize admin Admin List status to other users Managing E Keys 1) Click “ ” to manage the eKeys you send. The key management here refers to the Bluetooth key management. 2) After the administrator has successfully added the lock, the administrator will have the highest rights of the lock.
- Page 20 Adding IC Cards H11 supports opening door through IC Cards. Before an IC Card is sed to open the door, it needs to be added first. The adding process needs to be performed by the app. The validity period of the IC can be set, permanent or time limited.
- Page 21 Lock Records Click “ “ as shown below. With “Lock Records” you can view: eKeys, saved passcodes and unlock history TTLock eKeys Pending... 2020.03.06 11:14-2021.03.06 11:14 Touch to Unlock. Long Press to Lock Passcodes Records Refresh Records 444335 Invalid ..Search 2020.01.14 15:00- 2020.01.14 16:00 Timed 23175003...
- Page 22 Remote Wifi Management Adding a Gateway Please note that when adding a gateway, your smartphone and the gateway must be connected to the same Wi-Fi network.
- Page 23 TTLock is directly connected via Bluetooth and is not connected to the network itself, which is why it is not vulnerable to network attacks. The gateway is an accessory of the smart lock, it is the bridge connecting the smart lock and the home wifi network. Through the gateway, users can remotely view and calibrate the lock clock, read the unlocking records of passwords in a timely manner and remotely delete and modify passwords.
- Page 24 Troubleshooting Programming Troubleshooting 1) How do I read operation In the “Records” of the main records? interface or on the TTLock website 2) What is the maximum limit of There is no limit e-Key? 3) Why does it show “pending” when Before the receiver opens the app to I send e-Keys to other receive, the status shows...
- Page 25 11.) Is it possible to obtain the • IC Card: The remote add card password remotely? currently only supports Androids with NFC • Non Custom: Password can be obtained directly • Custom: Password can be obtained remotely by adding a gateway Hardware Troubleshooting 1) After installation, the touch a.) In this case, first check that the...
- Page 26 6.) How many times can I put the Enter wong 5 times and it locks for incorrect password before it locks 30 seconds me out? 7) How many records can be kept • Bluetooth: 500 on the lock? • Non-Bluetooth: 10,000 8) How many locks can match at No limit the same time?
- Page 27 1 (800) 219-2366 authority@portsmartlock.com http://www.portsmartlock.com/...
