Summary of Contents for PORT Post N20
- Page 1 Smart Lock Manual Model: Post...
-
Page 3: Table Of Contents
Table of Contents In the Box Product Specifications Features Installation Instructions Programming Your Lock Adding Fingerprint Lock Records Remote Wifi Management Using the Manual Key Troubleshooting... -
Page 4: In The Box
In the Box 1. Front Panel 2. Back Panel (1) 3. Latch (1) 4. Manual Key (2) 8. Hexgonal Screw 5. Waterproof 6. Strike (1) 7. Strike Box (1) M4x30mm (2) Rubber Gasket (2) 9.) Mortise Screws 10x5mm (For 9.Screw Stubs: 30.5x6mm for 10) Mortise Screws aluminum door) (4) door thickness 30mm-55mm... -
Page 5: Product Specifications
Product Specifications Model Name Material 304 Stainless Steel & Zinc Alloy Lock Size Handle: 148x27mm (5 3/4” x 1”) Base: 68mm (2 2/3”) Unlocking Methods Fingerprint Bluetooth Gateway Manual Key Finishes Satin Stainless Steel (SSS) Satin Black (SBL) Door Types Metal Wood Working Voltage... - Page 6 Lever Details Latch Dimensions...
-
Page 7: Features
Semiconductor fingerprint sensor (508dpi) • Voice guided lock/unlock command • Auto locking time setting option: After successfully unlocking, the Port Smart Lock will re-lock after a period of time (between 5 to 120 seconds). The owner sets this function Security •... -
Page 8: Installation Instructions
Installation Instructions Install Latch 1. Use the template enclosed to cut holes for the door. *It is important to follow the template 2. Adjust the latch to the desired backset (2 3/8” or 2 3/4”) 3. Install the latch using the 25x4mm screws for wood doors (Parts #10) and 10x5mm screws for aluminum doors (Parts #9) - Page 9 Connect Interior and Exterior Panel & Wires 1. Set the back panel (Part #2) along with the second waterproof rubber gasket (Part #5) on the door 2. Connect the wires from the interior panel to the exterior panel (just plug and click) 3.
- Page 10 Install Batteries 1. Install (4) new AAA Batteries into the battery chamber 2. Put the battery cover back System Initialization Reset button Open the cover of the back panel handle. Long press the “Reset” button for 5 seconds, and the initialization is complete...
-
Page 11: Programming Your Lock
Programming Your Lock 1. Search for TTLock in the App Store or Google Play to download Login Login Register Register 18520265893 Phone number/Email ..Password Login Login Forgot Password? Forgot Password? Login Register 18520265893 ..Login Forgot Password? 2. Register a new account with your email address or login with an existing account (skip this step if you have an existing account) •... - Page 12 TTLock Choose Lock Type All Locks Scan all types of locks Door Lock Padlock Lock Safe Lock Cylinder Press to Add Lock Bicycle Parking Lock Lock Remote Control The phone must be within 6 feet of the Smart Lock during the Pairing process Add Lock Nearby Locks BL01_63230b...
- Page 13 Sending E Keys 1. Click on “ ” as shown in the figure below; you can send the ekey to other users of TTLock to authorize the unlock (the receiver must download the app and set up an account) 2. Select e-key format (timed, permanent, one-time or recurring) 3.
-
Page 14: Adding Fingerprint
Managing E Keys 1. Click “ ” to manage the eKeys you send. The key mangement here refers to the Bluetooth key management. 2. After the administrator has successfully added the lock, the administrator will have the highest rights of the lock. The administrator can do the following: •... - Page 15 Add Fingerprint Add Fingerprint Add Fingerprint Name Connecting with Lock. Please wait... You will be required to Place your Finger on the Sensor several times. Please follow the prompt... Permanent 2020-03-06 09:37 Start Time 2020-03-06 09:37 End Time Next Follow the prompts...You will be required to Start remove and place your finger to the sensor to record your fingerprint...
-
Page 16: Lock Records
Lock Records Click “ “ as shown below. With “Lock Records” you can view: eKeys, saved fingerprints and unlock history TTLock Records eKeys Refresh Records Pending... Search 2020.03.06 11:14-2021.03.06 11:14 2019-07-12 18050066613 11:28:56 unlock with app success Touch to unlock. Long press to lock. -
Page 17: Remote Wifi Management
Remote Wifi Management Adding a Gateway Please note that when adding a gateway, your smartphone and the gateway must be connected to the same Wi-Fi network. - Page 18 TTLock is directly connected via Bluetooth and is not connected to the network itself, which is why it is not vulnerable to network attacks. The gateway is an accessory of the smart lock. It is a bridge connecting the smart lock and the home wifi network.
-
Page 19: Troubleshooting
Troubleshooting Programming Troubleshooting 1. Where can I view my operation • Under “Records” on the app records? • TTLock website 2. What is the purpose of uploading What is uploaded is not the my fingerprint? fingerprint itself, but the number of the fingerprint. - Page 20 11. What is the maximum number of There is no limit locks that can be added on the app? 12. Is it possible to add fingerprint Fingerprint is not supported for remotely? remote addition at the time being Hardware Troubleshooting 1.
- Page 21 5. There is no response when using It may be the triangle direction on the the handle on the outside of the door; clutch has an error, please check the and the inside of the door is connection responsive, but the verification motor is normal 6.
- Page 22 1 (800) 219-2366 authority@portsmartlock.com http://www.portsmartlock.com...
