P+L Systems PlusZap PZ16 Manual

Commercial Zapper Insect Control
Please read these instructions carefully and store in a safe
place for future reference.
PLUSZAP
™
As part of the P+L brand of insect control products, PlusZap
an effective and flexible commercial flykiller. Available in a
white or stainless steel finish, two sizes of unit are available
which can be wall mounted, ceiling suspended or desk
mounted.
Contents of package
- 1 x PlusZap flykiller
™
- 2 x Screws, wall plugs and suspension keyrings
- 1 x Mains cable
- 1 x Suspension chain
- 2 x UV tubes
WARNING - THIS APPLIANCE MUST BE EARTHED
INSECT CONTROL PRODUCTS
PlusZap utilises ultra violet tubes to attract flying insects and
™
zaps them on a killing grid, before collecting them in a deep
removable catch tray.
WARNING
PLUSZAP MUST ONLY BE USED IN AREAS WHICH ARE FREE OF
™
DUST AND ANY POSSIBLE EXPLOSIVE VAPOUR MIXTURE.
SHOULD YOU HAVE ANY QUERIES CONTACT YOUR LOCAL FIRE
AUTHORITY FOR ADVICE BEFORE INSTALLATION.
PLUSZAP IS SUITABLE FOR INDOOR USE ONLY AND IS NOT
™
SUITABLE FOR USE IN BARNS, STABLES AND SIMILAR
LOCATIONS.
POSITIONING
PlusZap should ideally be fixed around two meters above
™
the ground, preferably in the darkest place within the area to
be protected and is supplied with a two meter mains lead.
Do not position the unit close to windows, skylights or other
sources of light, or where it may be obscured by furniture,
doors or other obstacles. Ideally, PlusZap
visible from every part of the area to be protected.
INSTALLATION
PRIOR TO INSTALLATION, ENSURE THE POWER SUPPLY OF YOUR
MAINS OUTLET CORRESPONDS TO THAT MARKED ON THE
SPECIFICATION LABEL FOUND ON THE FLYKILLER.
PlusZap should be mounted as shown in the mounting
™
options section of this document. Use the removable mains
lead and plug to connect the PlusZap
appropriate rating, as specified on the specification label
found on the catch tray.
WARNING - THIS APPLIANCE MUST BE EARTHED
USING PLUSZAP
™
PlusZap should ideally be in operation for 24 hours a day,
™
ensuring your premises are kept free of flying insects. Insects
are most attracted to PlusZap
competition from daylight or other light sources.
units should be
™
to a power supply of
™
units at night when there is no
™
CLEANING
ENSURE THAT THE FLYING INSECT KILLER IS DISCONNECTED
FROM THE MAINS BEFORE CLEANING
It is recommended that cleaning is carried out regularly every
is
™
month. During cleaning the unit should be thoroughly wiped
down with a damp cloth, removing any build up of dirt.
Ensure the unit is completely dry before reconnecting it to the
power supply.
GUARANTEE
PlusZap has a two year guarantee and if maintained as
™
recommended in these instructions should continue to work
for many years.* Use of non-approved consumables may
invalidate the guarantee.
*Excludes tubes and starters. Does not cover breakdown due to misuse, incorrect operation
or use in an incorrect application.
MOUNTING FIXING CENTRES
METHOD PZ16
Wall 288mm 438mm
Desk
Suspended 356mm 506mm
Wall
Desk
Suspended
PZ30
- -
PZ16 & 30
