P+L Systems Satalite 18 Instructions

Decorative Glueboard Insect Control
Please read these instructions carefully and store in a safe place
for future reference.
SATALITE
TM
As part of the Insect-O-Cutor
Satalite TM a contemporary and highly effective decorative insect
control unit for use within front of house applications. Satalite
utilises highly effective UV tubes and is designed for use with a
high specification glupac
®
available, Satalite 18 and Satalite
TM
mounted either horizontally or vertically.

CONTENTS OF PACKAGE

- 1 x Satalite flykiller
- 1 x Glupac pheromone impregnated glueboard
®
- 2 x Screws and wall plugs
- 1 x Mains cable (Type X)
- 1 x Compact 18W tube (fitted)
or
- 2 x 15W High powered insect attractive UV tubes (fitted)
WARNING - THIS APPLIANCE MUST BE EARTHED (CLASS 1)
INSECT CONTROL PRODUCTS
Satalite utilises high powered ultra violet tubes to attract flying
TM
insects and retains the caught insects on a pheromone
impregnated glueboard for inspection or hygienic disposal.
WARNING
Satalite TM is not to be used by children or persons with reduced
physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or
instruction.
Children should be supervised to ensure they do not play with
the appliance.
If the mains cable is damaged it must be replaced by a
specialist mains cable available from P+L Systems Ltd or your
supplier.
Not suitable for applications where potentially explosive environ-
ments may exist.

POSITIONING AND GUIDANCE FOR USE

THIS UNIT IS FOR INDOOR USE ONLY.
Satalite should ideally be fixed around two meters above the
TM
ground, preferably in the darkest place within the area to be
protected. Do not position the unit close to windows, skylights or
other sources of light, or where it may be obscured by furniture,
doors or other obstacles. Ideally, Satalite
every part of the area to be protected.
Satalite should ideally be in operation for 24 hours a day,
TM
ensuring your premises are kept free of flying insects. Insects are
most attracted to Satalite
TM
competition from daylight or other light sources.

GUARANTEE

Satalite has a two year guarantee and if maintained as
TM
recommended in these instructions should continue to work for
many years.* Use of non-approved consumables may invalidate
the guarantee. Ensure genuine glupac
conjunction with this product.
*Excludes tube(s), glueboard and starter(s). Does not cover breakdown due to misuse,
incorrect operation or use in an incorrect application.
® brand of insect control products,
glueboard. Two sizes of unit are
30, both of which can be
TM
should be visible from
TM
units at night when there is no
glueboards are used in
®

INSTALLATION

INSTALLATION SHOULD BE CARRIED OUT BY SERVICE PERSONNEL
ONLY.
To ensure Satalite reaches you in perfect condition, a protective
TM
film covers the aluminium backplate. Remove this film before
use.
TM
Satalite should be mounted as shown in the mounting options
TM
section of this document. Once installed in position, fit the
glupac glueboard in position as described in the glueboard
®
replacement section of this document. Use the removable mains
lead and plug to connect the Satalite
supply.

CLEANING

CLEANING SHOULD BE CARRIED OUT BY SERVICE PERSONNEL
ONLY, AFTER ENSURING THAT THE UNIT IS DISCONNECTED FROM
THE MAINS SUPPLY.
It is recommended that cleaning is carried out regularly when
the glueboard is replaced. Once the glueboard is removed, the
unit should be thoroughly wiped down with a damp cloth,
removing any build up of dirt. Ensure the unit is completely dry
before reconnecting it to the power supply.

MOUNTING FIXING CENTRES

METHOD
Wall 180mm

WALL MOUNTING OPTIONS

Horizontal
TM to an appropriate power
1.

Front Guard Removal

18 30
426mm
Vertical
Satalite 18 & 30
2.
