P+L Systems Luralite Plus Instructions

Decorative Glueboard Insect Control
Please read these instructions carefully and store in a safe
place for future reference.
LURALITE PLUS
As part of the P+L brand of insect control products, Luralite
Plus is an easy to service and highly effective decorative
TM
insect control unit for use within front of house applications.
Luralite Plus utilises highly effective UV tubes and is designed
TM
for use with a high specification glupac
Contents of package
- 1 x Luralite Plus flykiller
™
- 1 x glupac pheromone impregnated glueboard
™
- 2 x Screws and wall plugs
- 2 x 15W High powered insect attractive UV tubes (fitted)
WARNING - THIS APPLIANCE MUST BE EARTHED
INSECT CONTROL PRODUCTS
Luralite Plus utilises high powered ultra violet tubes to attract
TM
flying insects and retains the caught insects on a pheromone
impregnated glueboard for inspection or hygienic disposal.
POSITIONING
THIS UNIT IS FOR INDOOR USE ONLY.
Luralite Plus should ideally be fixed around two metres
TM
above the ground, preferably in the darkest place within the
area to be protected and is supplied with a two meter mains
lead. Do not position the unit close to windows, skylights or
other sources of light, or where it may be obscured by
furniture, doors or other obstacles. Ideally, Luralite Plus
should be visible from every part of the area to be protected.
INSTALLATION
PRIOR TO INSTALLATION, ENSURE THE POWER SUPPLY OF YOUR
MAINS OUTLET CORRESPONDS TO THAT MARKED ON THE
SPECIFICATION LABEL FOUND ON THE FLYKILLER.
Luralite Plus should be fixed to the wall with the supplied wall
TM
plugs and screws. Once installed in position, fit the glupac
glueboard in position as described in the glueboard
replacement section of this document. Luralite Plus
plug fitted to the mains lead and once installed in position,
should be plugged into the nearest mains outlet.
WARNING - THIS APPLIANCE MUST BE EARTHED
USING LURALITE PLUS
Luralite Plus should ideally be in operation for 24 hours a day,
TM
ensuring your premises are kept free of flying insects. Insects
are most attracted to Luralite Plus
competition from daylight or other light sources.
glueboard.
™
units
TM
has a
TM
at night when there is no
TM
CLEANING
ENSURE THAT THE FLYING INSECT KILLER IS DISCONNECTED
FROM THE MAINS BEFORE CLEANING.
It is recommended that cleaning is carried out regularly when
the glueboard is replaced. Once the glueboard is removed,
the unit should be thoroughly wiped down with a damp
cloth, removing any build up of dirt. Ensure the unit is
completely dry before reconnecting it to the power supply.
GUARANTEE
Luralite Plus has a two year guarantee and if maintained as
TM
recommended in these instructions should continue to work
for many years.* Use of non-approved consumables may
invalidate the guarantee. Ensure genuine glupac
glueboards are used in conjunction with this product.
*Excludes tubes, glueboards and starters. Does not cover breakdown due to misuse,
incorrect operation or use in an incorrect application.
™
™
Luralite Plus
