P+L Systems INSECT-O-CUTOR Focus Series Instructions

Professional Electric Insect Control
Please read these instructions carefully and store in a safe
place for future reference.
Focus
As part of the Insect-O-Cutor
products, the Focus range is an effective range of professional
flykillers which utilise highly effective Synergetic
Constructed from coated mild steel, the Focus range can be
wall mounted, ceiling suspended or desk mounted.

Contents of package

- 1 x Insect-O-Cutor flykiller
- 1 x Mains cable (Type X)
- 1 x Removable catch tray (Fitted and wrapped)
- 2 x Wall mounting screws and wall plugs
- 2 x Suspension hooks
- 2 x Suspension chains
- 1 x High powered UV tube (F1 - Fitted)
or
- 2 x High powered UV tubes (F2 - Fitted)
WARNING - THIS APPLIANCE MUST BE EARTHED (CLASS 1)

INSECT CONTROL PRODUCTS

The Focus range utilises high powered ultra violet tubes to
attract flying insects and then electrocutes them on a killing
grid, before collecting them in a removable catch tray.

WARNING

The Focus range is not to be used by persons with reduced
physical, sensory or mental capabilities, or lack of experience
and training, unless they have been given instruction.
Children should be supervised to ensure they do not play with
the appliance.
If the mains cable is damaged it must be replaced by a
specialist mains cable available from P+L Systems Ltd or your
supplier.
The Focus range must only be used in areas which are free of
dust and any possible explosive vapour mixture, are suitable
for indoor use only and are not suitable for use in barns,
stables and similar locations.

POSITIONING AND GUIDANCE FOR USE

The Focus range should ideally be fixed around two meters
above the ground, preferably in the darkest place within the
area to be protected. Do not position the unit close to
windows, skylights or other sources of light, or where it may be
obscured by furniture, doors or other obstacles.
The Focus range should ideally be in operation for 24 hours a
day, ensuring your premises are kept free of flying insects.
Insects are most attracted to the Focus range at night when
there is no competition from daylight or other light sources.

GUARANTEE

The Focus range has a five year guarantee and if maintained
as recommended in these instructions, should continue to
work for many years*. Use of non-approved consumables may
invalidate the guarantee.
*Excludes tubes. Does not cover breakdown due to misuse, incorrect operation or use in an
incorrect application.
brand of insect control
®
UV tubes.
®

INSTALLATION

INSTALLATION SHOULD BE CARRIED OUT BY SERVICE
PERSONNEL ONLY.
Before installation, first remove the plastic tie-wraps that are
securing the removable killing grid in place during transit. The
Focus range should be mounted as shown in the mounting
options section of this document. Keep out of reach of
children.
Wall Mounting - Install the supplied wall plugs and screws to
the mounting surface, having first made sure that appropriate
wall plugs are used for specialist mounting materials, such as
plasterboard.
Ceiling Suspension - Fit the suspension hooks to the top of the
unit, by first removing the two top screws, then replacing them
with the suspension hooks in place. Then fix the suspension
chains to the hooks. The Focus range should be hung 2 - 3m
from the ground, so if the supplied chains do not allow this,
chains of appropriate length and strength should be sourced.
Once installed into position, use the removable mains lead
and plug to connect the Focus range to an appropriate
power supply, as specified on the specification label found on
the flykiller.

CLEANING

CLEANING SHOULD BE CARRIED OUT BY SERVICE PERSONNEL
ONLY, AFTER ENSURING THAT THE UNIT IS DISCONNECTED FROM
THE MAINS SUPPLY.
It is recommended that cleaning is carried out regularly every
month. During cleaning the unit should be thoroughly wiped
down with a damp cloth, removing any build up of dirt.
Ensure the unit is completely dry before reconnecting it to the
power supply.
Desk
Suspended
Focus
Wall
FOCUS
