- Page 1 Vertical Laminar Flow Hood User Manual Models LAF-6 / LAF-8 Germfree - LAF Vertical Laminar Flow Hood - User Manual - v1.0 - 06/01/21 - RMH...
- Page 2 LAF Vertical Laminar Flow Hood User Manual Germfree 4 Sunshine Blvd., Ormond Beach, Florida USA www.germfree.com +1 386.265.4300 For Customer Service Inquiries: cs@germfree.com Creating Environments that Serve Life Science Innovation and Advance Global Health...
-
Page 3: Table Of Contents
Use of the LAF Series Hood ........ - Page 4 Germfree’s Mission ........
-
Page 5: Equipment Warranty
Germfree does not offer any other explicit or implicit guarantee for this product. In the case where the exclusion of all implicit guarantees is contradicted by the law, the duration of the implicit guarantee will be for one year from the date of purchase. -
Page 6: Introduction
This airflow pattern is known as laminar. Your LAF Series Hood is intended to be used as a work area that maximizes product quality control and minimizes risk of product exposure to contaminates. It should only be used with non-hazardous materials since the air being bathed over the product is reintroduced into the laboratory environment without being filtered again. -
Page 7: Installation
Assembly for detailed instructions. Once the LAF Series Hood is inside the laboratory, it should be positioned so that it is out of traffic patterns and away from room air currents that could disrupt its airflow. At least a foot of free space should be left on both sides of the unit for maintenance purposes. -
Page 8: Airflow
LAF Vertical Laminar Flow Hood User Manual Airflow The LAF Series Hood intakes air through a prefilter placed on the top of the hood. Five motor blowers push air through a HEPA filter and diffuser, causing uniform, laminar air to bath over the entire work surface. -
Page 9: Use Of The Laf Series Hood
Good Technique The operator is the critical factor in the successful performance of any LAF Series Hood. It is dangerous to rely on the unit to do all of the work. When properly maintained and operated, the LAF Series Hood will do an excellent job of controlling airborne contamination. -
Page 10: Operation
Since this LAF unit should only be used to work with non-hazardous materials, a “decontamination” procedure does not need to be completed before cleaning the inside of the hood. A “disinfectant” procedure should be completed to ensure the hood is sanitized before more compounding occurs. -
Page 11: Cautionary Notes
LAF Vertical Laminar Flow Hood User Manual Any spills that occur inside the hood should be cleaned immediately and the work surface should be disinfected before any more work occurs in the hood. Your facility should have a written plan available in case of a spill. Any wipes or mop pads used to clean the hood should be disposed in the same way as all other waste from the hood. -
Page 12: Maintenance
However, the prefilter should be changed at least once every 90 days. Replacement prefilters are available from Germfree and are usually a stock item. Call Germfree Customer Service to order. HEPA Filters The average life of a HEPA filter is 3 to 5 years or longer, depending on the cleanliness of the ambient air. -
Page 13: Filter Diffuser
LAF Vertical Laminar Flow Hood User Manual Filter Diffuser The HEPA filter is located behind the removable, perforated metal diffuser. Do not push items such as needles through the diffuser holes and do not hang items from any part of the diffuser. The diffuser should only be removed by your certifier and at that time it can be cleaned. -
Page 14: Errors And Troubleshooting
Errors and Troubleshooting The LAF Series Hood is a user-friendly machine. Pressure error messages are both visual and audible. Visual alarms are clear and concise, and they will remain on until the issue is resolved. When an alarm is activated, verify the error by resetting the alarm (hold left and right arrows on the Sensocon®... -
Page 15: Certification / Testing Expectations
This power is proportional to air speed. Alternatively, the velometer uses a probe that intakes air, and the force against the meter causes a deflection in the needle. If your facility does not have a certifier, Germfree can assist in finding one in your area. -
Page 16: Filter Housing Disassembly And Assembly
LAF Vertical Laminar Flow Hood User Manual Filter Housing Disassembly and Assembly Your hood is transported in two pieces and operational. Once the filter housing is placed on the frame, it can be plugged into an outlet and will be ready to be certified. Placing the filter housing on the stand requires at least four people to ensure the hood is not damaged during the process. -
Page 17: Parts List
LAF Vertical Laminar Flow Hood User Manual Parts List Any consumable materials listed below can be replaced by contacting Germfree at +1 386.265.4300 or cs@germfree.com. FILTERS • HEPA (High Efficiency Particulate Air) • HEPA Air Filter – 73” x 29” x 3”... -
Page 18: Service Log
LAF Vertical Laminar Flow Hood User Manual Service Log Date Service Provided... -
Page 19: Quality Statement
User Manual Quality Statement Our Company Accountability Germfree has been a leading innovator in aseptic control and isolation systems since 1962. We will deliver our products on time, as promised, and free from defects. We design and manufacture a diverse range... -
Page 20: Appendix A: Laf-6 Drawing Package
LAF Vertical Laminar Flow Hood User Manual Appendix A: LAF-6 Drawing Package... - Page 21 NOTES: REVISIONS 77 9/16 1970 DESCRIPTION APPROVED DATE DRAWN BY CONSTRUCTION: OVERALL INITIAL RELEASE 10/01/19 DETAILS FOR NEW SASH DESIGN 11/18/19 TYPE 304SS, #4 POLISHED VIEW SCREEN: 3/8" POLYCARBONATE SS CASTERS, RELOCATION OF SENSOCON 12/11/19 SIDE SCREEN: 1/4" POLYCARBONATE ...
- Page 22 73 13/16 1875 WORK AREA HEPA FILTER LED LIGHT 28 13/16 WORK AREA VELOCITY SENSOR SECTION B-B SENSOCON ALARM / SILENCE 96 3/8 2448 79 11/16 2024 LIGHT INTERIOR SWITCH HEIGHT POWER SWITCH 35 1/2 DETAIL C SECTION A-A SS CASTERS...
- Page 23 FIXED POINT FIXED PULLEY 58 1/16 1475 SASH HEIGHT IN DOWN POSITION WINDOW SASH TRAVEL RANGE FRONT VIEW LEFT VIEW WITHOUT SASH WEIGHT BRACKET COVER MOVEABLE DETAIL D PULLEY...
-
Page 24: Appendix B: Laf-8 Drawing Package
LAF Vertical Laminar Flow Hood User Manual Appendix B: LAF-8 Drawing Package... - Page 25 REVISIONS NOTES: DESCRIPTION DATE DGNR DRFTR CHKR APRV CONSTRUCTION: INITIAL RELEASE 07JAN21 TYPE 304SS, #4 POLISHED FRONT VIEW SCREEN: 3/8" POLYCARBONATE SIDE SCREEN: 1/4" POLYCARBONATE GASKET MATERIAL: EPDM AND SILICONE CONTROL PANEL: 1x SENSOCON 1x MAIN POWER PUSH BUTTON ...
- Page 26 SENSOCON 99 3/16 PRE-FILTERS 31.5in x 28in x 1in QTY. 3 97 5/16 ALARM / SILENCE LIGHT SWITCH POWER 30 9/16 SWITCH 37 3/4 93 9/16 WORK AREA 28 7/8 WORK AREA 6 1/2 SECTION C-C TOP VIEW DETAIL B 38 1/8 PRE-FILTERS 31.5in x 28in x 1in...
-
Page 27: Appendix C: Electrical Diagrams
LAF Vertical Laminar Flow Hood User Manual Appendix C: Electrical Diagrams...
