Summary of Contents for Ford FOCUS 2014

Page 1 FORD FOCUS Owner's Manual...
Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2014 All rights reserved. Part Number: 01/2014 20140822070202...
Page 3: Table Of Contents
Table of Contents Disarming the engine immobilizer....41 Introduction About This Manual...........7 Alarm Symbols Glossary..........7 Principle of Operation........42 Replacement Parts Recommendation........9 Arming the alarm...........42 Disarming the alarm........42 At a Glance Steering Wheel At a Glance............11 Adjusting the Steering Wheel....43 Child Safety Audio Control...........43 Child Seats............20 Voice Control...........44...
Page 4 Table of Contents Cup Holders.............113 Windows and Mirrors Glasses Holder..........113 Power Windows..........68 Audio Input Jack..........113 Exterior Mirrors..........69 USB Port............113 Power exterior mirrors........70 Satellite Navigation Unit Holder....114 Auto-Dimming Mirror........71 Floor Mats............114 Blind Spot Information System....71 Starting and Stopping the Instrument Cluster Engine Gauges..............74 General Information........115...
Page 5 Table of Contents Parking Brake..........130 Active City Stop Principle of Operation.........153 Stability Control Using Active City Stop - 1.0L Principle of Operation........131 EcoBoost /2.0L Duratec-HE (MI4).............153 Using Stability Control - 1.0L EcoBoost /2.0L Duratec-HE (MI4)..............131 Load Carrying General Information........155 Hill Start Assist Luggage Covers..........155 Principle of Operation.........133 Using hill start assist........133...
Page 6 Table of Contents Under Hood Overview.........177 Navigation Engine Oil Dipstick - 1.6L Duratec-16V Navigation............199 (Sigma)............178 Engine Oil Dipstick - 2.0L Duratec-HE Audio introduction (MI4).............178 Important audio information....208 Engine Oil Dipstick........179 Engine Oil Check...........179 Audio unit overview Engine Coolant Check.........179 Audio unit overview ........209 Brake and Clutch Fluid Check....180 Power Steering Fluid Check.....180 Audio System Security...
Page 7 Table of Contents Auxiliary input jack Auxiliary input jack........227 Audio Troubleshooting Audio troubleshooting.......228 Appendices Electromagnetic Compatibility....229 Type approvals..........230 Type approvals..........230 Type approvals..........231 Type approvals..........232 Focus (CD3) , enPHI, Edition date: 01/2014...
Page 8 Focus (CD3) , enPHI, Edition date: 01/2014...
Page 9: Introduction
Introduction ABOUT THIS MANUAL Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it.
Page 10 Introduction Brake system Fasten safety belt Cabin air filter Front airbag Front fog lamps Check fuel cap Fuel pump reset Child safety door lock or unlock Fuse compartment Child seat lower anchor Hazard warning flashers Child seat tether anchor Heated rear window Cruise control E71340 Heated windshield...
Page 11: Replacement Parts Recommendation
You can clearly identify genuine Ford and Motorcraft parts Power steering fluid by looking for the Ford, FoMoCo or Motorcraft branding on the parts or their packaging. Power windows front/rear Scheduled Maintenance and...
Page 12 Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, refer to the terms and conditions of the Ford Warranty.
Page 13: At A Glance
At a Glance Front exterior overview E133220 See Locking and Unlocking (page 35). See Keyless Entry (page 37). See Autolamps (page 52). See Active City Stop (page 153). See Checking the Wiper Blades (page 49). See Maintenance (page 173). See Towing Points (page 171). See Changing a Bulb (page 58).
Page 14 At a Glance Tire pressures. See Technical Specifications (page 193). See Changing a Road Wheel (page 188). Vehicle interior overview E133222 See Transmission (page 126). See Locking and Unlocking (page 35). See Power Windows (page 68). See Power exterior mirrors (page 70). See Head Restraints (page 107).
Page 15 At a Glance See Fastening the safety belts (page 29). See Rear Seats (page 109). See Manual Seats (page 108). See Power Seats (page 109). See Parking Brake (page 130). See Opening and Closing the Hood (page 173). Instrument panel overview Type 1 Left-hand Drive E151209...
Page 16 At a Glance Right-hand Drive E151210 Focus (CD3) , enPHI, Edition date: 01/2014...
Page 17 At a Glance Type 2 Left-hand Drive E169976 Focus (CD3) , enPHI, Edition date: 01/2014...
Page 18 At a Glance Right-hand Drive E169977 Air vents. See Air Vents (page 98). Direction indicators. See Direction Indicators (page 55). Main beam. See Lighting Control (page 51). Information display control. See Information Displays (page 80). Instrument cluster. See Gauges (page 74). See Warning Lamps and Indicators (page 76).
Page 19 At a Glance Heated rear window switch. See Heated Windows and Mirrors (page 104). Heated windshield switch. See Heated Windows and Mirrors (page 104). Climate controls. See Climate Control (page 98). Start button. See Keyless Starting (page 115). Ignition switch. See Ignition Switch (page 115). Steering wheel adjustment.
Page 20 At a Glance Rear exterior overview E133221 See Checking the Wiper Blades (page 49). See Changing a Bulb (page 58). See Changing a Bulb (page 58). See Fuel filler door (page 122). See Changing a Road Wheel (page 188). Tire pressures. See Technical Specifications (page 193). Focus (CD3) , enPHI, Edition date: 01/2014...
Page 21 At a Glance See Towing Points (page 171). See First Aid Kit (page 161). See Warning Triangle (page 161). Spare wheel. See Changing a Road Wheel (page 188). Jack. See Changing a Road Wheel (page 188). Wheel brace. See Changing a Road Wheel (page 188). Towing eye.
Page 22: Child Safety
Child Safety CHILD SEATS WARNINGS Do not leave unattended children in your vehicle. If your vehicle has been involved in an accident, have the child restraints checked by properly trained technicians. Note: Mandatory use of child restraints E133140 varies from country to country. Only child restraints certified to ECE-R44.03 (or later) have been tested and approved for use in your vehicle.
Page 23: Booster Seats
Child Safety Child safety seat CAUTION When using a child seat on a rear seat, make sure that the child seat rests tightly against the vehicle seat. It may be necessary to lift or remove the head restraint. See Head Restraints (page 107). Booster seat (Group 2) E68920 Secure children that weigh between 13 and...
Page 24: Child Seat Positioning
Please consult your Dealer for the to its fully rearwards position. If it proves latest details relating to Ford difficult to tighten the lap section of the recommended child seats. safety belt without slack remaining, adjust the seatback to the fully upright position and raise the height of the seat.
Page 25 Child Safety Mass group categories Seating positions 9 - 18 kg 15 - 25 kg 22 - 36 kg Up to 10 kg Up to 13 kg (20 - 40 (33 - 55 (49 - 79 (22 lbs) (29 lbs) lbs) lbs) lbs)
Page 26 At time of publishing the recommended Group O+ ISOFIX baby safety seat is the Britax Roemer Baby Safe. Please consult your Dealer for the latest details relating to Ford recommended child seats. At time of publishing the recommended Group 1 ISOFIX child seat is the Britax Roemer Duo.
Page 27: Isofix Anchor Points
Child Safety Top tether anchor points - 4 door ISOFIX ANCHOR POINTS WARNING Use an anti-rotation device when using the ISOFIX system. We recommend the use of a top tether or support leg. Note: When you are purchasing an ISOFIX restraint, make sure that you know the correct mass group and ISOFIX size class for the intended seating locations.
Page 28: Child Safety Locks
Child Safety E87145 2. Push the child seat back firmly to engage the ISOFIX lower anchor points. E78298 3. Tighten the tether strap in line with the child seat manufacturer's instructions. Left-hand side Turn counterclockwise to lock and CHILD SAFETY LOCKS clockwise to unlock.
Page 29: Occupant Protection
Occupant protection Driver and front passenger airbags PRINCIPLE OF OPERATION Airbags WARNINGS Do not modify the front of your vehicle in any way. This could adversely affect deployment of the airbags. Original text according to ECE R94.01: Extreme Hazard! Do not use a rearward facing child restraint on a seat protected by an airbag in front of it! E74302...
Page 30 Occupant protection Safety belts The side airbags will deploy during significant lateral collisions. Only the airbag WARNINGS on the side affected by the collision will deploy. The airbags will inflate within a few Wear a safety belt and keep thousandths of a second and deflate on sufficient distance between yourself contact with the occupants, thus providing and the steering wheel.
Page 31: Fastening The Safety Belts
Occupant protection Pull the belt out steadily. It may lock if you FASTENING THE SAFETY pull it sharply or if the vehicle is on a slope. BELTS Press the red button on the buckle to release the belt. Let it retract completely WARNING and smoothly.
Page 32: Using Safety Belts During Pregnancy
Occupant protection The safety belt minder warning DISABLING THE PASSENGER lamp illuminates and an audible AIRBAG warning will sound if the driver's or front seat passenger's safety belt has WARNING not been fastened and the vehicle exceeds a relatively low speed. It will also illuminate Make sure that the passenger airbag if the driver's or front seat passenger's is disabled when using a rearward...
Page 33 Occupant protection Disabling the passenger airbag E71312 Disabled Enabled Turn the switch to position A. When you switch the ignition on, check that the passenger airbag deactivation warning lamp illuminates. Enabling the passenger airbag WARNING Make sure that the passenger airbag is enabled when you are not using a child restraint on the front passenger seat.
Page 34: Keys And Remote Controls
Keys and Remote Controls Note: Further remote controls may be GENERAL INFORMATION ON programmed at this stage. RADIO FREQUENCIES 4. Press any button on each additional remote control within 10 seconds of CAUTIONS each other. The radio frequency used by your remote control can also be used by Reprogramming the unlocking other short distance radio...
Page 35 Keys and Remote Controls Remote control without a folding Insert a screwdriver in the position key blade shown and gently push the clip. 2. Press the clip down to release the battery cover. E128810 E87964 3. Carefully remove the cover. Press and hold the pushbuttons on the edges to release the cover.
Page 36 Keys and Remote Controls E119190 4. Carefully insert the screwdriver in the position shown to open the remote control. E125860 CAUTION Do not touch the battery contacts or the printed circuit board with the screwdriver. 5. Carefully prise out the battery with the screwdriver.
Page 37: Locks
Locks Double locking with the key LOCKING AND UNLOCKING Turn the key to the lock position twice CAUTION within three seconds. Check your vehicle is locked before Double locking with the remote control leaving it unattended. Press the button twice within three seconds.
Page 38 Locks Locking and unlocking Locking the doors individually with confirmation the key Note: If your vehicle has double locking, the Note: If the central locking function fails to direction indicators will flash once after you operate, the doors can be individually locked have activated central locking, followed by using the key in the position shown.
Page 39: Keyless Entry
Locks Passive key KEYLESS ENTRY The vehicle can be locked and unlocked General information with the passive key. The passive key can also be used as a remote control. See WARNING Locking and Unlocking (page 35). The keyless entry system may not Locking the vehicle function if the key is close to metal objects or electronic devices such as...
Page 40 Locks Note: There must be clearance between each touch of the door handle. Note: Once activated, the vehicle will remain locked for a few seconds. When the delay period is over, the doors can be opened again, provided the passive key is within the respective detection range.
Page 41: Global Opening And Closing
Locks Global opening To enable all your passive keys, unlock the vehicle using a passive key or the remote control unlocking function. All passive keys will then be enabled if the ignition is turned on or the vehicle is started using a valid key.
Page 42 Locks To close all the windows, press and hold the remote control lock button for at least three seconds. Press the lock or unlock button to stop the closing function. The anti-trap function is also active during global closing. Vehicles with keyless entry E87384 WARNING Take care when using global closing.
Page 43: Engine Immobilizer
If you lose a key, you can obtain a replacement from your Ford Dealer. If possible, provide them with the key number from the tag provided with the original keys. You can also obtain additional keys from your Ford Dealer.
Page 44: Alarm
Alarm PRINCIPLE OF OPERATION DISARMING THE ALARM Alarm system Vehicles without keyless entry Your vehicle may be equipped with the Perimeter alarm following alarm system: Disarm and silence the alarm by unlocking • Perimeter alarm. the doors with the key and switching the ignition on with a correctly coded key, or Perimeter alarm unlocking the doors or the luggage...
Page 45: Steering Wheel
Steering Wheel ADJUSTING THE STEERING WARNING WHEEL Make sure that you fully engage the locking lever when returning it to its original position. WARNING Never adjust the steering wheel AUDIO CONTROL when the vehicle is moving. Select the required source on the audio Note: Make sure that you are sitting in the unit.
Page 46: Voice Control
Steering Wheel Type 2 VOICE CONTROL Type 1 Left hand drive E153802 Volume up Seek up or next E129464 Volume down Right hand drive Seek down or previous Seek, next or previous Press the seek button to: • tune the radio to the next or previous stored preset •...
Page 47 Steering Wheel Type 2 E159531 Press the button to select or deselect voice control. Focus (CD3) , enPHI, Edition date: 01/2014...
Page 48: Wipers And Washers
Wipers and Washers Automatic wiper system WINDSHIELD WIPERS Some models without autowipers are fitted with a speed-dependent front windshield wiper system. When the vehicle is slowed to walking speed or is brought to a standstill, the wiper speed will automatically switch to the next lower wiper speed setting.
Page 49: Windshield Washers
Wipers and Washers WINDSHIELD WASHERS E153811 High sensitivity E153812 WARNING Low sensitivity Do not operate the washer for more If you switch autowipers on, the wipers will than 10 seconds at a time, and never not cycle until water is detected on the when the reservoir is empty.
Page 50: Rear Window Wiper And Washers
Wipers and Washers Rear window washer REAR WINDOW WIPER AND WASHERS Intermittent wipe E153814 WARNING Do not operate the washer for more than 10 seconds at a time, and never when the reservoir is empty. While the lever is pushed away from the steering wheel the washer will work in conjunction with the wipers.
Page 51: Checking The Wiper Blades
Wipers and Washers Service position CHECKING THE WIPER BLADES E75184 E66644 Run the tip of your fingers over the edge of the blade to check for roughness. Clean the wiper blade lips with water applied with a soft sponge. CHANGING THE WIPER BLADES E153815 Windshield wiper blades...
Page 52 Wipers and Washers Install in the reverse order. Note: Make sure that the wiper blade locks into place. Rear window wiper blade Lift the wiper arm. E86456 2. Position the wiper blade at right angles to the wiper arm. 3. Disengage the wiper blade from the wiper arm.
Page 53: Lighting
Lighting One side LIGHTING CONTROL Lighting control positions E132706 E153816 Right-hand side Side and tail lamps Left-hand side Headlamps High and low beam Parking lamps WARNING Prolonged use of the parking lamps will discharge the battery. Switch off the ignition. Both sides Turn the lighting control switch to position E153817...
Page 54: Autolamps
If the lights of oncoming vehicles are hidden by obstacles (for example guard rails) the system may not deactivate the high beam. Always fit Ford Original Parts when replacing headlamp bulbs. Other bulbs may reduce system performance. Check and replace wiper blades...
Page 55 Lighting Note: Keep the windscreen free from obstructions such as bird droppings, insects and snow or ice. The system will automatically switch on main beam if it is dark enough and no other traffic is present. If it detects an approaching vehicle’s headlamps or tail lamps, or street lighting ahead the system will switch off main beam before it can...
Page 56: Front Fog Lamps
Lighting To permanently deactivate the system use REAR FOG LAMPS the information display menu or turn the lighting control switch from autolamps to WARNINGS headlamps. Only use the rear fog lamps when visibility is restricted to less than 50 FRONT FOG LAMPS meters (164 feet).
Page 57: Cornering Lamps
Lighting CORNERING LAMPS E72898 Headlamp beam Cornering lamp beam The cornering lamps illuminate the inside DIRECTION INDICATORS of a corner when you are turning. E153816 Focus (CD3) , enPHI, Edition date: 01/2014...
Page 58: Interior Lamps
Lighting Note: Tap the lever up or down to make the You can control all lamps using switch A. direction indicators flash only three times. Type 2 INTERIOR LAMPS Interior lighting Note: Individual lamps may be switched on independently, but not off if all lamps have been switched on by the driver.
Page 59: Adjusting The Headlamps - Vehicles With: High Intensity Discharge Headlamps/Adaptive Front Lighting
Lighting Type 2 Ambient lighting illuminates several areas, for example footwells, cup holders and doors with a single color and can be switched on and off using the information display menu. See (page 80). Use the instrument lighting dimmer switches to adjust to the desired brightness.
Page 60: Changing A Bulb
Lighting Note: When fitting the headlamp, make sure that you reconnect the electrical connector properly. Note: When fitting the headlamp, make sure that you fully engage the headlamp in the lower fixing point. Note: When fitting the headlamp, make sure that the screw is located in the headlamp molding before you install it.
Page 61 Lighting Headlamp main beam CAUTION Do not touch the glass of the bulb. Remove the headlamp. See Removing a Headlamp (page 57). E133102 Side lamp Headlamp dipped beam Headlamp main beam Direction indicator Direction indicator E133105 Remove the headlamp. See 2.
Page 62 Lighting Side repeater E133426 Carefully remove the cover. E133106 2. Remove the cover. 3. Disconnect the electrical connector. 4. Release the clip and remove the bulb. Side Lamp Remove the headlamp. See Removing a Headlamp (page 57). E133427 2. Using a suitable implement release the retaining clip.
Page 63 Lighting Insert your fingers into the gap between the mirror housing and the mirror glass and pull gently to remove the mirror glass. E133717 2. Remove the lamp. E133109 4. Remove the bulb holder. 5. Remove the bulb. Approach lamp E133718 3.
Page 64 Lighting Remove the trim panel. E133703 2. Remove the wing nuts. 3. Remove the lamp. E133107 Note: You cannot separate the fog lamp bulb from the bulb holder. 2. Disconnect the electrical connector. 3. Turn the bulb holder counterclockwise and remove it. Rear lamps - 4 door Direction indicator, brake and tail lamp E133713...
Page 65 Lighting 6. Gently press the bulb into the bulb 4. Remove the lamp. holder, turn it counterclockwise and remove it. A. Brake and tail lamp B. Direction indicator Fog and reversing lamp Open the luggage compartment lid. E133726 5. Disconnect the electrical connector. E133724 2.
Page 66 Lighting E133127 E133111 4. Disconnect the electrical connector. Remove the trim panel. E133113 E133112 5. Remove the bulb holder. 2. Remove the wing nuts and detach the clip. 6. Gently press the bulb into the bulb holder, turn it counterclockwise and 3.
Page 67 Lighting License plate lamp Vehicles with halogen lamps Note: These are not serviceable items, please consult your dealer if they fail. Interior lamps Vehicles with LED lamps Note: The LED board is not a serviceable item, please consult your dealer if this fails. E125092 E145746 Carefully prise out the lamp.
Page 68: Bulb Specification Chart
Lighting Luggage compartment lamp, Carefully prise out the lamp. footwell lamp and tailgate lamp 2. Remove the bulb. E72784 BULB SPECIFICATION CHART Lamp Specification Power (watt) Front direction indicator PY21W Headlamp main beam Headlamp dipped beam Cornering lamp Front fog lamp Side lamp Side repeater WY5W...
Page 69 Lighting Lamp Specification Power (watt) Reversing lamp W16W Luggage compartment lamp Fit a replacement with the same rating as the one you have removed. Focus (CD3) , enPHI, Edition date: 01/2014...
Page 70: Windows And Mirrors
Windows and Mirrors Opening and closing the windows POWER WINDOWS automatically WARNING Press or lift the switch to the second action point and release it completely. Press or Do not operate the power windows lift it again to stop the windows. unless they are free from obstruction.
Page 71: Exterior Mirrors
Windows and Mirrors The power windows will stop 3. Lift the switch again for one more automatically while closing and reverse second. some distance if there is an obstacle in the 4. Push and hold the switch until the way. window is fully open.
Page 72: Power Exterior Mirrors
Windows and Mirrors The mirrors will fold automatically when POWER EXTERIOR MIRRORS you lock the vehicle with the key, the remote control or a keyless entry system request. The mirrors will unfold when you unlock the vehicle with the key, the remote control, a keyless entry system request, the driver's interior door handle or starting the engine.
Page 73: Auto-Dimming Mirror
Windows and Mirrors The system is a convenience feature that AUTO-DIMMING MIRROR aids the driver in detecting vehicles that may have entered the blind spot zone (A). The detection area is on both sides of the vehicle extending rearwards from the exterior mirrors to approximately 3 meters (10 feet) beyond the bumper.
Page 74 Windows and Mirrors System detection and alerts • Vehicles passing through the blind zone at high speed. The system will trigger the alert for vehicles • Severe weather conditions. that enter the blind spot zone from the rear • Several vehicles passing through the or merge from the side.
Page 75 Windows and Mirrors If the system senses a fault on either If the vehicle is fitted with a trailer tow sensor, the system warning symbol will module approved by us, the system will illuminate and remain on. The information detect a connected trailer and deactivate. display will confirm the fault and indicate A confirmation message will be shown in whether the left or right side is affected.
Page 76: Instrument Cluster
Instrument Cluster GAUGES Type 1 E132065 Information display. See Information Displays (page 80). Speedometer Engine coolant temperature gauge Tripmeter reset button See Trip Computer (page 87). Fuel gauge Tachometer Focus (CD3) , enPHI, Edition date: 01/2014...
Page 77 Instrument Cluster Type 2 and 3 E130149 Information display. See Information Displays (page 80). Speedometer Engine coolant temperature gauge Fuel gauge Tachometer If the needle enters the red section, the Engine coolant temperature gauge engine is overheating. Stop the engine, switch the ignition off and determine the All vehicles cause once the engine has cooled down.
Page 78: Warning Lamps And Indicators
Instrument Cluster Brake system lamp WARNING LAMPS AND INDICATORS It illuminates when the parking brake is engaged. The following warning lamps and indicators illuminate when the ignition is WARNING switched on: Reduce your speed gradually and • Airbag stop your vehicle as soon as it is safe to do so.
Page 79 Instrument Cluster Front fog lamp indicator Low fuel level warning lamp It will illuminate when you switch If it illuminates, refuel as soon as the front fog lamps on. possible. Frost warning lamp High beam indicator It will illuminate when you switch WARNING the headlamp main beam on.
Page 80: Audible Warnings And Indicators
Instrument Cluster Shift indicator 4. Highlight Information or Warning and press the OK button to switch the It will illuminate to inform you chime on and off. that shifting to a higher gear may 5. Press the left arrow button to exit the give better fuel economy and menu.
Page 81 Instrument Cluster Low fuel A warning chime will sound when the remaining fuel is less than approximately 6 liters (1.3 gallons). Safety belt minder See Belt Minder (page 29). Focus (CD3) , enPHI, Edition date: 01/2014...
Page 82: Information Displays
Information Displays Phone GENERAL INFORMATION Note: The information display will remain Settings on for several minutes after you switch off the ignition. Various systems on your vehicle can be controlled using the information display Controls controls on the steering column. Corresponding information is displayed in Press the up and down arrow buttons to the information display.
Page 83 Information Displays Trip Computer Dist to empty Trip odometer Instant fuel Ford EcoMode Average fuel Gear shifting Anticipation Speed Ford EcoMode Average speed Outside air All values Information Seatbelts Auto StartStop Settings Driver assist Traction ctrl BLIS City Stop Hill start assist...
Page 84 Information Displays Display Navigation info Always on On demand Always off Language English Deutsch Italiano Français Español Čeština Dansk Norsk Pyccкий Nederlands Polski Svenska Português Taiwanese Measure unit l/100km Miles/Gallon Temp unit °Celsius °Fahrenheit Chimes Park slot found Information Warning Convenience Aux heater Park heater...
Page 85 Information Displays Menu structure - Information and You can access the menu using the entertainment display buttons on the audio or navigation unit. Type 1 Radio FM AST AM AST Auxiliary iPOD Line in Menu Radio/CD/MP3-CD/USB/iPod (Depending on the audio source) Audio settings Adaptive volume Sound...
Page 86 Information Displays Type 2 Radio FM AST AM AST SYNC Media Dial number SYNC Phone Redial Phone book Call history Speed dial Text messaging BT Devices Phone settings Menu SYNC settings Set bluetooth On/Off Set defaults Master reset Install on SYNC System Information Voice settings Interaction mode...
Page 87 Information Displays Type 3 Navigation Active guidance Route Route sections list Block next section Unblock rte sectn Country Destination input City/postcode Street District Start guidance Traffic TMC for route All TMC Block next section Route sections list Unblock rt sectn Start guidance Home address Change address...
Page 88 Information Displays Eco settings Trailer Roof box Dynamic Motorway Tunnel Ferry/motorail Toll Seasonal roads Toll sticker Special functions GPS info System info Enter position Demo mode Radio See separate menu structure SYNC Media See separate menu structure SYNC Phone See separate menu structure See separate menu structure Menu SYNC settings...
Page 89: Trip Computer
Information Displays Map display Map content Arrows on map Nav time display Map heading up Best contrast Assistance options Signs/lanes Speed limits Nav icons in lists Clear last destination Personal data Clear favourites Delete home address Clear all Reset all settings See separate menu structure Audio Settings Clock Settings...
Page 90: Personalized Settings
Information Displays Resetting the trip computer Chime deactivation To reset a particular display: The following chimes can be deactivated: • Warning messages. Highlight Trip Computer with the up and down arrow buttons and press the • Information messages. right arrow button. 2.
Page 91 Information Displays Active City Stop Message Indicator Action Active City Stop Sensor amber See Using Active City Stop (page 153). blocked Clean screen Active City Stop not amber See Using Active City Stop (page 153). available Active City Stop Auto See Using Active City Stop (page 153).
Page 92 Information Displays Battery and charging system Message Message Action indicator Stop your vehicle as soon as it is safe to do so and Electrical system over switch off the ignition. Have the system checked voltage stop safely by a properly trained technician as soon as possible.
Page 93 Information Displays Doors open Message Message Action indicator Stop the vehicle as soon as safely possible and Driver door open close. Driver side rear door Stop the vehicle as soon as safely possible and open close. Stop the vehicle as soon as safely possible and Passenger door open close.
Page 94 Information Displays Keyless entry Message Message Action indicator Ford KeyFree key not See Keyless Entry (page 37). inside car Ford KeyFree key inside amber See Keyless Entry (page 37). vehicle Ford KeyFree Place key See Keyless Entry (page 37). in key holder Ford KeyFree no key See Keyless Entry (page 37).
Page 95 Information Displays Message Message Action indicator One or both of the headlamp low beam bulbs have Dipped beam bulb fault blown. Check the headlamp low beam bulbs. See Changing a Bulb (page 58). One or both of the brake lamp bulbs on your trailer Trailer brake lamp bulb have blown.
Page 96 Information Displays Occupant protection Message Indicator Action Have the system checked by a properly trained Service Beltminder technician as soon as possible. Parking aid Message Indicator Action Parking aid malfunction amber Have the system checked by a properly trained Service required technician as soon as possible.
Page 97 Traction control off amber See (page 80). Starting the engine Message Message Action indicator Ford KeyFree switch ignition off press See Keyless Starting (page 115). POWER Drive to clean exhaust amber See Diesel Particulate Filter (page 118). filter check handbook...
Page 98 Information Displays Transmission Message Message Action indicator Under certain driving conditions it is possible that the clutches in the transmission can overheat. In these circumstances it is necessary to press the brake pedal and stop the vehicle to prevent further Transmission too hot overheating.
Page 99 Information Displays Message Message Action indicator Transmission not in See Automatic Transmission (page 126). See Park select P Starting and Stopping the Engine (page 115). See Automatic Transmission (page 126). See To start press brake Starting and Stopping the Engine (page 115). Press brake pedal See Automatic Transmission (page 126).
Page 100: Climate Control
Climate Control Warming the interior PRINCIPLE OF OPERATION Direct the air towards your feet. In cold or Outside air humid weather conditions, direct some of the air towards the windshield and the Keep the air intakes forward of the door windows. windshield free from obstruction (snow, leaves etc.) to allow the climate control Cooling the interior...
Page 101: Manual Climate Control
Climate Control Side air vent MANUAL CLIMATE CONTROL Air distribution control E132996 E74660 Face level Face level and footwell Footwell Footwell and windshield Windshield You can set the air distribution control to any position between the symbols. Focus (CD3) , enPHI, Edition date: 01/2014...
Page 102 Climate Control Blower Ventilation E129885 Set the air distribution control, blower and air vents to suit your requirements. Air conditioning Switching the air conditioning on and E75470 Note: If you switch the blower off, the windshield may mist up. If you turn the blower off, the air conditioning will turn off.
Page 103: Automatic Climate Control
Climate Control With the heater control in this position, the If you move the air distribution control to air conditioning and recirculated air will a position other than windshield, the A/C switch on automatically. will remain on. You can switch the air conditioning and You can switch the air conditioning and recirculated air on and off.
Page 104 Climate Control To switch mono mode off Note: Avoid adjusting the settings when the vehicle interior is extremely hot or cold. Select a temperature for the passenger’s The automatic climate control adjusts to side with the rotary control on the the current circumstances automatically.
Page 105 Climate Control Air distribution The blower speed and the temperature control operate automatically and cannot To adjust air distribution, press the desired be adjusted manually. The blower is set to button. Any combination of settings can high speed and the temperature to HI. be selected simultaneously.
Page 106: Heated Windows And Mirrors
Climate Control When switched off, the heating, ventilation POWER MOON ROOF and air conditioning system is switched off and recirculated air is selected. WARNING Before operating the power HEATED WINDOWS AND moonroof you should verify it is free MIRRORS of obstructions and ensure that children and/or pets are not in the proximity of the moonroof opening.
Page 107 Climate Control Opening and closing the moonroof To open or close the moonroof automatically press either side of the switch to the second action point and release it completely. Press again to stop. When the closed position is reached, the moonroof stops automatically.
Page 108 Climate Control Moonroof safety mode WARNING The anti-trap function is not active during this procedure. Make sure that there are no obstacles in the way of the closing moonroof. If the system detects a malfunction, it enters a safety mode. The moonroof will move for only about 0.5 seconds at a time and then stop again.
Page 109: Seats
Seats • bend your legs slightly so that you can SITTING IN THE CORRECT press the pedals fully. POSITION • position the shoulder strap of the safety belt over the center of your shoulder and position the lap strap tightly across your hips. Make sure that your driving position is comfortable and that you can maintain full control of your vehicle.
Page 110: Manual Seats
Seats Adjusting the height of the driver s MANUAL SEATS seat Moving the seats backwards and forwards E70730 Adjusting the angle of the seatback E130249 WARNING Rock the seat backwards and forwards after releasing the lever to make sure that it is fully engaged in its catch.
Page 111: Power Seats - Vehicles With: 6-Way Power Seats
Seats POWER SEATS - VEHICLES WITH: 6-WAY POWER SEATS E78060 REAR SEATS WARNINGS When folding the seatbacks down and up, take care not to get your fingers caught between the seatback and seat frame. Make sure that the seats and the seatbacks are secure and fully engaged in their catches.
Page 112 Seats E135628 E135646 Note: Hold the cushion edge to avoid the ISOFIX anchor points and brackets. Note: Make sure that the safety belt is fully Insert your fingers between the seat tightened into the retractor. cushion and seatback and fold the seat cushion forwards.
Page 113 Seats Folding the seatbacks up WARNING When folding the seatbacks up, make sure that the belts are visible to an occupant and not caught behind the seat. Focus (CD3) , enPHI, Edition date: 01/2014...
Page 114: Convenience Features
CLOCK Note: You can use the socket to power 12 volt appliances that have a maximum current rating of 10 Amperes. Use only Ford See Information Displays (page 80). accessory connectors or connectors specified for use with SAE standard sockets.
Page 115: Cup Holders
Convenience features CUP HOLDERS WARNING Do not place hot drinks in the cup holders when the vehicle is moving. Rear seat armrest E91508 AUDIO INPUT JACK You can find the socket in the glove box or the center console. See Auxiliary input jack (page 227).
Page 116: Satellite Navigation Unit Holder
Convenience features SATELLITE NAVIGATION UNIT HOLDER Adjusting the holder E112711 Unlock. 2. Adjust the holder to the desired position. 3. Lock. Note: Make sure that the navigation unit holder is locked in position. FLOOR MATS WARNING When using the floor mats, always make sure the floor mat is properly secured using the appropriate fixings and positioned so that it does not interfere...
Page 117: Starting And Stopping The Engine
Starting and Stopping the Engine II The ignition is switched on. All electrical GENERAL INFORMATION circuits are operational. Warning lamps and indicators illuminate. This is the key General points on starting position when driving. You must also select If the battery has been disconnected the it when being towed.
Page 118 Starting and Stopping the Engine Ignition on Press the button once. All electrical circuits are operational, warning lamps and indicators illuminate. Starting with manual transmission Note: Releasing the clutch pedal during engine start will stop the engine cranking and return to ignition on. Fully depress the clutch pedal.
Page 119: Steering Wheel Lock
Starting and Stopping the Engine Stopping the engine with the To unlock the steering wheel: vehicle stationary Insert the key in the ignition switch. 2. Turn the key to position I. Note: The ignition, all electrical circuits, warning lamps and indicators will be Note: You may need to rotate the steering switched off.
Page 120: Starting A Diesel Engine
Starting and Stopping the Engine If the engine does not start after three STARTING A DIESEL ENGINE attempts, wait 10 seconds and follow the flooded engine procedure. Cold or hot engine If you have difficulty starting the engine All vehicles when the temperature is below -25°C (-13°F), press the accelerator pedal to the Note: When the temperature is below -15°C...
Page 121: Switching Off The Engine
Starting and Stopping the Engine Regeneration • Drive your vehicle at a constant speed, preferably on a main road or highway, WARNING for up to 20 minutes. • Avoid prolonged idling and always Do not park or idle your vehicle over observe speed limits and road dry leaves, dry grass or other conditions.
Page 122: Eco Mode
Eco Mode Anticipation PRINCIPLE OF OPERATION Adjusting your vehicle speed and the The system assists the driver to drive more distance to other vehicles without the need efficiently by constantly monitoring for heavy braking or acceleration will characteristics of gear changing, improve fuel consumption.
Page 123: Fuel And Refueling
Do not use leaded gasoline or gasoline Note: The use of additives or other engine with additives containing other treatments not approved by Ford is not metallic compounds (e.g. recommended. manganese-based). They could damage the emission system.
Page 124: Fuel Consumption
E144241 driving style, high speed driving, stop/start driving, air conditioning usage, the accessories fitted and towing etc. Your Ford dealer can give you advice on improving your fuel consumption. FUEL FILLER DOOR WARNINGS Take care when refueling to avoid spilling any residual fuel from the fuel nozzle.
Page 125 Fuel and Refueling Type 2 Type 2 E137622 Press/pull the flap to open it. E144295 2. Close the fuel filler flap. Press/pull the flap to open it. Note: Fuel filler flap is automatically locked 2. Open the door fully until it engages. when vehicle is locked.
Page 126 Fuel and Refueling E139205 E139202 Insert the fuel nozzle up to and including the first notch on the nozzle A. Keep it resting on the cover of the fuel pipe opening. E144296 WARNINGS We recommend that you remove the fuel nozzle slowly to allow any E139203 residual fuel to drain into the fuel tank.
Page 127: Technical Specifications
Fuel and Refueling 5. Slightly raise the fuel nozzle to remove Refueling with a fuel can Use the funnel which is located in the spare wheel well. E119081 TECHNICAL SPECIFICATIONS Focus Fuel Consumption Figures CO2 Emis- Urban Extra-Urban Combined sions Variant l/100 km l/100 km...
Page 128: Transmission
Transmission MANUAL TRANSMISSION AUTOMATIC TRANSMISSION Selecting reverse gear Selector lever positions CAUTION Do not engage reverse gear when the vehicle is moving. This can cause damage to the transmission. E133124 Park E99067 Reverse On some vehicles it is necessary to raise Neutral the collar whilst selecting reverse gear.
Page 129 Transmission The transmission will select the WARNINGS appropriate gear for optimum performance Apply the parking brake and based on ambient temperature, road select park before leaving your gradient, vehicle load and driver input. vehicle. Make sure that the selector lever is latched in position. Sport mode and manual shifting Sport Mode Note: An audible warning will sound if you...
Page 130: Park Lock Control
Transmission Moving off Release the parking brake. 2. Release the brake pedal and press the accelerator pedal. Stopping Release the accelerator pedal and press the brake pedal. 2. Apply the parking brake. 3. Select neutral or park. E133129 Note: The lever is white. Kickdown 4.
Page 131 Transmission To use this feature, carry out the following steps within 30 seconds after you switch the ignition off and before the driver's door is opened. Select park and switch off the vehicle. 2. Remove the key. 3. Press and hold the brake pedal. 4.
Page 132: Principle Of Operation
Brakes The ABS will not eliminate the risks when: PRINCIPLE OF OPERATION • you drive too close to the vehicle in Note: Depending on applicable laws and front of you regulations in the country for which your • the vehicle is aquaplaning vehicle was originally built, the brake lamps •...
Page 133: Stability Control
Stability Control Stability control (ESP) warning lamp PRINCIPLE OF OPERATION The ESP warning lamp will flash when the Electronic stability program (ESP) system is operating. See Warning Lamps and Indicators (page 76). WARNING Emergency brake assist ESP does not relieve you of your responsibility to drive with due care WARNING and attention.
Page 134 Stability Control To turn the system off and on. See Information Displays (page 80). Focus (CD3) , enPHI, Edition date: 01/2014...
Page 135: Hill Start Assist
Hill Start Assist PRINCIPLE OF OPERATION WARNINGS At all times you are responsible for The system makes it easier to pull away controlling the vehicle, supervising when the vehicle is on a slope without the the system and intervening, if need to use the parking brake.
Page 136 Hill Start Assist • Wait for a short time until the system deactivates automatically. • If a forward gear was selected when the system became active, select reverse gear. • If reverse gear was selected when the system became active, select a forward gear.
Page 137: Parking Aids
Parking Aids Note: The outer sensors may detect the PRINCIPLE OF OPERATION side walls of a garage. If the distance between the outer sensor and the side wall WARNING remains constant for three seconds, the The system does not relieve you of tone will switch off.
Page 138: Parking Aid - Vehicles With: Front And Rear Parking Aid
Parking Aids E130180 A trailer symbol indicates there is a trailer attached and the system is disabled. E130178 PARKING AID - VEHICLES Distance Indicator. WITH: FRONT AND REAR PARKING AID As the distance decreases the indicator moves towards the vehicle. WARNING A continuous tone will start at a distance of less than 30 centimeters (11 inches) to...
Page 139 Parking Aids Maneuvring with the parking aid You will hear an alternating tone from the front and rear if obstacles are closer than 30 centimeters (11 inches) to the front and rear bumpers. E130382 Distance Indicator. E130381 As the distance decreases the indicator Reverse gear selected moves towards the vehicle.
Page 140 Parking Aids E130180 A trailer symbol indicates there is a trailer attached and the rear sensors are disabled. Focus (CD3) , enPHI, Edition date: 01/2014...
Page 141: Rear View Camera
Rear view camera PRINCIPLE OF OPERATION The camera is a visual aid for use when reversing. WARNING The system does not relieve you of your responsibility to drive with due care and attention. CAUTIONS If you use a high pressure spray to wash your vehicle, only spray the camera briefly from a distance not E99105...
Page 142 Rear view camera Using the display CAUTIONS Obstacles above the camera position will not be shown. Inspect the area behind your vehicle if necessary. Marks are for general guidance only, and are calculated for vehicles in maximum load conditions on an even road surface.
Page 143 Rear view camera Note: When reversing with a trailer, the lines on the screen are not shown. Deactivating the rear view camera Note: Disengage reverse gear. The display will stay on for a short period before switching off. Note: The system will automatically switch off once the vehicle speed has reached approximately 15 km/h (9 mph).
Page 144: Active Park Assist
Active Park Assist The system will detect a suitable parallel PRINCIPLE OF OPERATION parking space and steer the vehicle into the space. The system controls the WARNINGS steering while the driver controls the The system does not relieve you of accelerator, transmission and brakes.
Page 145 Active Park Assist Move forwards at a maximum speed of 30 right-hand side of the vehicle. km/h (18 mph). Press the active park assist Note: If no selection is made via the switch. See At a Glance (page 11). Use direction indicator lever the system will the direction indicator lever to select default to the passenger side of the vehicle.
Page 146 Active Park Assist You can take control of the maneuver by To accept this message press the active holding the steering wheel. A message may park assist switch. See At a Glance (page appear that the system can be resumed. 11).
Page 147: Cruise Control
Cruise Control Setting a speed PRINCIPLE OF OPERATION Press the SET+ switch or the SET- switch WARNING to store and maintain your current speed. The cruise control indicator will illuminate. The system does not relieve you of See Warning Lamps and Indicators your responsibility to drive with due (page 76).
Page 148 Cruise Control Canceling the set speed Press the brake pedal or pull the CAN switch. Note: The system will no longer control your speed. The cruise control indicator will not illuminate but the system will retain the speed that you previously set. Resuming the set speed Pull the RES switch.
Page 149: Adaptive Cruise Control (Acc)
Adaptive cruise control (ACC) Note: When adaptive cruise control is PRINCIPLE OF OPERATION activated, you may hear some unusual sounds during automatic braking. This is WARNINGS normal and caused by the automatic The system is not a collision warning braking system. or avoidance system.
Page 150 Adaptive cruise control (ACC) Detection beam issues Automatic braking with ACC WARNINGS You must take immediate action once alerted, as the adaptive cruise control braking will not be sufficient to keep a safe distance to the vehicle in front. In some cases there may be no warning or the warning may be delayed.
Page 151: Using Adaptive Cruise Control
Adaptive cruise control (ACC) Changing the set speed USING ADAPTIVE CRUISE CONTROL Note: Vehicle speed may be increased and decreased at intervals of 5 km/h or 5 mph. The system is operated by adjustment Note: If the system does not react to these controls mounted on the steering wheel.
Page 152 Adaptive cruise control (ACC) The distance between you and the vehicle Press the brake pedal or pull switch F to detected in front is maintained by a cancel the system. The system will return variable setting. There are five steps which to standby mode allowing you full manual are represented by horizontal bars control of the vehicle.
Page 153: Forward Alert Function
Adaptive cruise control (ACC) • brake temperature being too high, for Note: The collision alerts will only occur if example when driving on mountainous the system is switched on, however the or hilly roads brake support is always on and cannot be turned off.
Page 154: Speed Limiter
Speed Limiter Switching the system on and off PRINCIPLE OF OPERATION Press switch B. The information display WARNING will prompt for a speed to be set. When you are going downhill, your Setting the speed limit speed may increase above the set speed.
Page 155: Active City Stop
Active City Stop PRINCIPLE OF OPERATION WARNINGS If the engine stops after the system has been activated, the hazard WARNINGS warning flashers will be activated. The system does not relieve you of your responsibility to drive with due The system may not function when care and attention.
Page 156 Active City Stop Switching the system on and off Note: The system automatically turns on every time you switch the ignition on. In certain situations it is advisable to disable the system, for example: • Driving off road when objects may cover the windshield.
Page 157: Load Carrying
Load Carrying GENERAL INFORMATION WARNINGS Use load securing straps to an approved standard, e.g. DIN. Make sure that you secure all loose items properly. Place luggage and other loads as low and as far forward as possible within the luggage or loadspace. Do not drive with the tailgate or rear E97377 door open.
Page 158: Towing
Towing In high altitude regions above 3281 feet TOWING A TRAILER (1000 meters), the stipulated maximum permitted gross train weight must be WARNINGS reduced by 10% for every additional 3281 Do not exceed 62 mph (100 km/h). feet (1000 meters). Failure to take care may result in loss Note: The electrical system is not suitable of vehicle control, serious personal...
Page 159 Towing Towing Capacities Variant Transmis- Body style Without Trailer Brake With Trailer Brake sion 1.6L Petrol Manual 4 door and 645 kg 750 kg 5 door Auto 4 door 750 kg 800 kg 2.0L Petrol Manual 4 door and 750 kg 1,100 kg 5 door Auto...
Page 160: Essential Towing Checks
Towing Electric brakes and manual, automatic or ESSENTIAL TOWING CHECKS surge-type trailer brakes are safe if you install them properly and adjust them to Follow these guidelines for safe towing: the manufacturer's specifications. The • Do not tow a trailer until you drive your trailer brakes must meet local and federal vehicle at least 1000 miles (1600 regulations.
Page 161 Towing • When stopped in congested or heavy traffic during hot weather, place the gearshift in position P to aid engine and transmission cooling and to help A/C performance. • Turn off the speed control with heavy loads or in hilly terrain. The speed control may turn off automatically when you are towing on long, steep grades.
Page 162: Driving Hints
Driving Hints In an emergency, the vehicle can be driven BREAKING-IN through water to a maximum depth of 200 millimeters (8 inches) and at a maximum Tires speed of 10 km/h (6 mph). Extra caution should be exercised when driving through WARNING flowing water.
Page 163: Roadside Emergencies
Roadside Emergencies FIRST AID KIT Space is provided in the luggage compartment. WARNING TRIANGLE Space is provided in the luggage compartment. Focus (CD3) , enPHI, Edition date: 01/2014...
Page 164: Fuse Box Locations
Fuses Pinch the retaining clips to release the FUSE BOX LOCATIONS cover. Engine compartment fuse box 2. Lower the fuse box cover and pull it towards you. This fuse box is located in the engine Install in the reverse order. compartment See Maintenance (page 173).
Page 165: Fuse Specification Chart
Fuses FUSE SPECIFICATION CHART Engine compartment fuse box E129925 Ampere Fuse Circuits protected rating Anti-lock Braking System pump, electronic stability program pump Electronic stability program valve Heated rear window Heater blower Trailer module Engine management systems, exhaust gas recirculation relay Starter relay Heated windshield (right-hand side) Focus (CD3) , enPHI, Edition date: 01/2014...
Page 166 Fuses Ampere Fuse Circuits protected rating Transmission control module Heated windshield (left-hand side) Front cigar lighter Windshield wipers Anti-lock Braking System, electronic stability program module Horn Brake lamp switch Battery monitoring system Relay coils, lighting control switch module Power window switch (front) Power exterior mirrors Transmission control module Air conditioning clutch...
Page 167 Fuses Ampere Fuse Circuits protected rating Not used Powertrain control module, transmission control module Headlamp control module (halogen leveling) Electric power assisted steering Body control module Rear window wiper Headlamp control module (high intensity discharge leveling), adaptive front lighting unit Adaptive cruise control Heated washer jets Power windows (front)
Page 168 Fuses Passenger compartment fuse box E129926 Ampere Fuse Circuits protected rating Fuel pump supply Not used Not used Passive anti-theft system supply Interior lamps, driver's door switch pack, glove box, ambient lighting, power moonroof Focus (CD3) , enPHI, Edition date: 01/2014...
Page 169 Fuses Ampere Fuse Circuits protected rating Not used Rain sensor module, humidity sensor, auto-dimming mirror Adaptive cruise control Not used Luggage compartment lid release Driver's door lock, double locking Information and entertainment display, GPS, bluetooth phone voice control connectivity Electrical steering column lock Instrument cluster Central locking Air conditioning...
Page 170 Fuses Ampere Fuse Circuits protected rating Restraint system Not used Not used Not used Load compartment fuse box E129927 Ampere Fuse Circuits protected rating Not used Keyless vehicle module Keyless vehicle door handles Door module (left-hand front) (power windows, central locking, electric folding mirrors, heated exterior mirrors) Door module (right-hand front) (power windows, central locking, electric folding mirrors, heated exterior mirrors)
Page 171 Fuses Ampere Fuse Circuits protected rating Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Not used Trailer module Blind spot monitor, active city stop, rear view camera...
Page 172: Changing A Fuse
Fuses Ampere Fuse Circuits protected rating Not used Power moonroof Not used Not used Not used Not used Not used Not used Not used Not used Not used Note: A fuse puller is located in the engine compartment fuse box. CHANGING A FUSE WARNINGS Do not modify the electrical system...
Page 173: Vehicle Recovery
Vehicle recovery Rear towing eye TOWING POINTS Towing eye location The screw-in towing eye is located in the spare wheel well. The towing eye must always be carried in the vehicle. Installing the towing eye CAUTION The screw-in towing eye has a left-hand thread.
Page 174 Vehicle recovery CAUTIONS Too much tension in the tow rope could cause damage to your vehicle or the vehicle that is towing. Select neutral when your vehicle is being towed. In the event of a breakdown or mechanical failure do not use individual axle carriers.
Page 175: Maintenance
(page 179). maintain its roadworthiness and resale • Brake fluid level. See Brake and value. There is a large network of Ford Clutch Fluid Check (page 180). Authorized Repairers that are there to help you with their professional servicing •...
Page 176 Maintenance E133239 E87786 Move the yellow catch to the right. Open the hood and support it with the strut. Closing the hood WARNING Make sure that the hood is closed properly. Lower the hood and allow it to drop from under its own weight for the last 20 –...
Page 177: Under Hood Overview - 1.6L Duratec-16V (Sigma)
Maintenance UNDER HOOD OVERVIEW - 1.6L DURATEC-16V (SIGMA) E130030 Engine coolant reservoir : See Engine Coolant Check (page 179). Brake and clutch fluid reservoir (right-hand drive) : See Brake and Clutch Fluid Check (page 180). Engine oil filler cap : See Engine Oil Check (page 179). Brake and clutch fluid reservoir (left-hand drive) : See Brake and Clutch Fluid Check (page 180).
Page 178: Under Hood Overview - 2.0L Duratec-He (Mi4)
Maintenance Engine oil dipstick : See Engine Oil Check (page 179). Windshield washer fluid reservoir : See Washer Fluid Check (page 181). For easy identification, filler caps and the engine oil dipstick are marked in color. UNDER HOOD OVERVIEW - 2.0L DURATEC-HE (MI4) E139960 Engine coolant reservoir : See Engine Coolant Check (page 179).
Page 179: Under Hood Overview
Maintenance Engine oil filler cap : See Engine Oil Check (page 179). Brake and clutch fluid reservoir (left-hand drive) : See Brake and Clutch Fluid Check (page 180). Battery: See Vehicle battery (page 185). Engine compartment fuse box: See Fuses (page 162). Air cleaner: No maintenance necessary.
Page 180: Engine Oil Dipstick - 1.6L Duratec-16V (Sigma)
Maintenance Engine coolant reservoir : See Engine Coolant Check (page 179). Brake and clutch fluid reservoir (right-hand drive) : See Brake and Clutch Fluid Check (page 180). Engine oil dipstick : See Engine Oil Check (page 179). Brake and clutch fluid reservoir (left-hand drive) : See Brake and Clutch Fluid Check (page 180).
Page 181: Engine Oil Dipstick
Note: Soak up any spillage with an Do not use oil additives or other absorbent cloth immediately. engine treatments. Under certain Top up with fluid that meets the Ford conditions, they could damage the specification. See Technical engine. Specifications (page 181).
Page 182: Brake And Clutch Fluid Check
Note: The brake and the clutch systems are technician as soon as possible. supplied from the same reservoir. Prolonged use of incorrect dilution of Top up with fluid that meets the Ford the coolant can cause engine damage specification. See Technical from corrosion, overheating or Specifications (page 181).
Page 183: Washer Fluid Check
ISO 4925 Class 6 Brake Fluid Your engine has been designed to be used with Ford Engine Oil, which gives a fuel economy benefit whilst maintaining the durability of your engine. Topping up the oil: If you are unable to find an oil that meets the specification defined by WSS-M2C913-C or WSS-M2C948-B (gasoline engines only), you must use SAE 5W-30 that meets the specification defined by ACEA A5/B5.
Page 184 Maintenance Capacities Variant Item Capacity in Liters (gallons) Gasoline engines Fuel tank 55 (12.1) 2.0L Duratorq-TDCi - DW Fuel tank 53 (11.6) Windshield washer system 4.5 (1) - with headlamp washers Windshield washer system - without headlamp 3 (0.7) washers 1.6L Duratec-16V Ti-VCT - Engine oil - with filter 4.1 (0.9)
Page 185: Vehicle Care
Use a clean, lint free cloth or a damp have completed the cleaning process. chamois leather to clean the inside of the We recommend that you use Ford service rear window. wheel cleaner. Make sure that you read and follow the manufacturer’s instructions.
Page 186: Cleaning The Interior
You should repair paintwork damage CLEANING THE INTERIOR caused by stones from the road or minor scratches as soon as possible. A choice of products is available from your Ford Safety belts Dealer. Read and follow the manufacturer’s instructions. WARNINGS Do not use abrasives, or chemical solvents to clean them.
Page 187: Vehicle Battery
Vehicle battery To connect the booster cables JUMP STARTING THE VEHICLE WARNING Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. CAUTIONS Connect batteries with only the same nominal voltage. Always use booster cables with insulated clamps and adequate size cable.
Page 188: Changing The 12V Battery
Vehicle battery BATTERY CONNECTION CAUTIONS Do not connect to the negative (–) POINTS terminal of the flat battery. CAUTION Make sure that the cables are clear of any moving parts and fuel delivery Do not connect to the negative (–) system parts.
Page 189: Wheels And Tires
Wheels and Tires To make sure the front and rear tires of GENERAL INFORMATION your vehicle wear evenly and last longer, we recommend that you swap the tires CAUTIONS from front to rear and vice versa at regular Use only approved wheel and tire intervals of between 5000 and 10000 sizes.
Page 190: Changing A Road Wheel
Wheels and Tires WARNINGS WARNINGS Only fit snow chains to specified Drive the shortest possible distances. tires. See Technical Specifications (page 193). Do not fit more than one spare wheel on your vehicle at any one time. CAUTION Do not carry out any tire repairs on a If your vehicle is fitted with wheel spare wheel.
Page 191 Wheels and Tires Jacking and lifting points It is recommended to use a workshop type hydraulic jack for changing between CAUTION summer and winter tires. Use only the specified jacking points. Note: Use a jack with a minimum lifting If you use other positions, you may capacity of 1.5 tonnes and a lifting plate with damage the body, steering, a minimum diameter of 80 millimeters (3.1...
Page 192 Wheels and Tires Assembling the wheel brace Type one WARNING When returning the wheel brace extension to its original position, take care not to get your fingers caught. Note: Make sure that the wheel brace is fully extended. E93302 Small arrow-shaped marks on the sills A show the location of the jacking points.
Page 193 Wheels and Tires Removing the wheel trim WARNINGS If your vehicle has a manual Type one transmission, select first or reverse gear. If it has an automatic Insert the flat end of the wheel brace transmission, select park. between the rim and the trim and carefully remove the trim.
Page 194 Wheels and Tires Note: The lug nuts of alloy wheels and spoked steel wheels can also be used for the steel spare wheel for a short time (maximum two weeks). Note: Make sure the wheel and hub contact surfaces are free from foreign matter. Note: Make sure that the cones on the lug nuts are against the wheel.
Page 195: Technical Specifications
Wheels and Tires TECHNICAL SPECIFICATIONS Tire pressures (cold tires) Lug nut torque Wheel type Nm (Ib-ft) 135 (100) Up to 80 km/h (50 mph) Normal load Full load Front Rear Front Rear Variant Tire size bar (lbf/ bar (lbf/ bar (lbf/ bar (lbf/ in²) in²)
Page 196 Wheels and Tires Continuous speed in excess of 160 km/h (100 mph) Normal load Full load Variant Tire size Front Rear Front Rear bar (psi) bar (psi) bar (psi) bar (psi) 205/60 R 16 2.1 (31) 2.1 (31) 2.4 (35) 2.8 (41) 1.6L Duratec-16V Ti- VCT - Sigma, 2.0L...
Page 197: Vehicle Identification
Vehicle identification VEHICLE IDENTIFICATION VEHICLE IDENTIFICATION PLATE NUMBER Note: The vehicle identification plate design may vary to that shown. Note: The information shown on the vehicle identification plate is dependant upon market requirements. E87496 The vehicle identification number is stamped into the floor panel on the right-hand side, beside the front seat.
Page 198: Capacities And Specifications
Capacities and Specifications TECHNICAL SPECIFICATIONS Vehicle dimensions 4-door Dimension description Dimension in mm (inches) Maximum length 4534 (178.5) Overall width including exterior mirrors 2010 (79.1) Overall height - EC curb weight 1451 - 1484 (57.1 - 58.4) Wheelbase 2648 (104.3) Front track 1544 - 1559 (60.8 - 61.4) Rear track...
Page 199 Capacities and Specifications Towing equipment dimensions E132737 Focus (CD3) , enPHI, Edition date: 01/2014...
Page 200 Capacities and Specifications 4-door Item Dimension description Dimension in mm (inches) Bumper – center of tow ball 77 - 80 (3 - 3.1) Attachment point – center of tow ball 3 (0.1) Wheel center – center of tow ball 1068 - 1071 (42 - 42.2) Center of tow ball –...
Page 201: Navigation
If the glass breaks, do not Note: You can only use Ford licensed data. touch the liquid crystalline material. In case of contact with the skin, wash immediately Road Safety with soap and water.
Page 202 Navigation Note: You are ultimately responsible for Safety Information the safe operation of your vehicle and must If detailed viewing of route instructions is evaluate whether it is safe to follow route necessary, pull off the road when it is safe suggestions.
Page 203 Navigation Message Unblock route sections Destination input Country City/postcode Street District Start guidance Traffic TMC for route All TMC Block next section Route sections list Unblock route sections Home address Start guidance Change address Last destinations Favourites Favourites (A-Z) Points of interest POIs nearby Near destination Along motorway...
Page 204 Navigation Message Always ask Driver: Leisurely Normal Fast Eco settings Trailer: Roof box Dynamic Motorway Tunnel Ferry/motorail Toll Seasonal roads Toll sticker Special functions GPS info System info Enter position Demo mode Route Options Press the NAV button and scroll to route options.
Page 205 Navigation Message Description and Action Short Uses the shortest distance possible. Driver: Leisurely This option will calculate your time of arrival based on a leisurely drive to the destination. Normal This option will calculate your time of arrival based on a normal drive to the destination.
Page 206 Navigation Message Description and Action Toll When switched off the system will avoid toll roads on your route and automatically update your route distance and timings. Seasonal roads When switched off the system will avoid seasonal roads (for example, mountain passes) on your route and automatically update your route distance and timings.
Page 207 Navigation Message Description and Action Store position Store and name your current position. This will automatically save in your favorites. Route options Set your route options from the available list. Special functions Select GPS and system information or a demonstration of the system functionality.
Page 208 Navigation Adjusting the Navigation Voice Level Nav Audio Mixing You can adjust the voice prompt level This feature allows you to adjust the during an active voice prompt by using the volume mix between the audio unit and volume control. navigation voice level.
Page 209 Navigation Move Once an active route is underway, guidance will be given by on-screen information and When you are in map mode, press function voice prompts. Whichever audio source button two. You can now use the arrow you wish to leave the unit in, basic turn by buttons on the audio unit to move around turn and distance information will remain the map.
Page 210: Audio Introduction
Audio introduction IMPORTANT AUDIO INFORMATION WARNINGS Due to technical incompatibility, E66257 recordable (CD-R) and rewritable Disc labels (CD-RW) discs may not function correctly. Audio CD These CD radio units will play compact discs that conform to the International Red Book standard audio specification.
Page 211: Audio Unit Overview
Audio unit overview Note: Units have an integrated multi function display situated above the CD aperture. This shows important information regarding control of your audio unit. Additionally, there are various icons placed around the display screen which light up when a function is active (for example CD, Radio or Aux.) Type 1 E130324...
Page 212 Audio unit overview TA: Press the button to turn traffic announcements on or off and cancels announcements during an active announcement. See Traffic information control (page 219). Numeric keypad: Press the button to recall a previously stored station. To store a favorite station press and hold until the sound returns. See Station preset buttons (page 219).
Page 213 Audio unit overview Type 2 Descriptions for function buttons E104157 E130142 Focus (CD3) , enPHI, Edition date: 01/2014...
Page 214 Audio unit overview Eject: Press the button to eject a CD. See Compact Disc Player (page 223). Cursor arrows: Press a button to scroll through on-screen choices. CD slot: Where you insert a CD. See Compact Disc Player (page 223). OK: Press the button to confirm on-screen selections.
Page 215 Audio unit overview RADIO: Press the button to select different radio bands, it will also cancel the menu or list browsing. See Audio unit operation (page 218). CD: Press the button to change source to CD, it will also cancel the menu or list browsing.
Page 216 Audio unit overview E129074 On, Off: Press the button to switch the audio system on or off. DISPLAY: Press the button to turn on the display into idle mode. Numeric keypad: Press the button to recall a previously stored station. To store a favorite station press and hold until the sound returns.
Page 217 Audio unit overview Seek up: Press the button to go to the next station up the radio frequency band or the next track on a CD when in CD mode. In phone mode, use the button to end a phone call. An incoming call can be rejected. See Station tuning control (page 218).
Page 218 Audio unit overview Function buttons 1 to 4 are context dependent, and change according to the current unit mode. Descriptions for the functions are shown at the bottom of the screen display. Focus (CD3) , enPHI, Edition date: 01/2014...
Page 219: Audio System Security
Audio System Security SECURITY CODE Each unit incorporates a unique code that is linked to the vehicle identification number (VIN). The system will automatically check that the audio unit and vehicle match before allowing operation. If a security code message appears, please see your dealer.
Page 220: Audio Unit Operation
Audio unit operation Note: The system will automatically ON/OFF CONTROL change to another corresponding station if the current one becomes unavailable, for Press the on/off control. This will also example when leaving the coverage area. operate the unit for up to one hour with the ignition turned off.
Page 221: Station Preset Buttons
Audio unit operation 2. Select RADIO mode and then SCAN. AUTOSTORE CONTROL 3. Use the seek buttons to scan up or Note: This will store up to a maximum of down the selected waveband. the 10 strongest signals available, either 4.
Page 222 Audio unit operation Note: When you are listening to a non TA station and turn TA off and on again a TP seek will occur. Traffic announcement volume Traffic announcements interrupt normal broadcasts at a preset minimum level that is usually louder than normal listening volumes.
Page 223: Audio Unit Menus
Audio unit menus AUTOMATIC VOLUME NEWS BROADCASTS CONTROL Some audio units interrupt normal reception to broadcast news bulletins from When available, automatic volume control stations on the FM waveband or radio data (AVC) adjusts the volume level to system (RDS) and enhanced other compensate for engine noise and road network (EON) linked stations, in the same speed noise.
Page 224: Regional Mode (Reg)
Audio unit menus It will restore radio reception when it finds one or, if one is not found, the unit will return to the original stored frequency. When selected, ‘AF’ will be shown in the display. Press the MENU button. 2.
Page 225: Compact Disc Player
Compact Disc Player COMPACT DISC PLAYBACK SHUFFLE/RANDOM Note: During playback, the display indicates Random track playback, also known as the disc, track and time that has elapsed shuffle, plays all tracks on the CD in since the start of the track. random order.
Page 226: Compact Disc Track Scanning
Compact Disc Player When an MP3 CD is playing, options You can play MP3 files recorded on include REPEAT for the track, or to repeat CD-ROMs, CD-Rs, and CD-RWs. The disc all the tracks in the folder. Repeat presses must be in the ISO 9660 level 1 or level 2 of function button 1 will toggle these format, or Joliet or Romeo in the expansion options.
Page 227 Compact Disc Player File formats Playback tip: To specify a desired playback order, before the folder or file • With formats other than ISO 9660 name, input the order by number (e.g., “01,” level 1 and level 2, folder names or file “02”), then record contents onto a disc.
Page 228: Mp3 Display Options
Compact Disc Player MP3 navigation • The disc name • The artist name MP3 tracks may be recorded on the CD in • The track name several ways. They can all be placed in the root directory like a conventional audio CD, These display options are selected in the or they can be placed in folders that may same way as MP3 displays.
Page 229: Auxiliary Input Jack
Auxiliary input jack Note: For optimum performance when using any auxiliary device set the volume on the device high. This will reduce audio interference when charging the device via the vehicle power supply socket. When fitted the Auxiliary input (AUX IN) socket permits an auxiliary device, such as an MP3 player, to be linked into the vehicle audio system.
Page 230: Audio Troubleshooting
Audio Troubleshooting AUDIO TROUBLESHOOTING Audio unit display Rectification PLEASE CHECK CD General error message for CD fault conditions, such as cannot read the CD, data-CD inserted, etc. Ensure disc is loaded correct way up. Clean and re-try, or replace disc with known music disc. If error persists contact your dealer.
Page 231: Appendices
Appendices ELECTROMAGNETIC WARNINGS The RF (radio frequency) transmitter COMPATIBILITY equipment (e.g. cellular telephones, amateur radio transmitters etc.) may WARNINGS only be fitted to your vehicle if they comply Your vehicle has been tested and with the parameters shown in the table certified to legislations relating to below.
Page 232: Type Approvals
The Bluetooth word mark and logos are TYPE APPROVALS owned by the Bluetooth SIG, Inc. and any use of such marks by Ford Motor Company FCC/INDUSTRY CANADA NOTICE is under license. Other trademarks and trade names are those of their respective This device complies with Part 15 of the owners.
Page 234: Type Approvals
Appendices TYPE APPROVALS WARNINGS Invisible laser radiation. Do not view Laser sensor directly with optical instruments (magnifiers). Class 1M laser product. IEC 60825-1: 1993 + A2:2001. Complies with FDA performance standards for laser products except for deviation pursuant to Laser Notice No. 50, dated July 26th, 2001.
Page 235 Index Audible Warnings and Indicators.....78 Automatic transmission........78 Door open..............78 Frost................78 See: Climate Control..........98 Key outside car............78 About This Manual...........7 Lights on..............78 Low fuel..............79 See: Brakes............130 Safety belt minder..........79 ABS driving hints Switching the chimes on and off....78 See: Hints on Driving With Anti-Lock Audio Control...........43 Brakes..............130 Type 1................43...
Page 236 Index Autostore control..........219 Changing a Bulb..........58 Autowipers............46 Approach lamp............61 Auxiliary input jack........227 Central high mounted brake lamp....64 Auxiliary Power Points.........112 Front fog lamps.............61 Headlamp...............58 Interior lamps............65 License plate lamp..........65 Battery connection points......186 Luggage compartment lamp, footwell lamp Belt Minder............29 and tailgate lamp..........66 Deactivating the safety belt minder.....30 Rear lamps - 4 door..........62 Blind Spot Information System....71...
Page 237 Index Cleaning the Interior........184 Driving Through Water.......160 Instrument cluster screens, LCD screens, Driving through water........160 radio screens...........184 Rear windows............184 Safety belts............184 Climate Control..........98 Eco Mode............120 Principle of Operation........98 Principle of Operation........120 Clock..............112 Electromagnetic Compatibility....229 Coded keys............41 Ending compact disc playback....226 Cold Weather Precautions.......160 Engine Coolant Check.........179 Compact disc playback......223...
Page 238 Index Fuel Consumption Heated Windows and Mirrors....104 See: Technical Specifications......125 Heated Exterior Mirrors........104 Fuel filler door..........122 Heated windows..........104 Heating Filling...............123 Refueling with a fuel can.........125 See: Climate Control..........98 Hill launch assist (HLA) Vehicle equipped with capless system..............123 See: Using hill start assist........133 Hill Start Assist..........133 Vehicles equipped with cap system....122 Fuel Quality - Diesel........121...
Page 239 Index Information Messages.........88 Active City Stop............89 Airbag...............89 Keyless Entry............37 Alarm................89 Disabled keys............38 Automatic main beam control.......89 General information..........37 Battery and charging system......90 Locking and unlocking the doors with the Blind spot monitor..........90 key blade............39 Cruise control and Adaptive cruise control Locking the vehicle..........37 (ACC)..............90 Passive key..............37...
Page 240 Index Maintenance...........173 Navigation............199 General Information...........173 Hazard Spot Warning........207 Technical Specifications........181 Information............204 Manual Climate Control......99 Loading Map Data..........199 Air conditioning...........100 Menu Structure..........200 Air distribution control........99 Navigation Map Updates........207 Blower..............100 Road Safety............199 Heating the interior quickly......100 Route Options.............202 Recirculated air...........100 Setting a Route..........200 Ventilation............100 Setting Your Navigation Preferences..204 Manual Seats..........108...
Page 241 Index Power moon roof.........104 Repairing Minor Paint Damage....184 Repeat compact disc tracks....223 Moonroof anti-trap protection......105 Moonroof relearning.........106 Type 1..............223 Moonroof safety mode........106 Type 2 and 3............223 Replacement Parts Opening and closing the moonroof....105 Recommendation.........9 Opening and closing the moonroof automatically..........105 Collision Repairs............9 Tilting the moonroof.........105 Scheduled Maintenance and Mechanical...
Page 242 Index Station tuning control.........218 Type approvals..........230 DAB service linking..........218 FCC/INDUSTRY CANADA NOTICE.....230 Manual tuning............218 Laser sensor............232 Scan tuning............218 RX-42 - declaration of conformity....230 Seek tuning............218 Steering Wheel Lock........117 Steering Wheel..........43 Switching Off the Engine......119 Under Hood Overview - 1.6L Duratec-16V (Sigma)............175 Vehicles with a turbocharger......119 Symbols Glossary..........7...
Page 243 Index Using the speed limiter.......152 Intentionally exceeding the set speed limit..............152 Warning Lamps and Indicators....76 Setting the speed limit........152 ABS warning lamp..........76 Switching the system on and off....152 Airbag warning lamp...........76 System warnings..........152 Blind spot monitor indicator......76 Using Winter Tires........187 Brake system lamp..........76 Cruise control indicator........76 Direction indicators..........76...
Page 244 Focus (CD3) , enPHI, Edition date: 01/2014...

Ford FOCUS 2014 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ford FOCUS 2014

Summary of Contents for Ford FOCUS 2014

Table of Contents
