Introduction ABOUT THIS MANUAL Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it.
Page 9
Engine air Engine Engine filter coolant coolant temperature Engine oil Explosive gas Fan warning Fasten Front airbag Front fog safety belt lamps 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 10
In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
Page 11
Introduction Ford Motor Company, Ford of Canada, and service and repair facilities may access or share among them data for vehicle improvement purposes. For U.S. only (if equipped), if you choose to use the SYNC® Vehicle Health Report, you consent that certain diagnostic information may also...
Page 12
EDR. Ford Motor Company and Ford of Canada do not access event data recorder...
Page 13
See www.dtsc.ca.gov/hazardouswaste/perchlorate for more information. FORD CREDIT (U.S. ONLY) Ford Credit offers a full range of financing and lease plans to help you acquire your vehicle. If you have financed or leased your vehicle through Ford Credit, thank you for your business.
Page 14
Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, see the terms and conditions of the Ford Warranty.
Page 15
Introduction Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. MOBILE COMMUNICATIONS EQUIPMENT Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’...
NHTSA and other safety organizations, or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consulting your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in your vehicle.
Page 17
See Front Passenger Sensing System in the Supplementary Restraints System chapter for more information. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
WARNING: Always restrain an unoccupied child seat or booster seat. These objects may become projectiles in a crash or sudden stop, which may increase the risk of serious injury. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 19
Note: The child seat must rest tightly against the vehicle seat upon which it is installed. It may be necessary to lift or remove the head restraint. See the Seats chapter for information on head restraints. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Is the shoulder belt centered on the shoulder and chest? • Can the child stay seated like this for the whole trip? Always use booster seats in conjunction with your vehicle lap and shoulder belt. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 21
If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 22
Do not introduce any item thicker than this under the booster seat. Check with the booster seat manufacturer’s instructions. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, occupants should only use seating positions where they are able to be properly restrained. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 24
2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 25
You should not be able to pull more belt out. If the retractor is not locked, unbuckle the belt and repeat Steps 5 and 6. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 26
There should be no more than 1 inch (2.5 centimeters) of movement for proper installation. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed.
Page 27
Your vehicle has LATCH lower anchors for child seat installation at the seating positions marked with the child seat symbol. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 28
The seat should move less than one inch when you do this for a proper installation. If the safety seat is not anchored properly, the risk of a child being injured in a crash greatly increases. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 29
Keep the tether strap just snug without lifting the front of the child seat. Keeping the child seat just touching the vehicle seat gives the best protection in a severe crash. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 30
4. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
If the safety seat is not anchored properly, the risk of a child being injured in a crash greatly increases. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. CHILD SAFETY LOCKS When these locks are set, the rear doors cannot be opened from the inside.
Never wear the shoulder belt under the arm. 2) Never swing the safety belt around your neck over the inside shoulder. 3) Never use a single belt for more than one person. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 33
The pretensioners may also activate when a side curtain airbag is deployed. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Make sure the tongue is securely fastened in the buckle. 2. To unfasten, press the release button and remove the tongue from the buckle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 35
Failure to replace the belt and retractor assembly could increase the risk of injury in crashes. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 36
3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
1. Squeeze the button and slide the height adjuster up or down. 2. Release the button and pull down on the height adjuster to make sure it is locked in place. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
If the Belt-Minder warnings have expired (warnings for about five minutes) for one occupant (driver or front passenger), the other occupant can still activate the Belt-Minder feature. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 39
Belt-Minder system activated for yourself and others who may use the vehicle. To reduce the risk of injury, do not deactivate or activate the Belt-Minder feature while driving the vehicle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 40
• This will disable the Belt-Minder feature for that seating position if it is currently enabled. • This will enable the Belt-Minder feature for that seating position if it is currently disabled. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Read the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a crash be replaced. However, if the crash was minor and an authorized dealer finds that the belts do not show damage and continue to operate properly, they do not need to be replaced.
Contact your authorized dealer as soon as possible. WARNING: Several airbag system components get hot after inflation. Do not touch them after inflation as this may result in serious injury. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 44
• you press the hazard control button • you press the panic button (if equipped) on the remote entry transmitter, or • your vehicle runs out of power. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• driver and passenger airbag modules • crash sensors and monitoring system with readiness indicator. See Crash Sensors and Airbag Indicator later in this chapter. • front passenger sensing system 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 46
Failure to follow these instructions may increase the risk of injury in a crash. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 47
The front passenger sensing system uses a pass airbag off indicator which will illuminate and stay lit to remind you that the front passenger frontal airbag is disabled. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 48
• If the indicator lamp remains lit even after this, the person should be advised to ride in the rear seat. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 49
If the airbag readiness lamp is lit, do the following: The driver or adult passengers should check for any objects that may be lodged underneath the front passenger seat or cargo interfering with the seat. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Manual.
The airbag was designed to inflate between the door panel and occupant to further enhance the protection provided occupants in side impact crashes. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
A, B, or C pillar trim, or the headliner on a vehicle containing side curtain airbags as you could be seriously injured or killed. Contact your authorized dealer as soon as possible. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 53
• a flexible headliner which opens above the side doors to allow side air curtain deployment. • crash sensors and monitoring system with readiness indicator. See Crash sensors and Airbag Indicator later in this chapter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
See the Instrument Cluster chapter. Routine maintenance of the airbag is not required. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
AIRBAG DISPOSAL Contact your authorized dealer as soon as possible. Airbags must be disposed of by qualified personnel. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Refer to Remote Control in this chapter for more information on the location and use of the mechanical key blade. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Note: Replacing the battery will not delete the transmitter from your vehicle. The transmitter should operate normally. The remote control uses one coin-type three-volt lithium battery CR2032 or equivalent. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 58
Press the button to activate the alarm. Press the button again or switch the ignition on to deactivate. Note: The panic alarm will only operate when the ignition is off. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 59
To remote start your vehicle: 1. Press the lock button to lock all the doors. 2. Press the remote start button twice. The exterior lamps flash twice. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
A dealer can program the transmitters to your vehicle or you may be able to program them yourself. See the Security chapter for information on programming your transmitters. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Vehicle speed minders of 45, 55 or 65 mph (75, 90 or 105 km/h). Once you select a speed, it will be shown in the display, followed by an audible tone when the preselected vehicle speed is exceeded. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
MyKey is successfully created. Make sure you label it so you can distinguish it from the admin keys. You can also program configurable settings for the key(s). See Programming/Changing Configurable Settings. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Indicates the number of MyKeys programmed to your vehicle. Use this feature to detect how many MyKeys you have for your vehicle and determine when a MyKey has been deleted. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
MyKey is not compatible with non-Ford-approved aftermarket remote start systems. If you choose to install a remote start system, please see your Ford authorized dealer for a Ford-approved remote start system . Vehicles With Ford-approved Aftermarket Remote Start Systems When using a Ford-approved aftermarket remote start system, the vehicle recognizes the remote start system as an additional admin key.
Page 65
MyKey compatible with non-Ford-approved remote start systems, but may help you retain some MyKey functions. When using a non-Ford-approved remote start system, the vehicle may recognize the remote start system as an additional admin key with its associated privileges.
MyKey. • The vehicle has been started using a remote start system that is not programmed with admin privileges. See Using MyKey With Remote Start Systems. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 67
• An admin fob is present at the vehicle start. No MyKey functions • No MyKeys are created. See Creating a with the Intelligent Access key. MyKey. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
The doors will lock again, the horn will sound and the turn signals will flash if all the doors and the luggage compartment are closed. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 69
The first pull unlocks the door and the second pull will unlatch the door. Activating Intelligent Access The intelligent access key must be within 3 feet (1 meter) of your vehicle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 70
• the ignition is on, • you shift into any gear putting your vehicle in motion, and • your vehicle attains a speed greater than 4 mph (7 km/h). 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 71
After programming the feature, switch the ignition off. The horn will sound once indicating programming is complete. Note: You can enabled or disabled the autounlock feature independently of the autolock feature. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 72
Accessory Mode Battery Saver for Intelligent Access Keys (If Equipped) If you leave the ignition on after leaving your vehicle, it will shut off 15 minutes after you close all of the doors. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Note: On a locked vehicle, you can press the trunk button on the remote control once. The vehicle will remain locked but you will have 20 seconds to press the outside release button. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Security SECURILOCK® PASSIVE ANTI-THEFT SYSTEM Note: The system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Metallic objects, electronic devices or a second coded key on the same key chain may cause vehicle starting issues if they are too close to the key when starting your vehicle.
Page 75
• Turn the ignition on or start the vehicle. • Use a key in the driver door to unlock your vehicle, then turn the ignition on within 12 seconds. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Correct Position in the Seats chapter. 1. Unlock the steering column. 2. Adjust the steering wheel to the desired position. 3. Lock the steering column. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• tune the radio to the next station up or down the frequency band • seek through a track. VOICE CONTROL (IF EQUIPPED) Pull the control to select or deselect voice control. See the MyFord Touch chapter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 78
Multimedia Controls Use the arrows on the right side of steering wheel to navigate through the available menus. Press OK to make a selection. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Use the rotary control to adjust the intermittent wipe interval. Speed Dependent Wipers When your vehicle speed increases, the interval between wipes will decrease when intermittent wipe is selected. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
When you shift into R (Reverse), the rear wiper will turn on to intermittent if the front wipers are activated. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 81
This may cause the washer pump to overheat. To use the rear washer function, push the lever away from you. When you release the lever, the wiper will operate for a short time. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Push the lever toward the instrument panel again or pull the lever towards you to deactivate. Flash-to-pass Pull toward you slightly to activate and release to deactivate. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Note: The headlamps can be activated manually by pulling the high beam/flash-to-pass lever toward you. The headlamps are deactivated after 30 seconds or three minutes if any door is open. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
This will ensure that your displays are visible under all lighting conditions. The brightness can then be adjusted to the users preference. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
You can switch the fog lamps on when the lighting control is in any position except off and the high beams are not on. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
A. Left map lamp switch, if equipped B. Right map lamp switch, if equipped C. Door function switch D. All lamps on and off switch 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 87
When the door function is on and you open a door, the courtesy and door lamps will switch on. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 88
• any of the remote entry controls are pressed and the vehicle is off. • all lamps on and off switch is pressed on the front dome/map lamp. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 89
The ambient lighting will remain on until you switch the ignition off and one of the following conditions have been met: • you lock your vehicle • the accessory delay timer expires. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Press the switch fully and release it. Press again or lift it to stop the window. One-Touch Up Lift the switch fully and release it. Press or lift it again to stop the window. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 91
You must reset the bounce-back memory separately for each window after the battery has been disconnected. 1. Lift and hold the switch until the window is fully closed. 2. Release the switch. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
WARNING: Do not adjust the mirror while your vehicle is in motion. A. Left-hand mirror B. Off C. Right-hand mirror Press the arrows to adjust the mirror. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 93
Glance over your shoulder to verify traffic is clear, and carefully change lanes. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
This lets you move the mirror head up or down and from side to side. Pull the tab below the mirror toward you to reduce glare at night. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Retract the visor before moving it back toward the windshield and storing it. Illuminated Visor Vanity Mirror Lift the cover to switch on the lamp. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Drive Habits as well as your use of accessories such as Climate Control. Your Range Estimate may change immediately when you change your Climate Control settings. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 97
• Energy Used - The average watt hours per mi (km). • Brake Score - The average percentage of braking energy recaptured and returned to the high voltage battery through regenerative braking. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Have the vehicle checked by your authorized dealer as soon as possible. Driving extended distances with the parking brake engaged can cause brake failure and the risk of personal injury. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 99
This will be accompanied by a corresponding message. Drive with caution. Keep the vehicle plugged in when not in use to maintain battery temperature. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 100
Safety belt Reminds you to fasten your safety belt. A Belt-Minder® chime will also sound to remind you to fasten your safety belt. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 101
Vehicle plugged in (RTT) Illuminates when the vehicle is plugged in. A corresponding message may display after attempting to start the vehicle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Sounds when you have left the parking brake on and drive your vehicle. If the warning chime remains on after you have released the parking brake, have the system checked by your authorized dealer immediately. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Press the OK button to choose and confirm a setting/messages. The arrows in the upper left corner of the display indicate additional content available when lit. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 104
Budget Text View Options Budget Text / Help Budget View Options Gauge Scale / Budget Text / Help Surplus Graphic / Budget Text / Range View Options Help 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 105
Estimate shown on Battery Gauge minus Budget distance). A positive Status indicates you are using less energy than typical and have extended your Range Estimate by the distance shown. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 106
The content you select is saved to the current driver’s key as MyView. Accessory Power: Indicates electrical power demands from your vehicle’s accessory systems. The gauge separately displays power demand in kilowatts (kW) for climate and other accessories. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 107
• Total Odometer — Displays the total distance the vehicle has traveled. This value can not be reset. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 108
System Check menu. View them immediately by pressing OK and then OK again to enter system check. Use the up/down arrows to scroll through the warnings. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 109
Note: Some items are optional and may not appear. Driver Assist Traction Ctrl On (default setting) / Off Rear Park Aid On (default on key cycle) / Off 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 110
Select the desired units of measure Temperature Brake Coach On / Off Regen Display On / Off Liftetime Energy use, Regen Miles, Brake Score, Hold OK to Summary Reset 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Check Brake System Displayed when the brake system needs servicing. If the warning stays on or continues to come on, contact your authorized dealer as soon as possible. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 112
Depleted Battery Stop safely now Displays when the estimated range is 0 mi (0 km). Stop the vehicle in a safe place. The vehicle must be charged. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 113
Drive with caution. Keep vehicle plugged in when not in use to maintain proper battery temperature. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 114
Your budget is set for the current vehicle range estimate. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 115
Key Inside Vehicle Displays to remind you that the key is in the luggage compartment. Refer to Push button start system in the Driving chapter for more information. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 116
Contact your authorized dealer. Headlamp malfunction Service Displays when an electrical system req’d problem occurs with the headlamp system. Contact your authorized dealer. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 117
Service Tire Mobility Kit Displayed when the kit needs service. See your authorized dealer. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 118
Check Park Aid Displayed when the transmission is in R (Reverse) and the park aid is disabled. Rear Park Aid On Off Displays the park aid status. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 119
To start press brake Displays when starting the vehicle as a reminder to apply the brake. Shift to Park Displayed as a reminder to shift to park. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 120
Understanding Your Tire Pressure Monitoring System (TPMS) in the Tires, Wheels and Loading chapter. If the warning stays on or continues to come on, contact your authorized dealer. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
This re-cooling of the interior air is more economical and efficient than normal air conditioning. Recirculated air may help reduce undesirable odors from entering the vehicle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 122
If you adjust the setting using the rotary control on the driver’s side, the system adjusts the temperature to the same setting on the passenger’s side. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 123
LO appears in the display. Air conditioning and recirculated air are on and fan speed increases to the highest speed. You can adjust the fan speed while in this mode. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 124
Use the heated seats on cold days to increase interior comfort. • Switch the air conditioning off in mild temperatures or low humidity conditions. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Note: Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum-based cleaning products. Both mirrors heat to remove ice, mist and fog when you turn the rear window defroster on. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 126
• heated seats • heated mirrors • heated rear window. You can adjust the settings using the information display controls. See the Information Displays chapter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 127
You can switch these devices on (if available, and selected to AUTO in the information displays) during remote start. Heated devices usually switch on during cold weather, and cooled devices during hot weather. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Keep sufficient distance between yourself and the steering wheel. We recommend a minimum of 10 inches (250 millimeters) between your breastbone and the airbag cover. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
For occupants of extremely tall stature, adjust the head restraint to its highest position. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 130
The head restraints consist of: A. An energy absorbing head restraint B. Two steel stems C. Guide sleeve adjust and release button D. Guide sleeve unlock and remove button 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 131
Note: Do not attempt to force the head restraint backward after it is tilted. Instead, continue tilting it forward until the head restraint releases to the upright position. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
WARNING: Rock the seat backward and forward after releasing the lever to make sure that it is fully engaged. Moving the Seat Backward and Forward Adjust the Height of the Driver’s Seat 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 133
WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a crash. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Lumbar Adjustment (If Equipped) Use the lever located on the side of the seatback to adjust the lumbar. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Allow the seat to dry thoroughly. • Operate the heated seats unless the vehicle is running. Doing so could drain the vehicle’s battery. Adjust the control to the desired heat setting. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
3. Stow the safety belt in the belt stowage clip. This will prevent the safety belt from getting caught in the seat latch. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 137
For additional cargo space, flip the seat cushions up before folding the seatback. This feature is only available on vehicles with a split folding seatback. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Do not leave devices plugged in overnight or when the vehicle is parked for extended periods. Locations Power points may be found: • on the center console • on the rear of the center console. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
OVERHEAD CONSOLE (IF EQUIPPED) The appearance of the overhead console will vary according to your option package. Press near the rear edge of the door to open it. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Press the brake pedal, and then press the button for a couple seconds. The green Ready to Drive indicator light appears in the instrument cluster when the vehicle is ready for driving. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 141
You cannot start the vehicle if the system does not detect a valid key within 10 seconds. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 142
3. Switch the ignition off by pressing and holding the button for one second, or pressing it three times within two seconds. 4. Apply the parking brake. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
WARNING: This equipment has arcing or sparking parts that should not be exposed to flammable vapors. This equipment should be located at least 18 inches (80 mm) above the floor. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 144
Power (green light) — this indicator lights up when the cord is plugged into the AC wall outlet. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 145
Don’t forget to press the lock button on your keyfob to re-lock the vehicle. The light ring will also display the current state of charge when opening the doors. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 146
If this happens unplug, and then re-plug the charging coupler into the charge port receptacle. If the problem persists contact your authorized dealer. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 147
When the vehicle automatically begins charging the light ring will turn on and display how far along the charge is per the section above. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 148
My GO Times per day for each of the seven days of the week. Remember, your vehicle must be plugged in for My GO time to work. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
The vehicle will detect if the electrical system is safe and reactivate automatically. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Is not intended for use under extended or normal driving conditions and results in less miles per charge. • The transmission may be shifted into L (Low) at any vehicle speed. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 151
3. Locate the brake shift interlock lever on the passenger side of the shifter assembly. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 152
If your vehicle gets stuck in mud or snow, it may be rocked out by shifting between forward and reverse gears, stopping between shifts in a steady pattern. Press lightly on the accelerator in each gear. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
This hold time will automatically be extended if you are in the process of driving off. 4. Drive off in the normal manner. The brakes will be released automatically. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
If the light does not illuminate during start-up, remains on or flashes, the anti-lock brake system may be disabled and may need to be serviced. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• you drive too closely to the vehicle in front of you. • your vehicle is hydroplaning. • you take corners too fast. • the road surface is poor. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
1. Press and hold the button located at the end of the parking brake handle. 2. Pull the handle up slightly, then push the handle down. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
When the traction control system is turned off or on, a message appears in the information display showing system status. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
See the Traction Control chapter for details on traction control system operation. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
R. You can turn off the traction control portion of the system independently. See the Traction Control chapter.. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Information Display chapter. If a fault is present in the system, a warning message appears in the information display and does not allow the driver to switch the faulted system on. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
WARNING: Backup as slow as possible since higher speeds might limit your reaction time to stop the vehicle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 162
3. Select Rear View Camera The guideline options are ACTIVE + FIXED, FIXED and OFF. Note: The centerline is available if Active or Fixed guidelines are ON. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 163
(4) to the yellow (3) or red zones (2). Use the side mirrors and rearview mirror to get better coverage on both sides and rear of the vehicle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 164
Selectable settings for this feature are (+) and (-). The default setting for the manual zoom is OFF. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 165
If the vehicle is in R (Reverse) and the liftgate is ajar, no rear video camera features will be displayed. A message will be displayed on the touchscreen if the liftgate is ajar. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 166
• If the image is not clear, check if anything is covering the lens such as dirt, mud, ice, snow, etc. If the image is still not clear after cleaning, have your system inspected by your authorized dealer. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Note: Cruise control will disengage if your vehicle speed decreases more than 10 mph (16 km/h) below your set speed while driving uphill. The cruise controls are located on the steering wheel. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 168
Switching Cruise Control Off Note: You will erase the set speed if you switch the system off. Press and release OFF or switch the ignition off. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
You may not notice any difference in the feel of your steering, but a serious condition may exist. Failure to do so may result in loss of steering control. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 170
Typical steering and driving maneuvers will allow the system to cool and steering assist will return to normal. When a steering system error is detected, steering messages may appear in the information display. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Vehicle Curb Weight – is the weight of your new vehicle when you picked it up from your authorized dealer plus any aftermarket equipment. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 172
Overloading or improperly loading your vehicle can contribute to loss of vehicle control and vehicle rollover. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 173
GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) – including vehicle curb weight and all payload. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 174
The GVW must never exceed the GVWR. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 175
WARNING: Do not exceed the GVWR or the GAWR specified on the Safety Compliance Certification Label. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 176
In metric units, the calculation would be: 635 kg - (5 x 99 kg) - (5 x 13.5 kg) = 635 - 495 - 67.5 = 72.5 kg. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013...
Page 177
Certification Label. The label shall be affixed to either the door hinge pillar, door-latch post, or the door edge that meets the door-latch post, next to the driver’s seating position. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
We recommend the use of a wheel lift and dollies or flatbed equipment to tow your vehicle. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Vehicle damage may occur if towed incorrectly, or by any other means.
Towing Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle. It is acceptable to have your vehicle towed from the front if using proper wheel lift equipment to raise the front wheels off the ground.
Once through the water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes. Drying can be improved by moving your vehicle slowly while applying light pressure on the brake pedal. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 181
• Always make sure that objects cannot fall into the driver footwell while the vehicle is moving. Objects that are loose can become trapped under the pedals causing a loss of vehicle control. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 182
• To install floor mats, position the floor mat so that the eyelet is over the retention post and press down to lock in. • To remove the floor mat, reverse the installation procedure. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
ROADSIDE ASSISTANCE Vehicles Sold in the U.S.: Getting Roadside Assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
U.S. Ford vehicle customers who require Roadside Assistance, call 1-800-241-3673. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles (56 kilometers). To obtain reimbursement information, U.S.
Do not attempt to push-start your automatic transmission vehicle. Automatic transmissions do not have push-start capability. Attempting to push-start a vehicle with an automatic transmission may cause transmission damage. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 186
Note: In the illustration, the vehicle on the bottom is used to designate the assisting (boosting) battery. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 187
2. Switch on the disabled vehicle to Ready to Drive mode. 3. Once the disabled vehicle has been started, keep both vehicles running for an additional three minutes before disconnecting the jumper cables. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Ready to Drive mode for several minutes so the high-voltage battery can continue to recharge the 12–volt battery. COLLISION, DAMAGE OR FIRE EVENT Guidance for Ford Motor Company Electric and Hybrid-Electric Vehicles Equipped With High-Voltage Batteries (Vehicle Owner/Operator/General Public)
Page 189
• Review the Owner’s Manual and become familiar with your vehicle’s safety information and recommended safety practices. • Do not attempt to repair damaged electric and hybrid-electric vehicles yourself. Contact an authorized Ford Dealer or vehicle manufacturer representative for service. Crashes...
Page 190
• For vehicles in the United States, notify Ford Motor Company 1-800-392-3673 (then follow the prompts on the voice response menu), an authorized Ford dealer or service center as soon as possible as there may be other steps to secure and/or discharge the HV battery.
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 192
• The name of the authorized dealer and city where located • The vehicle’s current odometer reading. In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 193
California Civil Code Section 1793.22(b) or the Magnuson-Moss Warranty Act, resorting to BBB AUTO LINE is not required by those statutes. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 194
BBB Auto Line dispute, and decision, are admissible in the court action. Should you choose to accept the BBB AUTO LINE decision, Ford is then bound by the decision, and must comply with the decision within 30 days of receipt of your acceptance letter.
Page 195
(CANADA ONLY) This pertains to vehicles delivered to authorized Canadian dealers. In those cases, where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation or arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 196
Central America, the Caribbean, and Israel, contact the nearest authorized dealer. If the authorized dealer cannot help you, contact: FORD MOTOR COMPANY FORD EXPORT OPERATIONS & GLOBAL INITIATIVES Customer Relationship Center 1555 Fairlane Drive Fairlane Business Park #3 Allen Park, Michigan 48101 U.S.A.
Page 197
If you buy your vehicle in North America and then relocate to any of the above locations, register your vehicle identification number (VIN) and new address with Ford Motor Company Export Operations & Global Growth Initiatives by emailing expcac@ford.com. If you are in another foreign country, contact the nearest authorized dealer.
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Green Green Green Pink Pink — — Orange Green Green — — — — Blue Yellow Yellow — — — Brown — — Natural Black Black 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. If the battery has been disconnected and reconnected, see Changing the Vehicle Battery in the Maintenance and Specifications chapter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 201
Temperature sensor 40A** Vacuum pump 40A** Motor control relay fuse 40A** On-board charger 40A** Heater element 1 — Not used 40A** Heater element 2 — Not used 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 202
Not used 20A* Coolant water pumps Vehicle audible speaker for pedestrians 15A* Powertrain control module (electronic control module KL15) Not used (spare) Electronic power assist steering 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 203
Electronic fan control module relay Mini relay Heater blower relay Mini relay Motor control relay Power relay Mechanical relay Power relay Ignition 15 *Mini Fuses **Cartridge Fuses 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 204
Interior light, Driver door switch pack, Glove box illumination, Overhead console switch bank Cigar lighter, Power point Rain sensor module — Not used — Not used Liftgate release 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 205
Front seat heater switch Airbag module, Occupant classification sensor, Passenger airbag deactivation indicator — Not used Supply for F67, F69, F71 and F79 — Not used 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 206
Door control unit – rear right — Not used Driver seat motor Rear window defroster Battery electronics control module — Not used — Not used — Not used — Not used 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 207
Not used — Not used — Not used — Not used — Not used — Not used — Not used — Not used — Not used 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 208
Protected components number rating — Rear 15 relay — Rear window defrost relay — Rear wiper relay — Not used — Not used — Not used 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
GENERAL INFORMATION Have your vehicle serviced regularly to help maintain its roadworthiness and resale value. There is a large network of Ford authorized dealers who are there to help you with their professional servicing expertise. We believe that their specially trained technicians are best qualified to service your vehicle properly and expertly.
Page 210
Failure to follow the guidelines will result in extensive damage to the high-voltage battery. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 211
4. To close the hood, lower the hood and allow it to drop from under its own weight for the last 8-11 inches (20-30 centimeters). Make sure that the hood is closed properly. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 212
B. DC/DC converter C. High voltage traction motor D. Inverter system controller E. Brake fluid reservoir F. 12-volt battery G. Power distribution box H. Windshield washer fluid 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Note: For best results, coolant concentration should be tested with a refractometer such as Rotunda tool 300-ROB75240E available from your dealer. Ford does not recommend the use of hydrometers or coolant test strips for measuring coolant concentrations. Note: It is very important to use prediluted coolant meeting the Ford specification in order to avoid plugging the small coolant passageways.
Page 214
• Do not add extra inhibitors or additives to the coolant. These can be harmful and compromise the corrosion protection of the coolant. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 215
Severe Climates If you drive in extremely cold climates: Note: It may be necessary to have an authorized Ford dealer increase the coolant concentration above 50%. Note: A coolant concentration of 60% will provide improved freeze point protection.
Page 216
Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Maintenance Only use a washer fluid that meets Ford specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing. See Technical Specifications in the Capacities and Specifications chapter.
Page 218
When a battery replacement is required, the battery should only be replaced with a Ford recommended replacement battery that matches the electrical requirements of the vehicle. Note: The clock and the preset radio stations must be reset once the battery is reconnected.
The layer of ice has many sharp edges and can damage the micro edge of the wiper rubber element. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident, an authorized dealer should check the alignment of your headlamps. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 221
If the top edge of the high intensity light zone is not at the horizontal reference line, the headlamp will need to be adjusted. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
4. Carefully lift the outer side of the headlamp and remove it. 5. Disconnect the electrical connector. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Note: If the bulb is accidentally touched, it should be cleaned with rubbing alcohol before being used. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 224
Install the new bulb in reverse order. Note: Be sure that the spring clip is not damaged or detached from the headlamp assembly during the replacement procedure. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 225
3. Remove the bulb by gently pulling the bulb straight out of the socket Install the new bulb in reverse order. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 226
A. Brake lamp bulb B. Reverse lamp bulb C. Tail lamp and side marker lamp bulb D. Turn signal bulb Install the new bulb in reverse order. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 227
* License plate lamp * High-mount brake lamp * To replace these lamps - see your authorized dealer. To replace all instrument panel lights - see your authorized dealer 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Vehicle Care GENERAL INFORMATION Your Ford or Lincoln authorized dealer has many quality products available to clean your vehicle and protect its finishes. FORD AND LINCOLN CAR CARE PRODUCTS Your Ford or Lincoln authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 229
• Using other non-recommended cleaners can result in severe and permanent cosmetic damage. • Never use abrasive materials such as steel wool or plastic pads as they can scratch the chrome surface. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Remove particles, such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout, before repairing paint chips. • Always read the instructions before using the products. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Note: Do not use sharp objects, such as a razor blade, to clean the inside of the rear window or to remove decals, as it may cause damage to the rear window defroster’s heated grid lines. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Avoid cleaners or polishes that increase the gloss of the upper portion of the instrument panel. The dull finish in this area helps protect the driver from undesirable windshield reflection. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• If the leather cannot be completely cleaned using a mild soap and water solution, the leather may be cleaned using a commercially available leather cleaning product designed for automotive interiors. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
All motor vehicles and their components were engineered and tested for reliable, regular driving. Long term storage under various conditions may lead to component degradation or failure unless specific precautions are taken to preserve the components. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 235
• Make sure all linkages, cables, levers and pins under vehicle are covered with grease to prevent rust. • Move vehicles at least 25 feet (8 m) every 15 days to lubricate working parts and prevent corrosion. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 236
(under hood) battery negative terminal should be disconnected. Failure to do this could damage the batteries. Note: If battery cables are disconnected, it will be necessary to reset memory features. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 238
Federal Motor Vehicle Safety Standard No. 139. Grades B and A represent higher levels of performance on the laboratory test wheel than the minimum required by law. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 239
• Rim: The metal support (wheel) for a tire or a tire and tube assembly upon which the tire beads are seated. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 240
E. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 241
(240 km/h), tire manufacturers sometimes use the letters ZR. For those with a maximum speed capability over 186 mph (299 km/h), tire manufacturers always use the letters ZR. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 242
2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 243
D. Maximum Load Single lb (kg) at psi (kPa) cold: Indicates the maximum load and tire pressure when the tire is used as a single, defined as two tires (total) on the rear axle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 244
B-Pillar or the edge of the driver’s door. See the payload description and graphic in the Load Carrying chapter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 245
You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 246
Then recheck the pressure with your tire gauge. 4. Replace the valve cap. 5. Repeat this procedure for each tire, including the spare. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 247
1/16th of an inch (2 millimeters). When the tire tread wears down to the same height as these wear bars, the tire is worn out and must be replaced. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 248
2001. The numbers in between are identification codes used for traceability. This information is used to contact customers if a tire defect requires a recall. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 249
(such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label (affixed to either the door hinge pillar, door-latch post, or the door edge that meets the door-latch post, next to the driver’s seating position), or the Tire Label...
Page 250
The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your tire pressure monitoring system.
Page 251
The tires should also be balanced periodically. An unbalanced tire and wheel assembly may result in irregular tire wear. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 252
USING SNOW CHAINS WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
This sequence will continue upon subsequent vehicle start-ups as long as the malfunction exists. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 254
2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 255
If the tires are properly inflated and malfunction the spare tire is not in use but the light remains on, contact your authorized dealer as soon as possible. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 256
If any tire is under-inflated, carefully drive the vehicle to the nearest location where air can be added to the tires. Inflate all the tires to the recommended inflation pressure. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
TEMPORARY MOBILITY KIT Note: The temporary mobility kit sealant compound in the canister is to be used for one tire only. See your Ford authorized dealer for additional replacement sealant canisters. The temporary mobility kit is located in the floor of the cargo area.
Page 258
• Keep the temporary mobility kit away from children. • Only use the temporary mobility kit when the ambient temperature is between -22°F (–30°C) and 158°F (70°C). 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 259
Always store the kit in its original location. • After sealant use, the tire pressure monitoring system sensor and valve stem on the wheel must be replaced by an authorized Ford dealer. • When inflating a tire or other objects, use the black air hose only. Do not use the transparent hose which is designed for sealant application only.
Page 260
6. Note: Start the motor only if the vehicle is outdoors or in a well-ventilated area. 7. Turn the dial (1) counterclockwise to the sealant position. Turn on the kit by pressing the on/off button (2). 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 261
11. After 4 miles (6 kilometers), stop and check the tire pressure. See Second stage: Checking tire pressure. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 262
After using the temporary mobility kit to seal your tire, you will need to replace the sealant canister and clear tube (hose). Sealing compound and spare parts can be obtained and replaced at an authorized Ford Motor Company dealership or tire dealer. Empty sealant bottles may be disposed of at home.
Page 263
Note: After sealant use, the tire pressure monitoring system sensor and valve stem on the wheel must be replaced by an authorized Ford dealer. You can check the tire pressure anytime within the 120 miles (200 kilometers) by performing the procedure from Second Stage: Checking Tire Pressure listed previously.
Page 264
3. Wrap the clear tube around the compressor housing. Note: If you experience any difficulties with the removal or installation of the sealant canister, consult your Ford Motor Company authorized dealer for assistance. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013...
N•m M12 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. Note: Inspect the wheel pilot bore and mounting surface prior to installation. Remove any visible corrosion or loose particles.
Devices and their location C. Make, vehicle line, series, body type D. Engine type E. Check digit F. Model year G. Assembly plant H. Production sequence number. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Code One-speed automatic (TR-WA) 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Accessories.Ford.com (United States only). Ford Custom Accessories are available for your vehicle through an authorized Ford or Ford of Canada dealer. Ford Motor Company will repair or replace any properly authorized dealer-installed Ford Custom Accessories found to be defective in factory-supplied materials or workmanship during the warranty period, as well as any component damaged by the defective accessories.
Page 271
• If you or an authorized Ford dealer add any non-Ford custom electrical or electronic accessories or components to your vehicle, you may adversely affect battery performance and durability, and may adversely affect the performance of other electrical systems in the vehicle.
3. BaseCARE – Covers 84 components 4. PowertrainCARE – Covers 29 critical components Ford ESP is honored by all Ford and Lincoln Dealers in the United States and Canada. It is the only Extended Service Plan authorized and backed by Ford Motor Company. That means you get: •...
Page 273
• Destination assistance for taxi, shuttle, rental car coverage and emergency transportation Transferable Coverage If you sell your vehicle before your Ford Extended Service Plan coverage expires, you can transfer any remaining coverage to the new owner. Whenever you sell your vehicle, prospective buyers may have a higher...
Page 274
To learn more, call our Ford ESP specialists at 800-367-3377. Don’t forget to ask about our interest free payment program, allowing you all the security and benefits Ford ESP has to offer while paying over time. You are pre-approved with no credit checks, no hassles!
Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Note: Do not insert CDs with homemade paper (adhesive) labels into the CD player as the label may peel and cause the CD to become jammed.
Page 276
(all .mp3 files play, regardless of being in a specific folder). In folder mode, the system only plays the .mp3 files in the current folder. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• In radio mode, press this button to manually search forward through the radio frequency band. • In Sirius mode, press this button to find the next available satellite radio station. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 278
(such as Jazz, Rock or News), use this button to find the previous channel in the selected category. • In CD mode, press this button to go to the previous track. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 279
The media hub is located in the center console and has the following features: A. A/V inputs B. SD card slot C. USB ports For more information, see the MyFord Touch chapter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
A. Phone B. Navigation (or Information if your vehicle is not equipped with Navigation) C. Climate D. Settings E. EV Information F. Home G. Information H. Entertainment 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 281
• Edit Route Cancel Route CLIMATE Press to select any of the following: • Driver Settings • Recirculated Air • Auto • Dual • Passenger Settings • A/C • Defrost 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 282
Press to select any of the following: • AM • FM • SIRIUS • CD • USB • BT Stereo • SD Card • A/V In 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 283
Do not pour or spray alcohol onto the display. Do not use detergent or any type of solvent to clean the display. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 284
3 mph (5 km/h). Make sure that you review your device’s manual before using it with SYNC. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 285
Viewing received text messages Editing preset text messages Navigation Using the keyboard to enter a destination Demo navigation route Adding or Editing Address Book entries or Avoid Areas 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 286
Master Reset to erase all stored information. System data cannot be accessed without special equipment and access to the vehicle’s SYNC module. Ford Motor Company and Ford of Canada do not access the system data for any purpose other than as described absent consent, a court order, or where required by law enforcement, other government authorities, or other third parties acting with lawful authority.
You can also switch your charging mode between Value Charge and Charge Now. See Convenience charging with MyFord mobile in the High Voltage Battery chapter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
The system also asks short questions (confirmation prompts) when it is not sure of your request or when there are multiple possible responses to your request. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 289
• After pressing the voice icon, wait until after the tone sounds and Listening appears before saying a command. Any command spoken prior to this does not register with the system. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 290
SD card is in the card slot. This command is only available when you have an active Sirius satellite radio subscription. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Note: Some features may not be available in your area. Contact an authorized dealer for more information. You can access these options using the touchscreen or voice commands. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 293
USB Port” section of this chapter. For a complete list of “Browse” voice commands, see USB and SD card voice commands and Bluetooth audio voice commands in the following sections. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 294
HD Radio allows you to receive radio broadcasts digitally, where available, providing free, crystal-clear sound. See HD Radio information later in this chapter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 295
See HD Radio information later in this chapter. Direct Tune Touch this button to manually enter the desired station number. Touch Enter when you are done. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 296
HD Radio reception is on, although it does not scan for HD2-HD7 channels. You may see the HD logo appear if the station has a digital broadcast. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 297
HD Radio technology. Independent entities own and operate each station. These stations are responsible for making sure all audio streams and data fields are accurate. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 298
HD Radio Technology manufactured under license from iBiquity Digital Corp. U.S. and foreign patents. HD Radio and the HD and HD Radio logos are proprietary trademarks of iBiquity Digital Corp. Ford Motor Company and iBiquity Digital Corp. are not responsible for the content sent using HD Radio technology.
Page 299
“FM2” “AM autoset preset <#>” “FM 2 preset <#>” “AM preset <#>” “HD <#>” “FM” “Preset <#>” “FM <87.9–107.9>” “Help” “FM <87.9-107.9> HD <#>” If available. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 300
Set Category for Seek/Scan allows you to select a category of music you would like to search for. You can then choose to either seek or scan for the stations playing that category. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 301
Note: Sirius does not support the Alert feature on all channels. Ford Motor Company shall not be responsible for Alert feature variation. Electronic Serial Number (ESN) is required when communicating with Sirius about your account.
Page 302
Note: Sirius reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 303
Satellite radio signal Your display may show ACQUIRING . . . to interference indicate the interference and the audio system may mute. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 304
Lock either skipped or or Skip function on locked. that station. Subscription Updated. Sirius has updated the No action required. channels available for your vehicle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 305
Note: Your vehicle may not have all these sound settings. Compression allows you to turn the compression feature on and off. Browse Touch this button to look through all available CD tracks. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 306
To access and play music from your card, press the lower left corner of the touchscreen, and then select the SD Card tab. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 307
Options allows you to view and adjust various media settings. • Sound Settings allows you to adjust settings for: • Bass • Midrange • Treble • Balance and Fade • DSP (Digital Signal Processing) 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 308
“Play video podcast <name>” “Play artist <name>” “Play video podcast episode <name>” “Play audiobook <name>” “Play video playlist <name>” “Play author <name>” “Previous” “Play composer <name>” “Repeat all” 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 309
“All songs” “Video playlist <name>” “All TV shows” “Video podcast <name>” “All video playlists” “Help” This command is only available in USB mode and are device-dependent. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 310
Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 311
A/V input jacks (white or red) inside the center console. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 312
• Control the portable media player in the same manner when used with headphones, as the auxiliary input jack does not provide control (such as Play or Pause) over the attached portable media player. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Other features, such as text messaging using Bluetooth and automatic phonebook download, are phone-dependent features. To check your phone’s compatibility, see your phone’s user manual and visit www.SYNCMyRide.com, www.SYNCMyRide.ca or www.syncmaroute.ca. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 314
2. Make sure that Bluetooth is set to On and that your cellular phone is in the proper mode. See your phone’s manual if necessary. • Select SYNC, and a six-digit PIN appears on your device. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 315
• Mute the call • Put it on hold • Turn on privacy (returns the call to your cellular phone) • Join two calls • End the call. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 316
Note: SYNC does not download read text messages from your phone. You can send and receive text messages using Bluetooth, read them aloud and translate text messaging acronyms, such as LOL. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 317
I’m running a few minutes late. I’m ahead of schedule, so I’ll be there early. I’m outside. I’ll call you when I get there. Thanks Stuck in traffic. Call me later. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 318
Text Message Notification Select a text message notification, if supported by your phone. Choose from possible system alert tones, text-to-speech or silent. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 319
“Unmute call” “Hold call off” “Help” “Hold on” This command is only available during an active call. If you have said “Messages”, see the following “Messages” chart. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 320
Note: You can also set up the charging convenience features using MyFord Mobile over the internet or smartphone application. For more information on MyFord Mobile, and to set up your MyFord Mobile account, visit www.myfordmobile.com. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 321
• Displays the estimated minimum and maximum times to fully charge the high-voltage battery. • Displays the battery’s present state of charge as a percentage of total capacity. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 322
Battery shows you the battery’s current charge displayed as a percentage. A reading of 100% means the battery has a full charge. A reading of 0% means the battery has no charge. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 323
Charge Now if you want your vehicle to immediately charge when plugged in at this profile location. This button illuminates when Charge Now is the charge mode selected for the presently detected charge profile. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 324
It is normal for the estimated complete time to change while charging. The vehicle keeps charging until the high-voltage battery is fully charged. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 325
Note: Cabin conditioning can perform differently depending on if you plug into a 120V convenience cord or 240V charging station. The power available for conditioning is limited to the charging station power available. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 326
Weekday and Weekend. If you touch the back arrow button to return to the previous screen without saving your settings, the system does not store them and you need to enter them again. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 327
A. Motor-to-wheel flow shows the direction of power flow between the wheels and the electric motor. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 328
H. Drive power represents the power going to the wheels. The higher the wheel power is, the larger the circle around this node. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
If your vehicle is equipped with Navigation, touch the i (Information) button to access these features. If your vehicle is not equipped with Navigation, touch the corner of the touchscreen with the green tab. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 330
Note: This feature does not function properly if you have enabled caller ID blocking on your mobile phone. Make sure your mobile phone is not blocking caller ID before using SYNC Services. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 331
For more information, see SYNC Services Terms and Conditions at www.SYNCMyRide.com. If you do not want Ford or its service providers to collect your vehicle travel information or other information identified in the Terms and Conditions, do not subscribe or use the service.
Page 332
Route Summary Turn List or the Route Status ETA. You can also turn voice guidance on or off, cancel the route or update the route. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 333
VIN (Vehicle Identification Number). You can pair and connect your phone to any vehicle equipped with SYNC Services and continue enjoying your personalized services. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 334
Sirius Travel Link. Note: Neither Sirius nor Ford is responsible for any errors or inaccuracies in the Sirius Travel Link services or its use in vehicles. When you subscribe to Sirius Travel Link, it can help you locate the best...
Page 335
You can also save up to 10 favorite teams for easier access. The score automatically refreshes when a game is in progress. Ski Conditions Touch this button to view ski conditions for a specific area. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 337
Navigation, touch the corner of the touchscreen with the green tab. Press Calendar. You can view the current calendar by day, week or month. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 338
• For information on airbag deployment, see the Supplementary Restraints System chapter. • For information on the fuel pump shut-off, see the Roadside Emergencies chapter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 339
• SYNC says the following, or a similar message: “SYNC will attempt to call 911, to cancel the call, press Cancel on your screen or press and hold the phone button on your steering wheel.” 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 340
Note: This feature may not function properly if you have enabled caller ID blocking on your mobile phone. Before running a report, review the Vehicle Health Report Privacy Notice. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 341
“Vehicle health report”. Vehicle Health Report Privacy Notice When you create a Vehicle Health Report, Ford Motor Company may collect your cellular phone number (to process your report request) and diagnostic information about your vehicle. Certain versions or updates to Vehicle Health Report may also collect more vehicle information.
From this screen, you can also make other adjustments, such as 12– or 24–hour mode, activate GPS time synchronization and have the system automatically update for new time zones. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 343
• Compatible file formats are as follows: .jpg, .gif, .png, .bmp. • Each file must be 1.5 MB or less. • Recommended dimensions: 800 x 384. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 344
Press the Settings icon > Vehicle > Rear View Camera, then select from the following settings: • Rear Camera Delay • Visual Park Aid Alert • Guidelines. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 345
Install Applications Install any downloaded applications or view the current software licenses. Master Reset Select to restore factory defaults. This erases all personal settings and personal data. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 346
Media Candidate Candidate lists are possible results from your Lists voice commands. The system simply makes a best guess at your request with these turned off. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 347
With this feature on, the Gracenote Database supplied cover art for your music files. This overrides any art from your device. This feature defaults to Media Player. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 348
Have the system turn on your radio for traffic announcements. Avoid Areas Enter specific areas that you would like to avoid on planned navigation routes. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 349
Roaming Warning Have the system alert you when in Roaming mode. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 350
SYNC as the internet gateway. Gateway (Access Point) Device List allows you to view recent connections to your Wi-Fi system. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 351
Order and have the system either always attempt to connect using a USB mobile broadband or using Wi-Fi. The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 352
ICE 1 and ICE 2 buttons. The ICE contacts you select appear at the end of the 911 Assist call process. Voice Command List View categorized lists of voice commands. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
• Distributes air through instrument panel vents. • Is more economical and efficient than normal A/C mode. • May help reduce odors from entering your vehicle. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 354
J. Driver settings: Touch + or – to adjust the temperature. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Press the green corner of your touchscreen, then Dest when it appears. Choose any of the following: Destination selections My Home Street Address Favorites Intersection Previous Destinations City Center Point of Interest Emergency Edit Route Cancel Route 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 357
When the system repeats the last guidance instruction, it updates the distance to the next guidance instruction, since it detects when the vehicle is moving. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 358
Pressing the Search By Name button allows you to directly enter the point of interest name into the system by using the keyboard. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 359
The icons only appear at a map scale of 5 miles (8 km) and lower. You may see the generic electrical plug icon or a brand icon for certain public charging stations. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 360
This screen displays either a facility photo (if available) or point of interest icons, such as: Hotel Coffeehouse Food & Drink Nightlife 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 361
Setting Your Navigation Preferences Select settings for the system to take into account when planning your route. Press the Settings icon > Settings > Navigation. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 362
Auto - Fill State/Province allows you have the system automatically fill in the state and province based on the information already entered into the system. Turn this feature ON or OFF. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 363
3D landmarks appear as clear, visible objects that are typically recognizable and have a certain tourist value. The 3D landmarks appear in 3D map mode only. Coverage varies, and improves with updated map releases. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 364
To turn the feature off, just press the + or - button again. In 3D mode, rotate the map view by swiping your finger across the shaded bar with the arrows. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 365
No GPS symbol indicates that insufficient GPS satellite signals are available for accurate map positioning. This icon may display under normal operation in an area with poor GPS access. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 366
Annual navigation map updates are available for purchase through your dealership, by calling 1-800-NAVMAPS (in Mexico, call 01–800–557–5539) or going to www.navigation.com/ford. You need to specify the make and model of your vehicle to determine if there is an update available.
Page 367
Destination chart. If you have said the command, “Navigation”, you may say any of the above commands or commands in the following Navigation chart. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 368
“Destination street address”, the system asks you to say the full address. The system displays an example on-screen. You can then speak the address naturally, such as “One two three four Main Street, Anytown”. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
SYNC® End User License Agreement (EULA) • You have acquired a device (“DEVICE”) that includes software licensed by Ford Motor Company and its affiliates (“FORD MOTOR COMPANY”) from an affiliate of Microsoft Corporation (“MS”). Those installed software products of MS origin, as well as associated media, printed materials, and “online”...
Page 370
Neither FORD MOTOR COMPANY nor its suppliers shall be liable for any damages arising out of errors in the speech recognition process.
Page 371
• Consent to Use of Data: You agree that MS, Microsoft Corporation, FORD MOTOR COMPANY, third party software and systems suppliers, their affiliates and/or their designated agent may collect and use technical information gathered in any manner as part of product support services related to the SOFTWARE or related services.
Page 372
DEVICE. UPGRADES AND RECOVERY MEDIA: If the SOFTWARE is provided by FORD MOTOR COMPANY separate from the DEVICE on media such as a ROM chip, CD ROM disk(s) or via web download or other means, and is labeled “For Upgrade Purposes Only” or For Recovery Purposes...
Page 373
For additional information, see http://www.microsoft.com/exporting/. TRADEMARKS: This EULA does not grant you any rights in connection with any trademarks or service marks of FORD MOTOR COMPANY, MS, Microsoft Corporation, third party software or service providers, their affiliates or suppliers.
Page 374
End user notice Microsoft® Windows® Mobile for Automotive Important Safety Information This system Ford SYNC™ contains software that is licensed to Manufacturer FORD MOTOR COMPANY by an affiliate of Microsoft Corporation pursuant to a license agreement. Any removal, reproduction, reverse engineering or other unauthorized use of the software from this system in violation of the license agreement is strictly prohibited and may subject you to legal action.
Page 375
Speech recognition software is inherently a statistical process which is subject to errors. It is your responsibility to monitor any speech recognition functions included in the system and address any errors. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 376
Not all emergency services such as police, fire stations, hospitals and clinics are likely to be contained in the map database for such navigation features. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 377
TeleNav with true, accurate, current, and complete information about yourself, and (b) to inform TeleNav promptly of any changes to such information, and to keep it true, accurate, current and complete. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 378
TeleNav Software. For example but without limitation, you agree not to rely on the TeleNav Software for critical navigation in areas where the well-being or survival 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 379
TELENAV SOFTWARE. SOME STATES AND/OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 380
TeleNav and its suppliers and licensors hereby reserve all of their respective rights other than the licenses explicitly granted in this Agreement. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 381
NAVTEQ North America, LLC (“NT”) within thirty (30) days of purchase for a refund of your purchase price. To contact NT, please visit www.navteq.com. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 382
Manuals and other documentation. Specifically, Multi-disc sets may only be transferred or sold as a complete set as provided to you and not as a subset thereof. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 383
INABILITY TO USE THIS DATA, ANY DEFECT IN THIS DATA, OR THE BREACH OF THESE TERMS OR CONDITIONS, WHETHER IN AN ACTION IN CONTRACT OR TORT OR BASED ON A WARRANTY, EVEN 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 384
State of Illinois for any and all disputes, claims and actions arising from or in connection with the Data provided to you hereunder. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 385
U.S. Patent: #6,304,523. Gracenote and CDDB are registered trademarks of Gracenote. The Gracenote logo and logotype, and the Powered by Gracenote™ logo are trademarks of Gracenote. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 386
Gracenote to count queries without knowing anything about who you are. For more information, see the web page at www.gracenote.com for the Gracenote Privacy Policy 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 387
Industry Canada technical specifications were met. The antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 388
Parts installed at your dealership carry a nationwide 12-month or 12000-mile (20000 kilometers) parts and labor limited warranty. If you do not use Ford authorized parts they may not meet our specifications and depending on the part, it could affect emissions compliance.
Page 389
Ford Motor Company has recommended maintenance intervals for various parts and component systems based upon engineering testing. Ford Motor Company relies upon this testing to determine the most appropriate mileage for replacement of oils and fluids to protect your vehicle at the lowest overall cost to you and recommends against maintenance schedules that deviate from the scheduled maintenance information.
Page 390
In order to keep your vehicle running right, it is important to have the systems on your vehicle checked regularly. This can help identify potential issues and prevent major problems. Ford Motor Company recommends the following multi-point inspection be performed at every scheduled maintenance interval to help make sure your vehicle keeps running great.
Page 391
The multi-point vehicle inspection is one more way to keep your vehicle running great! 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 392
Scheduled Maintenance 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Initial replacement at 10 years or 150000 miles (240000 kilometers), then every five years or 50000 miles (80000 kilometers). The coolant must be exchanged as indicated in the Ford Motor Company Workshop Manual. If not performed properly, damage could occur to the cooling system components.
Page 394
EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 395
EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 396
EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 397
EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Cell phone use ......14 fluid, checking ......215 Child safety restraints ....26 Automatic transmission ....149 fluid, refill capacities ....265 Child safety seats attaching with tether straps ..28 fluid, specification ....265 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 399
Getting the service Floor mats .........180 you need .........190 Fluid capacities ......265 Ordering additional owner’s literature .........196 Fog lamps ........84 Utilizing the Fuses ......198–199, 205 Mediation/Arbitration Program ........194 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 400
Locks How to use voice commands ...288 autolock ........69 childproof ........30 doors ..........67 Illuminated visor mirror .....94 Lubricant specifications ...265 Information displays ....102 Lug nuts ........264 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 401
......71 (see Motorcraft® parts) ..267 locking/unlocking doors ...67 Phone settings ....317, 348 opening the trunk .....68 Phone voice commands ....318 replacing the batteries .....56 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 402
......22 information ........309 heated ........134 SYNC® customer support ..283 SecuriLock passive anti-theft system ..........73 SYNC® Services ......329 Sending new text messages ..316 System settings ......344 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
Page 403
Windshield washer fluid and Traction control ......156 wipers Traffic preferences ....360 checking and adding fluid ..215 replacing wiper blades ...218–219 Transmission brake-shift interlock (BSI) ..150 Wrecker towing ......177 2014 Focus Electric Vehicle (fob) Owners Guide gf, 1st Printing, May 2013 USA (fus)
