Use and Maintenance Handbook
Use and Maintenance
Handbook
IRRIGAMATIC
PRO45 - PRO35
Irrigamatic
PRO45
Irrigamatic
PRO35
Carefully read this Handbook before using
Matermacc S.p.A.
Via Gemona, 18 - 33078 - San Vito al Tagliamento (PN) ITALIA
Telefono +39 0434/85267
telefax +39 0434/85517 www.matermacc.it
e-mail info@matermacc.it
Cod.58330261

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IRRIGAMATIC PRO45 and is the answer not in the manual?

Questions and answers

Related Manuals for Matermacc IRRIGAMATIC PRO45

Summary of Contents for Matermacc IRRIGAMATIC PRO45

  • Page 1 Use and Maintenance Handbook IRRIGAMATIC PRO45 - PRO35 Irrigamatic PRO45 Irrigamatic PRO35 Carefully read this Handbook before using Matermacc S.p.A. Via Gemona, 18 - 33078 - San Vito al Tagliamento (PN) ITALIA Telefono +39 0434/85267 telefax +39 0434/85517 www.matermacc.it e-mail info@matermacc.it Cod.58330261...
  • Page 2 Use and Maintenance Handbook...

  • Page 3: Updating The Manual

    Use and Maintenance Handbook INTRODUCTION This manual guide contains a description of the work and the necessary instructions for performing basic operations and regular maintenance of the device. This guide is for convenience divided into easily-defined chapters. These instructions are intended for professional users only, who are to possess specific knowledge about how to use the device, special admittance and training.

  • Page 4: Warranty Decline

    Use and Maintenance Handbook WARRANTY WARRANTY DECLINE ● Verify on delivery that the equipment has not been da- Besides what is reported in the supply maged during the transport and that the accessories contract the warranty declines: are integral and complete. ●...

  • Page 5: Notes On Safety

    Use and Maintenance Handbook NOTES ON SAFETY Operational safety For the safe operation of the device first read carefully Do not perform maintenance procedures, if they are not these notes. described in the documentation, or no training was provi- ded to the operator by the authorized regional dealer. Power supply The device is designed for the specified type of current.
  • Page 6 Use and Maintenance Handbook...

  • Page 7: Table Of Contents

    Use and Maintenance Handbook INDEX INTRODUCTION UPDATING THE MANUAL COPYRIGHT WARRANTY WARRANTY DECLINE NOTES ON SAFETY 1. General features..........................01 2. Interface............................02 3. Instructions for use.........................03 3.1 Start up and main menu.....................03 3.2 Accesso ai menu........................03 3.3 Programming an irrigation cycle..................04 3.4 Programming example of an irrigation cycle STANDARD...........05 3.5 Programming example of an irrigation cycle OPTIONAL..........09 3.6 Calibrating the machine....................14...
  • Page 8 Use and Maintenance Handbook 6. Using the GSM module (optional)...................19 6.1 Sim card assembly instructions..................19 6.2 Managing the contact list....................19 6.2.1 Adding a number to the list.................19 6.2.2 Deleting a number from the list................20 6.2.3 Enabling/disabling messages to a user..............20 6.2.4 Reading the list......................20 6.2.5 Querying the machine status................20 6.2.6 Querying the return speed..................20...

  • Page 9: General Features

    - SMS commands receive (i.e. START/STOP/ALT, • Regulation of the operating speed of up to 4 sectors speed/mm H2O adjust,...) (from 4 to 850m/h) (Irrigamatic PRO45). • Display of the actual time and irrigation end time. • Setup of job end time and automatic updating of spe- ed and pauses.

  • Page 10: Interface

    Use and Maintenance Handbook 2 USER INTERFACE The user interface is made up of a panel comprising: 1. A graphic LCD 128X64 pixel with backlight. 2. Push button to switch ON/OFF the console 3. Incremental encoder with switch setting and command operation. During an irrigation cycle the display shows actual speed, end job time, remaining unwounded hose, remaining pause time In case of anomalies appropriate messages are shown,.

  • Page 11: Instructions For Use

    Use and Maintenance Handbook 3.2 HOW TO ACCESS MENU 3 INSTRUCTIONS FOR USE (General Procedure) 3.1 START UP AND MAIN MENU To access menu and parameters to set-up the con- 1. Connect power supply cables of electronic console sole you ave to perform only three actions: to a 12V d.c. voltage source. 2.

  • Page 12: Programming An Irrigation Cycle

    Use and Maintenance Handbook 3.3 PROGRAMMING AN IRRIGATION CYCLE CALENDAR This menu allows to set the DATE / TIME of the IRR. 2K7 PRO console. OPERATION To perform an irrigation OPERATION you have to set the fol- IRR. 2K7 PRO CALIBRATION lowing parameters: CONFIGURATION...

  • Page 13: Programming Example Of An Irrigation Cycle Standard

    Use and Maintenance Handbook 3.4 PROGRAMMING EXAMPLE OF AN • Position the focus on NEXT to OUT PE IRRIGATION (STANDARD) move on to the next parame- ter: START TIME. (without parameter (TYPE REG.)) • Push the knob to confirm. Tubo da riav. 190 m NEXT BACK...
  • Page 14 Use and Maintenance Handbook PRO35 - PRO45 PRO45 4. START DELAY parameter. 5.b SECTOR 1 - 2 - 3 parameter. • Position the focus on the para- • To change the value of the START DELAY meter to modify the value. length of the sector and/or retri- SECTOR 1 eval speed place the focus on...
  • Page 15 Use and Maintenance Handbook PRO35 - PRO45 PRO35 6. END DELAY parameter. 8.a Performing the irrigation. • Position the focus on the para- • Once all the work cycle para- SUMMARY meter to modify the value. meters are set, a SUMMARY of END DELAY 14:30 - 15/06/11 the parameters appears on the...
  • Page 16 Use and Maintenance Handbook PRO35 - PRO45 PRO35 - PRO45 9. During the irrigation. 10. Interrupting / restarting the irrigation. • Once the irrigation cycle be- gins, the console mode is set to • Interrupting: Position the fo- START PAUSE (if configured), cus on STOP.

  • Page 17: Programming Example Of An Irrigation Cycle Optional

    Use and Maintenance Handbook 3.5 PROGRAMMING AN IRRIGATION • Position the focus on NEXT to P. OUT PE (STANDARD) move on to the next parame- ter: START TIME. (with parameter (TIPO REG.)) • Push the knob to confirm. Tubo da riav. PRO35 - PRO45 190 m NEXT...
  • Page 18 Use and Maintenance Handbook PRO35 - PRO45 PRO35 - PRO45 5.B Measuring unit mm (mil). 4. START DELAY parameter. • When choosing measuring unit • Position the focus on the para- mm (mil), proceed as follows. TYPE REG.E START PAUSE meter to modify the value.
  • Page 19 Use and Maintenance Handbook PRO35 - PRO45 PRO45 8. LANE WIDTH parameter. 10.b SECTOR 1 - 2 - 3 parameter. • Position the focus on the para- • To change the value of the LANE meter to modify the value. length of the sector and/or WIDTH SECTOR 1...
  • Page 20 Use and Maintenance Handbook PRO35 - PRO45 PRO35 11. END DELAY parameter. 13.a Performing the irrigation. • Position the focus on the para- • Once all the work cycle para- SUMMARY meter to modify the value. meters are set, a SUMMARY of END DELAY 14:30 - 15/06/11 the parameters appears on the...
  • Page 21 Use and Maintenance Handbook PRO35 - PRO45 PRO35 - PRO45 14. Retrieval speed adjust. 15. Interrupting / restarting the irrigation. • Once irrigation cycle has star- • Interrupting: Position the fo- ted check to the actual retrie- REGULATION [+++] cus on STOP. ving speed. REGULATION [+++] E-REG [#6] [+4 min] •...

  • Page 22: Calibrating The Machine

    Use and Maintenance Handbook 3.6 CALIBRATING THE MACHINE 3.8 CALENDAR SETTINGS • Position the FOCUS on CA- LENDAR in the main menu. CALENDAR !!! WARNING !!! The calibration menu is password- • Push the knob to confirm. protected. 15 / 06 / 11 It is only accessible to the manu- •...

  • Page 23: Work Parameters

    End irrigation delay at arrival (during this time span min. 0...120 the bypass valve will be completely open). STOP TIME Stop irigation time calculated based on 1)...5) hh:mm *calculated modifiable IRRIGAMATIC PRO45 Parameter Description RANGE DEFAULT P. OUT PE Total length of unwound hose. m (ft) 0...1500 (0..4919)

  • Page 24: Password-Protected User Parameters

    Use and Maintenance Handbook 4.1 PASSWORD-PROTECTED USER PARAMETERS (PASSWORD 1 1 1 1) Description Range Default Position of the flow valve. - inlet Flag - discharge Measuring units in use - EU (m, mm, m/h bar, mc/h) Flag - UK (ft, mil, ft/h, PSI, UKgal/ min) - US (ft, mil, ft/h, PSI, USgal/ min)

  • Page 25: Error Messages

    Use and Maintenance Handbook 5 ERROR MESSAGES The console contains a list of the last 6 error conditions that can arise. The error messages appear on the first row of the display as follows. PRESS 0 [#9] [+0 min] ERROR ELAPSED TIME ERROR DESCRIPTION ERROR CODE The errors that can occur during a work cycle together with the relative messages are provided in the table below.
  • Page 26 Use and Maintenance Handbook Type Description Conditions Correction Suspen Display cking sion R a i n o r The cycle is suspended for Valid only if the rain or ALL PV wind as long as the alarm persists wind sensor is provi- ded (par.

  • Page 27: Using The Gsm Module (Optional)

    (OPTIONAL) To add the user “Antonio”, with phone number “+393491234567” in the first position, send the following The following applies only if the IRRIGAMATIC PRO45 SMS message: console used supports the GSM/GPRS module. The user is reminded that consoles in the PRO series are WPB1(Antonio,+393491234567,ON) preconfigured to support the GSM/GPRS module.

  • Page 28: Deleting A Number From The List

    Use and Maintenance Handbook 6.2.2 DELETING A NUMBER FROM THE 6.2.5 QUERYING THE MACHINE STATUS PHONEBOOK 1. Compose the message SYS on a mobile phone. To delete a user from the list, simply send a write messa- 2. Send the SMS to the console, which replies with a ge with no content between the brackets.

  • Page 29: Changing The Current Return Speed

    Use and Maintenance Handbook 6.2.7 CHANGING THE CURRENT RETRIEVAL SPEED 6.2.8 STARTING AND STOPPING THE MACHINE REMOTELY Commands affecting the The commands to start and stop regulation parameters of the the machine are to be used exclu- machine are to be used sively when in view of the machine exclusively when in view of the (10...15m).

  • Page 30: Sms Commands

    Use and Maintenance Handbook 6.3 SMS COMMANDS Commande Reply Remarks #<n>_<state>_<name>_<code> This operation is rather long and requires at <n> operator’s index up to max 10 least 20 seconds. <state> operator’s state indicate the operator’s state according to the following diagram: 0 = unknown 1 = available 2 = current...
  • Page 31 Use and Maintenance Handbook Commande Reply Remarks SYS_<date_time>_S<state_system >_V<speed_o_height>_L<length>_ST< date_time_beginning>_ET<data_ora_fine> <date_time> date and time of the system <state_system > state of the system indicates the state either: 0 = system stopped 1 = opening of bypass and start 2 = closing flow and start 3 = starting time 4 = flow opening 5 = starting pause 6 = bypass adj.
  • Page 32 Use and Maintenance Handbook Commande Reply Remarks WTS(<date>,<time>) WTS_<Result>_<date_time> < d a t a > d a t e i n f o rma t <Result> result of the request The possible values are: DD/MM/YY <ora> time in format HH:MM:SS OK = positive result KO = negative result WTS(<date>,<time>) WET_< >_<date_time>...

  • Page 33: Test

    Use and Maintenance Handbook 7 TEST WIRING DIAGRAM The Irrigamatic PRO35-45 allows the user to verify the functionality and status of all the inputs and outputs as INPUT TERMINAL NO. well as the main devices (listed below) via a simple on site TEST procedure: RTC, EEPROM, GSM (if installed).
  • Page 34 Use and Maintenance Handbook TEST ACTION DISPLAY • If the TEST is NOT to be performed on this device, Push the knob when ESC INGRESSI appears on the display. M7 - DI Digital Imput PushURE SWITCH • If the circuit is Pushurised, CC appears (TERMINAL NO.
  • Page 35 Use and Maintenance Handbook TEST ACTION DISPLAY • If the TEST is NOT to be performed on this device, Push the knob when ESC USCITE appears on the display. AUX - DO AUX OUTPUT • Position the FOCUS on T. (TERMINAL NO.
