Page 1: Table Of Contents
Features Quick guide To operate Cleaning Battery replacement Calibration Error messages Troubleshooting guide Technical specifications Information about the scales available on the Bluelab Conductivity Pen Blulelab Probe Care Kits Bluelab limited warranty Contact details a handy solution made easy bluelab.com... -
Page 2: Features
Features Measures conductivity and temperature Hold reading function Selectable units for conductivity and Low battery indicator temperature Backlit LCD display Fully waterproof Calibration optional Auto off function Successful calibration indicator Automatic temperature compensation (ATC) Quick guide Check mark/ tick to indicate successful calibration. -
Page 3: To Operate
To operate Turn pen on Press power button. The last measurement is recalled for 3 seconds. To turn pen off Press and hold the power button until OFF is displayed. NOTE: The pen will automatically turn off after 4 minutes to conserve battery power. Power button Measure conductivity Place probe in solution and wait for reading to... -
Page 4: Cleaning
Battery replacement Calibration of the probe is required after every clean. The conductivity pen is powered with 1 x AAA alkaline battery. Do not use See the pH calibration in section 6.0. Place storage cap rechargeable batteries. A low battery warning is indicated by a battery symbol back onto the probe. -
Page 5: Calibration
Calibration Calibration of conductivity is not required for this unit as it is factory calibrated. However; if you wish to calibrate the unit follow the instructions below. YOU MUST CLEAN THE PROBE BEFORE CALIBRATING. See section 2.0. Rinse probe in fresh water and place it in a known standard solution. -
Page 6: Troubleshooting Guide
Low readings usually mean the probe is contaminated. Clean the probe and retest in a known solution. Ensure unscented cleaner is Conductivity pen used eg. Bluelab Conductivity Probe Cleaner, Jif, Liquid Vim, Soft gives low readings Scrub, Cif cream or Viss. -
Page 7: Information About The Scales Available On The Bluelab Conductivity Pen
Individual nutrient ions have different electrical effects! The true ppm of a solution can only be determined by a chemical analysis. ppm cannot be accurately measured by an EC meter. They are present on Bluelab products as a conversion guide only. The conversion is as follows;... -
Page 8: Bluelab Limited Warranty
This warranty is governed by the laws of the state of country where Product is purchased, without regard to its choice of law principles. Except as allowed by law, Bluelab does not limit or exclude other rights a consumer may have with regard to the Product. -
Page 9: Contact Details
The Bluelab Conductivity Pen comes with a 1 year limited written ® guarantee. Proof of purchase required. lets talk. If you need assistance or advice - we’re here to help you. North America Ph: 909 599 1940 NZ Ph: +64 7 578 0849 Fax: +64 7 578 0847 Email: support@bluelab.com...
