MONOPLEX SPEAKER SWITCH
Intellitec Part No. 00-00571-000
Note: The MONOPLEX SPEAKER SWITCH is a centralized audio switching center.
Power from both the ignition and battery is fed into the module. The power of
the battery is available at this box. Inadvertent shorts at this box could result in
damage and/or injury. All servicing of this box should be done only by a qualified
Service Technician.
Tools required: Low current Test Light, Accurate Voltmeter (digital read-out preferred)
INTELLITEC
SERVICE MANUAL
1
131 EISENHOWER LANE NORTH
LOMBARD, ILLINOIS 60148
630-268-0010 / 1-800-251-2408
P/N 53-22129A100
Advertisement
Related Manuals for Intellitec 00-00571-000
Summary of Contents for Intellitec 00-00571-000
- Page 1 MONOPLEX SPEAKER SWITCH SERVICE MANUAL Intellitec Part No. 00-00571-000 Note: The MONOPLEX SPEAKER SWITCH is a centralized audio switching center. Power from both the ignition and battery is fed into the module. The power of the battery is available at this box. Inadvertent shorts at this box could result in damage and/or injury.
- Page 2 Power for the control electronics is provided from the back lighting circuit. When this power is applied, the system will come up in the mute mode. 131 EISENHOWER LANE NORTH INTELLITEC LOMBARD, ILLINOIS 60148 630-268-0010 / 1-800-251-2408...
- Page 3 +12 volts, no button pressed, 0 volts with a button pressed. One channel not working. Unplug J2. Check for continuity between corre- sponding inputs and outputs. If open, replace module. 131 EISENHOWER LANE NORTH INTELLITEC LOMBARD, ILLINOIS 60148 630-268-0010 / 1-800-251-2408...
- Page 4 MONOPLEX SPEAKER SWITCH 131 EISENHOWER LANE NORTH INTELLITEC LOMBARD, ILLINOIS 60148 630-268-0010 / 1-800-251-2408 P/N 53-22129A100...
