- Page 1 Saynet-EI-Comet-WH19 OWNER'S MANUAL מדריך למשתמש Comet Please write model number here for future reference: :אנא כתוב מספר דגם כאן לעיון בעתיד...
-
Page 2: Safety Tips
Saynet-EI-Comet-WH19 SAFETY TIPS READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: 1. Proceed with caution. Read all instructions before beginning the installation. 2. WARNING! This fan may be operated only with a 2-pole switch with a 3mm contact opening each. 3. - Page 3 Saynet-EI-Comet-WH19 טיפים לבטיחות קרא ושמור את ההוראות :אזהרה: להפחתת סיכון לשריפה, התחשמלות או פגיעה באנשים, הקפידו לפעול לפי ההוראות הבאות .1. המשך בזהירות. קרא את כל ההוראות לפני שתתחיל בהתקנה .2. אזהרה! מאוורר זה יכול להיות מופעל רק עם מתג דו-קוטבי עם פתח מגע 3 מ"מ כל אחד .3.
- Page 4 Saynet-EI-Comet-WH19 FEATURES םינייפאמ FLUSH MOUNT INSTALLATION - For low ceilings DOWNROD INSTALLATION - For normal ceilings התקנה עם מוט תליה - לתקרות רגילות התקנה ללא מוט תליה - לתקרות נמוכות...
- Page 5 Saynet-EI-Comet-WH19 FEATURES םינייפאמ COMBO-BLADE Combo-Blades feature two high quality finishes on one blade. Select the one that best complements your decor, or change the style with just a flip of the blade. להבים משולבים להבים משולבים כוללים שני גימורים באיכות גבוהה על להב אחד. בחר את זה שהכי .מתאים...
-
Page 6: Preparing For Installation
Saynet-EI-Comet-WH19 PREPARING FOR INSTALLATION MOUNTING BRACKET INSTALLATION הכנה להתקנה התקנת תושבת תליה Unpack and inspect fan carefully to be certain all contents are included. Turn off power Remove the screws from the two mating holes (1) on the canopy. Loosen (do not remove) the at fuse box to avoid possible electrical shock. -
Page 7: Wiring Options
Saynet-EI-Comet-WH19 MOUNTING BRACKET INSTALLATION WIRING OPTIONS טוויח תויורשפא התקנת תושבת תליה Wiring: From House: TERMINAL BLOCK Connector: Live (L) Neutral (N) Ground Follow diagram above to make wiring connections to the termi- nal block on the mounting bracket. טוויח Drill two mounting holes in the ceiling joist and securely screw the mounting bracket to the :תיבהמ... -
Page 8: Flush Mount Option
Saynet-EI-Comet-WH19 FLUSH MOUNT OPTION הילת טומ אלל הנקתה Guide motor wires through the base of the canopy as shown and attach canopy directly to top of motor housing with flush mount screws and lock washers provided. Tighten screws securely. NOTE: IF YOU ARE INSTALLING YOUR FAN USING THE FLUSH MOUNT METHOD, PROCEED DIRECTLY TO STEP #12. הולך... - Page 9 Saynet-EI-Comet-WH19 DOWNROD MOUNT הילת טומ תנקתה Remove clamp pin (2) and cross pin (1) from downrod. Loosen setscrew in downrod ball (3) until ball moves easily up and down the downrod. Do not remove ground wire (4) from downrod. Slide downrod ball down, exposing cross pin (5). Do not remove ball completely. Remove cross pin and save for later use. הסר...
- Page 10 Saynet-EI-Comet-WH19 NORMAL DOWNROD OPTION MOUNTING הילת טומ םע הליגר הנקתה הנקתה Re-install cross pin into downrod and slide downrod ball up until cross pin fits firmly into Lower the canopy over the lead wires, plug and yoke(1) on motor assembly. Feed lead ball.
- Page 11 Saynet-EI-Comet-WH19 MOUNTING הנקתה Loosen set screws in downrod coupling (1). Insert downrod into downrod coupling. Make sure to align hole in downrod with the hole in coupling. Install yoke cross pin (2) through yoke and downrod. Insert clamp pin (3) into cross pin until it snaps into place. Tighten set screws (1) in coupling. שחרר...
- Page 12 Saynet-EI-Comet-WH19 MOUNTING BRACKET INSTALLATION הילת תבשות תנקתה Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on downrod ball (1) engages the ridge (2) on the mounting bracket. This will allow for hands free With bracket holding fan assembly, attach the male/female plug connection (1) from the fan wiring.
- Page 13 Saynet-EI-Comet-WH19 FLUSH MOUNT OPTION התקנה ישירה על התושבת ללא מוט תליה For flush mount fans, carefully lift fan from the mounting bracket, making sure not to break any wire connections. For downrod fans, slide the canopy up to the mounting bracket. The canopy has two mating slots (1) and two mating holes (2).
-
Page 14: Blade Installation
Saynet-EI-Comet-WH19 BLADE INSTALLATION SECURE TO CEILING םיבהל תנקתתה הרקתל עוביק Attach blade brackets to blades using the blade bracket screws (1), fabric washers (2), and Install two screws into the mating holes of the canopy and tighten to secure the nuts (3). - Page 15 Saynet-EI-Comet-WH19 BLADE INSTALLATION םיבהל תנקתתה If plastic shipping stabilizer tabs are attached to motor, remove and discard. Attach blade assembly to motor using the noise-dampening motor gaskets and motor screws provided. Tighten screws securely. NOTE: Some models do not utilize motor gaskets, washers, or stabilizer tabs. אם...
-
Page 16: Light Fixture Installation
Saynet-EI-Comet-WH19 LIGHT FIXTURE INSTALLATION הרואת ףוג תנקתה Connect the single plug (1) and 9-pole connector (2) from the fan to the single plug and 9-pole connector from the switch housing. Attach the switch housing using the screws and washers provided. Install light bulbs (not included). - Page 17 Saynet-EI-Comet-WH19 LIGHT FIXTURE INSTALLATION PULL CHAINS INSTALLATION הרואת ףוג תנקתה הכישמ תוארשרש תנקתה Assemble decorative fob and extension chains from hardware bag to fan pull chains by inserting end of chain into chain coupling. Confirm chains are held by lightly pulling both chains in coupling. Install glass shade and finger-tighten screws as shown.
-
Page 18: Operation And Maintenance
Saynet-EI-Comet-WH19 OPERATION & MAINTENANCE Operation Turn on the power and check operation of fan. The pull chain controls the fan speeds as follows: 1 pull - high; 2 pulls - medium; 3 pulls - low; 4 pulls - off. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. - Page 19 Saynet-EI-Comet-WH19 תפעול ותחזוקה תפעול :הדלק את המאוורר ותבדוק את פעילותו. שרשרת משיכה מפעילה את מהירות המאוורר כדלקמן משיכה אחת - גבוה, שתי משיכות - בינוני, שלוש משיכות - חלש, 4 משיכות - כיבוי. הגדרות המהירות למזג אוויר חם או קריר תלויות בגורמים כמו גודל החדר, גובה התקרה, מספר המאווררים וכן הלאה. קיים מתג השולט בכיוון הסיבוב, עם .או...
-
Page 20: Troubleshooting Guide
Saynet-EI-Comet-WH19 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be TROUBLESHOOTING GUIDE mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. - Page 21 Saynet-EI-Comet-WH19 מדריך פתרון בעיות אם אתה מתקשה להפעיל את מאוורר התקרה החדש שלך, זה עשוי להיות תוצאה של הרכבה, התקנה או חיווט שגויים. במקרים מסוימים, טעויות התקנה אלה עלולות להיחשב לעתים בתור פגמים. אם אתה נתקל בתקלות כלשהן, אנא בדוק את תרשים שלפניך. אם לא ניתן לתקן בעיה, אנא התייעץ עם החשמלאי .המוסמך...
- Page 22 Saynet-EI-Comet-WH19 Meaning of crossed-out wheeled dustbin: Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact you local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.
- Page 23 Saynet-EI-Comet-WH19...
- Page 24 Saynet-EI-Comet-WH19 Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. www.westinghouselighting.com , WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF are trademarks of Westinghouse Electric Corporation. Used under license by Westinghouse Lighting All rights reserved. Made in China...
