Monitor LEDs

The Click 330 has two different kinds of LEDs.
At the top of each device are two green LEDs labeled US1 and US2, used for monitoring the power supply. US1 monitors the
˽
first power supply (the one using the screw terminal marked US1) and US2 monitors the second (redundant) power supply.
Status Meaning
On Supply voltage is in an acceptable range
Off Supply voltage is too low
Each Ethernet port has two LEDs that show the data transmission speed of that port, as shown in the table below. These
˽
LEDs are labeled 100/ACT and 1000/ACT. If the LED is on, there is an electrical link. If the LED blinks, there is currently
network traffic at that speed.
LED
100/ACT
1000/ACT
