- Page 1 20v Max* Lithium Oscillating Multi-Tool NIVERSAL COMPATIBLE WITH: CON| / AVEC F I T M E N T WALT ® ™ Batteries and chargers sold separately. Instruction manual CATALOG NUMBER PCC710 *Maximum initial battery pack voltage (measured without a workload) is 20 volts. The nominal voltage is 18.
-
Page 2: Safety Guidelines - Definitions
SAFETY GUIDELINES - DEFINITIONS It is important for you to read and understand this manual. The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help you recognize this information. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 3: Specific Safety Rules
better control of the power tool in unexpected situations. f) Dress properly. Do not wear loose clothing or jewelry. keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. -
Page 4: Personal Safety
cushion, take frequent rest periods, and limit daily time of use. • Always hold the tool firmly with both hands for maximum control. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. •... -
Page 5: Environmental Safety
• Shock hazard. Do not allow any liquid to get inside charger. • Burn hazard. To reduce the risk of injury, charge only designated PORTER-CABLE batteries. Other types of batteries may burst causing personal injury and damage. - Page 6 The charger and battery pack are specifically designed to work together. • These chargers are not intended for any uses other than charging designated PORTER-CABLE rechargeable batteries. Any other uses may result in risk of fire, electric shock or electrocution.
- Page 7 2. Long storage will not harm the battery pack or charger. Charging Procedure PORTER-CABLE chargers are designed to charge PORTER-CABLE battery packs. Charge times are: PCC690L and PCC692L in 35-100 mins., PCC691L in 65-200 mins. and PCC695L in 160-300 mins. depending on the pack being charged.
- Page 8 This is important and will prevent serious damage to the battery pack. 2. The charger and battery pack may become warm to touch while charging. This is a normal condition, and does not indicate a problem. To facilitate the cooling of the battery pack after use, avoid placing the charger or battery pack in a warm environment such as in a metal shed, or an uninsulated trailer.
- Page 10 ASSEMBLY WARNING: Disconnect the plug from the power source before making any assembly, adjustments or changing accessories. Such preventive safety measures reduce the risk of starting the tool accidentally. WARNING: Risk of lacerations or burns. Do not touch the sharp edges of accessories at any time.
-
Page 11: Helpful Hints
Li-Ion battery to an authorized PORTER-CABLE service center or to your local retailer for recycling. You may also contact your local recycling center for information on where to drop off the spent battery. -
Page 12: Troubleshooting
TROUBLEShOOTING Problem Possible Cause Possible Solution • Unit will not start. • Battery pack not installed properly. • Check battery pack installation. • Battery pack not charged. • Check battery pack charging requirements. • Unit starts immediately • The switch has been • The switch must be moved upon inserting battery. left in the “on” position. to “off” to prevent the tool from immediately starting when battery is inserted • Battery pack will not charge. • Battery pack not inserted into charger. • Insert battery pack into charger until LED lights.
