- Page 1 Model SM6100SA User Guide Power Amplifier...
- Page 3 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
-
Page 4: Safety Instructions
This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of. 1. Read Instructions — All the safety and operating instruc- tions should be read before the appliance is operated. 2. - Page 5 Do not handle the mains lead with wet hands. EQUIPMENT MAINS WORKING SETTING Your Marantz product has been prepared to comply with the household power and safety requirements that exist in your area. Please make sure the mains voltage of your area and the version of this product (written on the back) are correct.
- Page 6 DIRECT INPUT CONNECTION When you desire to have high quality sound reproduction, connect the input signal to DIRECT INPUT jacks and switch the INPUT MODE switch to DIRECT INPUT position. The LEVEL controls on the rear panel cannot be used in this mode (Fixed input level).
- Page 7 Set to WARNING : SHOCK HAZARD - DO NOT OPEN VARIABLE INPUT Connection diagram for additional SM6100SA If there is no need to adjust the volume level, set the LEVEL controls to the MAX position. MODEL NO. SM6100 / U1B...
-
Page 8: Front View
FIGURES FRONT VIEW POWER AMPLIFIRE SM6100SA REAR VIEW t y u DIRECT DIRECT VARIABLE VARIABLE LEVEL LEVEL INPUT INPUT INPUT INPUT OUTPUT OUTPUT WARNING : SHOCK HAZARD - DO NOT OPEN AVIS : RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR. -
Page 9: Names Of Controls And Indicators
(POWER OFF mode). When it required to use remote control to the power on or off, use system remote controller of the MARANTZ equipment. w w w w w Power indicator When the POWER ON mode, the indicator lights blue. - Page 10 WHAT IS BI-AMP ? “Bi-amp (connection)” is a technique which is designed to make the enjoyment of sound reproduction more complete. Bi-amp refers to the use of two power amplifiers to drive individual speaker units a tweeter and a woofer. The connection shown in the figure below is known as a bi-amp connection.
-
Page 11: Bi-Amp Connection
When using an already purchased preamplifier with two sets of PRE OUTPUT jacks, the bi-amp connections can be provided as shown in the figure below. The speaker systems will then be driven more powerfully by the two SM6100SA. The example shows the speaker terminals that support bi-amp connections. “HF” (= high frequency) in the figure denotes the input jacks of the tweeter;... -
Page 12: Troubleshooting
If the trouble still persists after checking, please consult your dealer or nearest MARANTZ service agent. The amplifier does not work and the indicator does not light. 1. Check if the power cord is plugged properly into an AC power outlet. - Page 13 P.O. Box 685, Bell Village, Port Louis, Mauritius PO BOX 1280, Sandhausen 69200, Germany A division of Marantz Europe B.V., Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands 4 Station Street, Thornleigh NSW 2120, Australia Sandkerveien 64, Oslo 0483, Norway P.O.
