- Page 1 READ AND SAVE THESE INSTRUCTIONS CEILING FAN INSTALLATION AND OPERATION INSTRUCTION FAN RATING AC 120V. 60Hz UL LISTED MODEL: AC-552 WEIGHT OF FAN: 6.24 KGS...
-
Page 2: Tools And Materials Required
1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Blade set (5) Hanger bracket Canopy Downrod Fan motor assembly Blade bracket set (5) -
Page 3: Safety Rules
3. SAFETY RULES 1. To reduce the risk of electric shock, insure 7. Do not operate reversing switch while fan electricity has been turned off at the blades are in motion. Fan must be circuit breaker or fuse box before turned off and blades stopped before beginning. -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing UL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or Outlet box turning off circuit breakers. Secure the outlet box directly to the building structure. Use appropriate fasteners and Figure 1 building materials. -
Page 5: Hanging The Fan
5. HANGING THE FAN REMEMBER to turn off the power. Follow the UL Listed electrial steps below to hang your fan properly. NOTE: This ceiling fan is supplied with two types of hanging assemblies; the standard ceiling Ceiling Washers installation using the downrod with ball and mounting socket mounting and the "close-to-ceiling"... - Page 6 LOSE-TO-CEILING INSTALLATION 1. Remove the decorative canopy bottom Canopy cover from the canopy. (Fig. 8) 2. Pass the 120-volt supply wires through the center hole in the ceiling hanger bracket as Canopy bottom cover shown in Fig. 5. Figure 8 3.
-
Page 7: Make The Electric Connections
6. MAKE THE ELECTRIC CONNECTIONS SUPPLY CIRCUIT Remember to disconnect the power. Ground Follow the steps below to connect the fan to Conductor your household wiring. Use the wire connecting nuts supplied with your fan. Secure the connectors with electrical tape. Outlet Box Make sure there are no loose strands or connections. -
Page 8: Finishing The Installation
7. FINISHING THE INSTALLATION Outlet box Screws Hanger STANDARD CEILING INSTALLATION bracket Canopy Slide canopy up to the ceiling as shown in Figure 12. Make sure you place the wires safely into the outlet box. Secure the canopy to the hanger bracket with the four screws with your fan. -
Page 9: Attaching The Fan Blades
8. ATTACHING THE FAN BLADES CAUTION: Remove 5 rubber packing mounts and discard before installation. Step 1 Attach the blade to the blade bracket using the screws and fiber washers as shown in Figure 14. Start screw into bracket. Repeat for the two remaining screws. -
Page 10: Operating Your Fan
9. OPERATING YOUR Turn on the power and check the operation of your fan. The pull chain controls the fan speed as follows: 1. 3-speed pull chain- it controls the fan speed as follows: 1 pull- High, 2 pulls- Medium, 3 pulls- Low, and 4 pulls- Off. Speed settings for warm or cool weather depend on factors such as the room size, ceiling height, number of fans, and so on. -
Page 11: Care Of Your Fan
10. CARE OF YOUR FAN Here are some suggestions to help you maintain your fan 1. Because of the fan's natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. (It is not necessary to remove fan from ceiling.) 2.
