Echo shindaiwa RS850W Operator's Manual

Broadcast spreader
Hide thumbs

Advertisement

Quick Links

Download this manual
Operator's
Manual
RS850W
Broadcast
Spreader
X7507840600
© 3/22 ECHO Incorporated

Advertisement

loading
Need help?

Need help?

Do you have a question about the shindaiwa RS850W and is the answer not in the manual?

Questions and answers

Related Manuals for Echo shindaiwa RS850W

Summary of Contents for Echo shindaiwa RS850W

  • Page 1 Operator’s Manual RS850W Broadcast Spreader X7507840600 © 3/22 ECHO Incorporated...
  • Page 2 Scan QR codes for more information. For additional literature, including safety manuals where applicable, or questions regarding terms used in this manual, visit: https://www.echo-usa.com/manuals https://www.shindaiwa-usa.com/manuals X7507840600 © 3/22 ECHO Incorporated...
  • Page 3 Registering your product confirms your warranty coverage and provides a direct link between you and ECHO if we find it necessary to contact you. Additional Literature In addition to finding information online, information is available from your Authorized Shindaiwa Service Dealer, or by contacting ECHO Incorporated, 400 Oakwood Road, Lake Zurich, IL 60047, 1-800-432-ECHO (3246).
  • Page 4 Wear all personal protective equipment recommended by ◆ chemical manufacturer. Read and follow the chemical label instructions and ◆ warnings for handling and applying the chemicals you plan to spread – application settings provided are only a guideline. X7507840600 © 3/22 ECHO Incorporated...
  • Page 5 RS850W DESCRIPTION DESCRIPTION Handles Hopper Wheels Adjustable Deflectors Gate Control Rod Gate Control Lever Gate Adjustment Limiter X7507840600 © 3/22 ECHO Incorporated...
  • Page 6 Control Rod Adapter Grate Hopper Cover 6 mm Nut Cotter Pin 6 mm Flange Nuts 6 x 60 mm Bolts 6 x 50 mm Bolt Metal Washer Nylon Washer Rear Deflector Operator’s Manual Warranty Statement X7507840600 © 3/22 ECHO Incorporated...
  • Page 7 ASSEMBLY ASSEMBLY Install Wheels and Handle Install left wheel and secure with washer (A) cotter pin (B). Install right wheel and secure with 6 x 50 mm bolt (C) and 6 mm flange nut (D). X7507840600 © 3/22 ECHO Incorporated...
  • Page 8 (G) and two 6 mm flange nuts (H). Install Gate Control Rod Insert tab end of gate control rod (C) into slotted hole in gate control lever (B). Turn rod clockwise until it is parallel with handle assembly. X7507840600 © 3/22 ECHO Incorporated...
  • Page 9 Attach control rod adapter to gate linkage (F). Secure with 6 mm flange nut (G) and nylon washer (H). Tighten nut until snug, then loosen nut 1/4 turn to allow hinge movement. X7507840600 © 3/22 ECHO Incorporated...
  • Page 10 ASSEMBLY RS850W Push control rod adapter (D) downward until gate is fully closed. Position gate control lever fully forward, and tighten control rod nut and flange nut as shown. X7507840600 © 3/22 ECHO Incorporated...
  • Page 11 Install grate into hopper. Turn grate clockwise to lock into place. Rear Deflector Install rear deflector (A) as shown. Check Tire Pressure Tires should be inflated to 15 psi. Assure tire pressure does not exceed 30 psi. X7507840600 © 3/22 ECHO Incorporated...
  • Page 12 Use gate adjustment limiter (B) to restrict gate opening size. Push gate control lever (A) fully forward to close gate. Fill hopper with product. Fill hopper in an area that won’t be damaged by spilled product. X7507840600 © 3/22 ECHO Incorporated...
  • Page 13 Reinicie Reinicie Mise en Remise en Remise en marche marche marche RESTART RESTART Reinicie Reinicie Remise en Remise en marche marche SHUT OFF HERE SHUT OFF HERE Apague aquí Apague aquí Arrêt ici Arrêt ici X7507840600 © 3/22 ECHO Incorporated...
  • Page 14 MAINTENANCE RS850W MAINTENANCE Cleaning Spreader Avoid spraying gear case directly, and do not use a pressure washer on spreader. Wash spreader with a garden hose after each use. X7507840600 © 3/22 ECHO Incorporated...
  • Page 15 Lubrication Lubricate gear case and axle once per season. Gear case and Axle: Clear debris from grease fittings (A). Apply 1-2 pumps of lithium-based grease with appropriate grease gun. Clean excess grease from grease fittings. X7507840600 © 3/22 ECHO Incorporated...
  • Page 16 Please go to http://www.shindaiwa-usa.com to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO Incorporated. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
  • Page 17 RS850W PRODUCT REGISTRATION X7507840600 © 3/22 ECHO Incorporated...
  • Page 18 NOTES RS850W NOTES X7507840600 © 3/22 ECHO Incorporated...
  • Page 19 RS850W NOTES X7507840600 © 3/22 ECHO Incorporated...
  • Page 20 N3120001001 - N31200999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 -usa www.shindaiwa .com...
