Talk Tischfuss-Montage/Table leg assembly Tischfuss eingerückt Table leg indented Tischfuss unter der Tischfuge Table leg beneath the table-join...
Page 3
Talk Tisch-Montage/Table assembly WICHTIG. Der Tischfuß muss vollständig auf der Montageplatte aufliegen! IMPORTANT. The table leg needs to be fully in cont- act with the mounting plate! Justierbarer Gleiter Adjustable glider...
Page 6
Zur Vibrationsdämpfung bei dauerhaft aufgebauten TALK-Tischanlagen montieren Sie bitte zusätz- lich die beiliegenden Metallstützen (stets paarweise) gegen das im Plan vorgegebene Tischbein. For vibration damping in permanently built-up TALK table configurations please mount the enclosed metal supports (always in pairs) additionally against the table leg specified in the plan.
Page 7
Talk Montage Dämpfungselement/Damping element assembly Zur Tischplatte hin immer mit Schraube M6x20, Unterlegscheibe und Zahnscheibe (Kombination siehe Abbildung) verschrauben. For screwing the support towards the table top be sure to use M6x20 screw, washer and tooth lock washer (see image for combination) at all the times.
