- Page 1 Assembly instructions / Instructions de montage Flat Design by Ichiro Iwasaki Version U01...
- Page 2 - Do not disassemble, modify or try to repair this fitting. In order to get technical assistance contact VIBIA. Any change or - Nous vous recommandons de lire le manuel avant de modification to the light fitting can null the manufacturer’s...
- Page 3 Index Step 1 Product Spec Sheet Step 2 Supplied Materials Step 3 Product Assembly Step 4 Electrical Connection Step 5 Adjustments & Maintenance 3/10...
- Page 4 Step 1/5 Product Spec Sheet Technical specifications / Caractéristiques techniques 5945 Net Weight / Poids net 34.95 lbs. 2 x LED PLATE 7W 400mA 50/60 Hz. IP20 Bi-volt PUSH Dry Location IP20 Dry Location Bi-volt This lamp is for indoor use Product protected against Voltage range: Alternating current.
-
Page 5: Supplied Materials
Step 2/5 Supplied Materials Supplied material / Matériel fourni 5945 1 un. 1. Diffusers / Diffuseurs 1 un. 2. Lighting fixture / Structure du luminaire 1 un. 3. Driver + Plug / Transformateur + Fiche 5/10... -
Page 6: Product Assembly
Step 3/5 Product Assembly - VERY IMPORTANT: Make sure before making the connection of the LED plate that the plug to the Driver is disconnected. - TRÈS IMPORTANT: Assurez-vous que le fiche du transformateur est débranchée avant de connecter la plaque Leds. 6/10... - Page 7 Step 3/5 Product Assembly o 2 - 1 Paso 2 - 2 - VERY IMPORTANT: Make sure before making the connection of the LED plate that the plug to the Driver is disconnected. - TRÈS IMPORTANT: Assurez-vous que le fiche du transformateur est débranchée avant de connecter la plaque Leds.
-
Page 8: Electrical Connection
Step 4/5 Electrical Connection "Click" "Click" 8/10... -
Page 9: Adjustments & Maintenance
Step 5/5 Adjustments & Maintenance SWITCHING ON THE LIGHT ALLUMAGE DE LA LAMPE -Pulse button -Bouton -First pulse: lights up to 33% of full intensity -Second pulse: lights up to 66% of full intensity -Première appuyant: 33% d’intensité -Deuxième appuyant: 66% d’intensité -Third pulse: lights up to 99% intensity -Fourth pulse: turns off the light -Troisième appuyant: 99% d’intensité... - Page 10 In case of malfunction or damage, please contact the distributor who sold the lamp. En cas d’incident ou de non fonctionnement du luminaire, con- tactez directement l’établissement où vous l’avez acheté. VIBIA. INC. 272 Fernwood Ave. Edison, NJ 08837 . USA Phone 732 417 1700.
