GENESIS FITTED FURNITURE
Basin Unit:
Art No. NF02SBU50*** / NF02SBU60***
BTW Unit:
Art No. NF02SBTW50*** / NF02SBTW60***
Single Door Unit:
Art No. NF02SSDU30***
Three Drawer Unit:
Art No. NF02S3DR30***
Open Shelf Unit:
Art No. NF01SOS20***
End Panels:
Art No. NF01SEP***
Infill Panels:
Art No. NF01IP20***
Plinth:
Art No. NF01PL100*** / NF01PL150*** / NF01IP200***
MBL - Midnight Blue | DEM - Dark Emerald | CGR - Carbon Grey |
MWH - Matt White | SWO - Sherwood Oak
Thank you for purchasing this HiB Novum product.
Please read through these instructions carefully and refer back to
them during installation to ensure that your product is fitted safely
and that it retains its high quality finish.
FI#03 020 R220422
Ver
1.0 June 2022
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HiB Novum NF02SBU50 Series
Summary of Contents for HiB Novum NF02SBU50 Series
- Page 1 MBL - Midnight Blue | DEM - Dark Emerald | CGR - Carbon Grey | MWH - Matt White | SWO - Sherwood Oak Thank you for purchasing this HiB Novum product. Please read through these instructions carefully and refer back to them during installation to ensure that your product is fitted safely and that it retains its high quality finish.
- Page 2 Warnings for Safe Use • Please read the instructions and warnings carefully before installing the product and ensure this document is kept with the product for future reference, to ensure product longevity and in the interest of safety. • This product is intended for domestic use only. •...
- Page 3 Top Panel Installation • BTW Front Panel Installation • Drawer Installation • Handle Installation • Care & Maintenance • Aftercare Tools Required Suitable Drill Dust Mask Pencil Drill Bit Protection Silicone Clamps Spirit Level Tape Screwdriver Measure Fine Tooth Tape hib.co.uk...
- Page 4 Figures Fig. 1 - Carcass Leg Installation Fig. 2 - BTW Leg Installation Standard Plinth: H150mm Fig. 3 - Plinth Height Basin Unit BTW Unit Fig. 4 - Connecting Units...
- Page 5 See Fig. 2. 7. Insert the legs into the leg brackets. 8. Adjust the legs to the required height by turning the feet. The HiB standard plinth height is 15cm, see Fig. 3. 9. Position the units together in the configuration required against the wall.
- Page 6 Figures Plinth Return: BTW Unit Basin Unit W65mm Fig. 5 - Plinth Measurements Fig.6 - Plinth Return Fig.7 - Plinth Bracket Installation...
- Page 7 Measure the width and height required, see Fig. 5. HiB recommends installing plinths 2mm from the floor. 2. If installing a BTW unit, a return piece will need to be cut from the plinth. HiB recommends a return of 65mm, see Fig. 6.
- Page 8 Figures 830mm Fig. 8 - Recommended Install Height Fig. 9 - Measure & Cut Panel Fig. 10 - Seal cut edges 1. Loosen screw 2. Adjust furniture postion 3. Tighten screw Fig. 11 - Hanger Adjustment...
- Page 9 7. Slide the back panel back into position and replace shelves. 8. Measure and cut any end panels and infill panels required, see Fig. 9. Seal all cut edges, see Fig. 10. HiB recommends positioning the cut edge at the top of the unit.
- Page 10 Figures Move door(s) up/down Move door(s) up/down Move door away/towards the cabinet Move door away/towards the cabinet Move door(s) le /right Move door(s) le /right Fig. 12 - Release hinge plate Fig. 13 - Door Adjustment Fig. 15 - BTW Front Panel Fitting Fig.
- Page 11 2. Push the hinge plate into the pre-drilled holes provided and secure into place using the screws provided. HiB advises against using an impact driver. When installing a single door unit, take note of the left hand / right hand orientation prior to installation.
- Page 12 Figures Locator Pin Adjustment Wheel Fig. 17 - Locator Pin & Adjustment Wheel Fig. 16 - Drawer Runner Rear Hooks 1. Loosen screw 2. Adjust drawer front 3. Tighten screw Fig. 18 - Drawer Front Adjustment...
-
Page 13: Handle Installation
Drawer Installation and Adjustment HiB recommends fixing handles to the drawer box prior to installing the drawers. See the Handle Installation section below. 2. Align the drawer onto the runners ensuring the rear hooks are located in the holes on the rear of the drawer box, see Fig. 16. - Page 14 Ensure adequate ventilation is maintained in the bathroom. Handles HiB recommends cleaning with the use of a dry, lint free cloth or wiping the product using a soft cloth with beeswax. Under no circumstances should any form of metal cleaner, aerosol spray cleaner or solvent based abrasive cleaning solutions be applied to our products as these can remove protective lacquers.
- Page 15 hib.co.uk...
- Page 16 Building 3, North London Business Park, Oakleigh Road South, New Southgate, London. N11 1GN ©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and make sure they are as accurate as possible. In the interest of continuous product development, HiB reserves the right to alter specifications as necessary.
