GENESIS FITTED FURNITURE - TOP & BTW FRONT PANEL
Top Panel:
Art No. NF02TP50*** / NF02TP60***
BTW Front Panel:
Art No. NF02BTWFP50*** / NF02BTWFP60***
MBL - Midnight Blue | DEM - Dark Emerald | CGR - Carbon Grey |
MWH - Matt White | SWO - Sherwood Oak
Thank you for purchasing this HiB Novum product.
Please read through these instructions carefully and refer back to
them during installation to ensure that your product is fitted safely
and that it retains its high quality finish.
FI#03 023 R220426
Ver
1.0 June 2022
Advertisement
Table of Contents
Related Manuals for HiB novum GENESIS NF02TP50 Series
Summary of Contents for HiB novum GENESIS NF02TP50 Series
- Page 1 MBL - Midnight Blue | DEM - Dark Emerald | CGR - Carbon Grey | MWH - Matt White | SWO - Sherwood Oak Thank you for purchasing this HiB Novum product. Please read through these instructions carefully and refer back to them during installation to ensure that your product is fitted safely and that it retains its high quality finish.
- Page 2 Warnings for Safe Use • Please read the instructions and warnings carefully before installing the product and ensure this document is kept with the product for future reference, to ensure product longevity and in the interest of safety. • This product is intended for domestic use only. •...
- Page 3 Figures Fig. 1 - Top Panel Fitting Fig. 2 - BTW Front Panel Fitting Top Panel Installation Align the clips on the top panel with the clips on the carcass. Push the top panel into the clips to secure, see Fig. 1. BTW Front Panel Installation The BTW front panel is designed to suit a 15cm plinth height.
- Page 4 Building 3, North London Business Park, Oakleigh Road South, New Southgate, London. N11 1GN ©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and make sure they are as accurate as possible. In the interest of continuous product development, HiB reserves the right to alter specifications as necessary.
